Fitting the accessories
Screen
The screen mounting kit utilises the mirror mounts to
fix it to the scooter. Start by sliding 2 of the plastic
lugs over the L shaped chrome bars. The bars are
handed left and right. Next screw 1 nut onto the short
threaded part all the way, finger tight. Put the mirror
mount on so that the flat part faces down. Put the
other nut on finger tight. Next place the mirror through
the hole, though the spacer and screw into the mirror
mount on the handle bar. The uprights should be on
the inside. Next put the rubber pads over the chrome
screen fixings and push through the front of screen.
Put the 4 rubber washers on the back of the screen
and mount the assembly onto the frame. Use the M6
nuts and washers to fasten the screen. Position the
screen and tighten.
