Summary of Contents for ReSound Unite TV Streamer 2

  • Page 1 user guide TV Streamer 2...
  • Page 2 Welcome Statement: Congratulations on your purchase of a resound unite This device complies with Part 15 of the FCC rules. streamer 2. Operation is subject to the following two conditions: (1) this device TV streamer 2 will provide you with high quality streamed audio...
  • Page 3 TV streamer 2 is to transfer signals in countries outside eu and us. Please refer to local country re- from a TV set or other audio device to a resound wireless hear- quirements for these areas.

  • Page 4: Table Of Contents

    Operation is subject to the following two conditions: (1) this de- Contents vice may not cause interference, and (2) this device must accept description ........8 any interference, including interference that may cause undesired getting started .

  • Page 5: Description

    Description increase volume Micro-usB power socket decrease volume Pairing button Power light (green) Mono/stereo switch Analogue mini-jack audio input 10 Activity light (yellow) Optical (Toslink) audio input 11 Wall plug Coaxial audio input 12 Mini-usB plug...

  • Page 6: Getting Started

    Getting Started 4. The ”AudiO OuT” is usually marked ”L – r” for left and right, and can usually be found on the back of the audio source Installing the TV Streamer 2 depending on your TV, HiFi stereo, computer or other audio setup, the installation of TV streamer 2 may be done in several Note: With this installation, most audio sources will send ways described in the following section.
  • Page 7 Alternative analogue audio cable installations: If muted speakers are not desired, please refer to the first instal- lation, or the one on the following page. Your audio source may if it is not possible to connect the TV streamer 2 to the AudiO support speakers and HEADPHONE being on simultaneously;...
  • Page 8 Scart adapter: Connecting the TV Streamer 2 to a digital audio source (E.g. 1. Connect the power supply to the wall socket and insert the TV or HiFi stereo) cable into the micro-usB socket on TV streamer 2 2. insert the male stereo mini-jack on the audio cable into the fe- The TV Streamer 2 supports both analogue and digital au- male stereo mini-jack input on the TV streamer 2 (4 on page 8) dio input.
  • Page 9 Using the optical (Toslink) audio input Using the coaxial audio input 1. Connect the power supply to the wall socket and insert the 1. Connect the power supply to the wall socket and insert the cable into the micro-usB socket on TV streamer 2 cable into the micro-usB socket on TV streamer 2 2.

  • Page 10: Pairing To Your Hearing Instruments

    TV streamer 2 it is possible to pair up to three streaming devices - e.g. two TV streamers and one resound unite Mini Microphone (optional Pairing the TV Streamer 2 in channel 2 accessory) - with a given pair of hearing instruments.

  • Page 11: Start And Stop Streaming

    2. if you have a resound unite remote Control (optional), simply press the streaming button on this remote Control.
  • Page 12 You streaming button may also press the home button to return to your default settings. if you are using the telephone with resound unite Phone Clip+ or PhoneNow , streaming from the TV streamer 2 will be tempo- Connected to TV rarily disrupted.

  • Page 13: Controls

    TV streamer 2 will store the latest set volume level. use the resound unite remote Control 2 (optional) to adjust both the streaming volume level and the hearing instrument mi- crophone volume level in the hearing instrument*.

  • Page 14: Adjustable Delay Mode

    Adjustable delay mode speakers or alignment between the streamed audio and the TV picture has been reached, press and hold the paring but- in rare cases there may be a misalignment between the audio ton for 3 seconds. Now the TV streamer 2 will resume normal streamed to the hearing instruments and the sound coming from operation, indicated by the green light indicator being con- the TV speakers (echo) or even a misalignment between the...
  • Page 15 TV streamer 2 only with the power supply unit that has been supplied together with the product. The use of any other use only original resound accessories. types may damage or destroy the product and could be danger- do not make any changes or modifications to the TV streamer 2.

  • Page 16: Technical Specifications

    Technical specifications facturing or design defects fails to function properly under normal use during life of this warranty will be replaced or repaired at no Operating range: up to 7 meters charge for parts or labour when returned to the point of purchase. Power supply: external wall adapter if it is determined that repair is not feasible, the entire unit may be...

  • Page 17: Troubleshooting Guide

    TROUBLESHOOTING GUIDE SymPTom CAUSE PoSSIbLE rEmEDy The streaming button on the The TV streamer 2 and hear- Carry out pairing process Remote Control is pressed ing instruments have not been but with no effect at all paired The remote Control and ensure that remote Control and hearing instruments are hearing instruments are not within wireless range and activate streaming again...
  • Page 18 SymPTom CAUSE PoSSIbLE rEmEDy The streaming button on the The TV streamer 2 and ensure that TV streamer 2 and hearing instruments are hearing instruments are not within wireless range and activate streaming again Remote Control is pressed but no streamed audio signal within wireless range is found when searched for (indicated by an ’X’...
  • Page 19 SymPTom CAUSE PoSSIbLE rEmEDy The audio input level from Adjust the volume using the ”+” and ”-” keys on the TV The volume level from the TV Streamer 2 is very low the TV is too low streamer 2 until the sound is sufficiently loud The sound from the The TV streamer 2 and Move a little closer to the TV streamer 2...
  • Page 20 SymPTom CAUSE PoSSIbLE rEmEDy Your TV is not able to syn- if possible, try using another audio output from your TV. The sound from the TV Streamer 2 is not synchro- chronize the sound from Alternatively, follow the instructions in the “Adjustable delay nized with the sound from the the selected audio outputs mode”...
  • Page 21 Notes: Notes:...
  • Page 22 WARNING points out a situation that could lead to seri- ous injuries, CAUTION indicates a situation that could lead to minor and moderate injuries Advice and tips on how to handle your resound unite accessory better. equipment includes rF transmitter Please ask your local hearing care professional con-...
  • Page 23 Worldwide Headquarters Australia resound A/s gN resound Pty. Ltd. Lautrupbjerg 7 unit r1 regents Park estate dK-2750 Ballerup, denmark 391 Park road Tel.: +45 45 75 11 11 regents Park NsW 2143 Fax: +45 45 75 11 19 Tel.: (free) 1800 658 955 www.resound.com...
