Wybron Nexera LX User Manual
  1. Manuals
  2. Brands
  3. Wybron Manuals
  4. Lighting Equipment
  5. Nexera LX
  6. User manual

Wybron Nexera LX User Manual

Luminaire series
Hide thumbs
Table of Contents
  • Table of Contents
  • Declaration of Conformity
  • Safety Notice
  • Introduction
  • Quick Start
  • Nexera LX Fixture Specifications
    • Model 2560LX: Wash - Tungsten
    • Model 2570LX: Profile - Tungsten
    • Model 2580LX: Wash - CDM
    • Model 2600LX: Profile - CDM
    • Model 2640LX: 19º-26º Profile - Tungsten
    • Model 2650LX: 19º-26º Profile - CDM
  • Fixture Setup and Configuration
    • Installing the Lamp
    • Lamp Optimization
    • Mounting and Adjusting the Fixture
    • Attaching Accessories to the Front Accessory Holder
    • Connecting AC Power
    • Adjusting Field Angle
    • The Nexera LX System
    • Head-Feet Restrictions
    • Head-Feet Example
  • DMX Setup and Operation
    • Controls and Indicators
    • Menu Tree and Navigation
    • Display Messages
  • Service
    • Lamp Replacement
    • Cleaning the Reflector
    • Cleaning the Color Module
    • Cleaning the Lenses
    • Replacing Fuses
    • Error Messages/Troubleshooting
  • Appendix 1 - Color Table
  • Warranty Information
