Chapter 4 Wireless LAN Option
6. Press the Save button followed by the Reboot button to restart your
Compex NetPassage 16A. Once restarts, this Compex NetPassage 16A
will be operating in Client Mode.
If the Access Point that this Compex NetPassage 16A is accessing to has
implemented WEP private encryption, go to Section 4.4.4 titled Defining
WEP Private Encryption.
4.4.3

Implementing Wireless Pseudo VLAN

Compex NetPassage 16A Wireless LAN Option supports two types of
Wireless Pseudo VLAN, Per Node and Per Group. To understand Wireless
Pseudo VLAN and its application, please go to Section 4.3 titled Wireless
Pseudo VLAN.
To implement Per Node Wireless Pseudo VLAN:
NOTE
Wireless Pseudo VLAN can only be implemented when Compex
NetPassage 16A is operating in AP Mode.
1. Click on the WLAN Setup from the Command Menu and the Wireless
LAN operating mode setup window will be displayed, as shown in Figure
4.4a.
2. Press the Apply button and the access point configuration window will be
displayed, as shown in Figure 4.4b.
3. Expand the Pseudo VLAN drop down menu and select Per Node.
4. Press the Apply button and Compex NetPassage 16A shall reboot.
Once Compex NetPassage 16A restarts, Per Node Wireless Pseudo VLAN is
implemented. If you wish to implement WEP private encryption in
conjunction with Per Node Wireless Pseudo VLAN, please go to Section
4.4.4 titled Defining WEP Private Encryption.
82
This field is the Fragmentation Threshold. Packet
Frag
larger than Fragmentation Threshold will be broken
Threshold
into pieces for transmission. Do not modify the
default value if you are not sure what to do.
