Chapter 3 Configuring Compex NetPassage 16A
3.4

Static Address Translation (SAT)

If you are a notebook user, it is probably very often that you connect to the Internet at
your home to retrieve emails or surf the Internet. Static Address Translation function
that allows your notebook computer to connect to the Internet even if it is NOT
configured with the same subnet as Compex NetPassage 16A's.
For example, if Compex NetPassage 16A is configured with a Class C IP of
192.168.168.1 and your notebook is configured with Class C IP of 203.120.12.47, you
may access to the broadband Internet via Compex NetPassage 16A without the need of
reconfiguring the TCP/IP of your notebook. By default, this feature is disabled.
NOTE
If you are unsure whether to activate the SAT functionality, please disable
this function.
We at Compex always provide updated firmware on our website at
www.compex.com.sg. Constantly check to see if you have the updated
firmware.
3.4.1

Enable/disable Static Address Translation

1. Click on Static Address Translation option from the Command Menu
and the following window shall be displayed.
2. Press the Enable or Disable radio button to enable/disable this feature.
3. Press the Apply button for the changes to be affective.
4. Save the configuration.
50
Figure 3.4a Static Address Translation
