Carson Reflex Wheel Pro2 Instruction Manual page 25

Declaration of conformity
Dickie-TAMIYA GmbH & Co. KG hereby declares
that this model with radio, battery and charger is
in accordance with the basic requirements of the
following European directives:
98/37EG and 89/336/EWG and other relevant
regulations of guideline 1999/5/EG (R&TTE).
The original declaration of conformity can be
obtained from the following address in Germany:
Dickie-Tamiya GmbH & Co. KG • Werkstraße 1 •
D-90765 Fürth • Germany
Tel. +49 - (0)911 - 9765-03
Before using your radio control system carefully read this instructions!
Contents
Preface ..................................................................................24
Included Items ...................................................................26
Features of the 2.4 GHz Remote Control .................28
Advantages of the 2.4 GHz Technology ...................28
Worth Noting ......................................................................28
Safety Instructions ...........................................................29
Operating Procedure .......................................................30
Version Reflex Wheel Pro2 +
Reflex Wheel Pro2 LCD :
BEC-System/Connections to Receiver .......................30
Version Reflex Wheel Pro + Reflex Wheel Pro LCD:
Connections to Receiver ................................................ 31
Equipment for Combustion Engine ...........................32
Version Reflex Wheel Pro LCD +
Reflex Wheel Pro2 LCD:
External View of Transmitter ........................................33
CARSON Reflex Wheel Pro 50 050 0034 + 35 + 36 + 37
The meaning of the symbol
on the product, packaging
or instructions: Electronic
devices are valuable products
and should not be disposed
of with the household waste
when they reach the end of
their running time! Help us
to protect the environment
and respect our resources
by handing this appliance over at the relevant
recycling points.
We wish you good luck and a lot
of fun using your CARSON digital
proportional radio control system.
Throttle Rate Adjuster .....................................................33
Functions .............................................................................34
Transmitter Handling ......................................................35
Functions/Settings ...........................................................36
Version Reflex Wheel Pro + Reflex Wheel Pro2:
External View of Transmitter ........................................38
Throttle Rate Adjuster .....................................................38
Functions .............................................................................38
Transmitter Handling ......................................................40
Adjustment Fail Safe ........................................................ 41
Connection from Transmitter to Receiver ............... 41
Specifications .....................................................................42
Battery Safety Guidelines ..............................................42
Optional Accessories .......................................................43
