Summary of Contents for DMT Presenter Control
- Page 1 PRESENTER CONTROL ORDERCODE 100801...
- Page 2 For more information: iwant@dutchmediatools.info You can get some of the best quality, best priced products on the market from DMT. So next time, turn to DMT for more great lighting equipment. Always get the best -- with DMT ! Thank you!
-
Page 3: Table Of Contents
DMT Presenter Control Product Guide ™ Warning..…...................…………………………………………....Safety-instructions…………………………………………………………………………………………...... Operating Determinations…………………………………………………………………………………....Description..…................……….…………………………………....Features…….……………………………………………………………………………………….……...…....Overview………………………………………………………………………………………………………....Backside………………………………………………………………………………………………………....Installation................…...…………………………………….…...... Set up examples..............................Programming the device............................Controlling a projector with the PC using the remote terminal............... Controlling a projector with the PC using IR....................... Controlling an electric projection screen with the PC.................. -
Page 4: Warning
Your shipment includes: • DMT Presenter Control • User manual • 2 stereo audio cables 3,5mm jack – 1,4m – 3,5mm jack. -
Page 5: Safety-Instructions
If your DMT device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your DMT dealer for service. -
Page 6: Operating Determinations
Repairs, servicing and electric connection must be carried out by a qualified technician. WARRANTY: Till one year after date of purchase. OPERATING DETERMINATIONS If this device is operated in any other way, than the one described in this manual, the product may suffer damages and the warranty becomes void. -
Page 7: Features
Description of the device Features The Presenter Control is used for switching one of six program sources to a beamer or large screen and at the same time enabling remote control and/ or automated control of several functions. The presenter control is easy to operate. -
Page 8: Overview
Overview Remote Fig. 2 1) Computer. Pressing this button enables you to select the computer input. The LED will light if the computer input is selected. 2) DVD. Pressing this button enables you to select the DVD input. The LED will light if the DVD input is selected. 3) Aux 1. -
Page 9: Backside
Lights up if the Amp socket is active. 22) Light intensity indicator. The Presenter Control can send a control voltage (DC 0 – 10V) to an external dimmer. The intensity of the LED is linear with the DC voltage at the light output. - Page 10 Connect with the VGA in terminal of a projector. This output will contain the VGA program signal. 47) Projector RS232 terminal. Connect with the RS232 terminal of a projector. 48) Computer serial port. Connect with the RS232 port of your PC/ laptop to program the Presenter Control.
-
Page 11: Installation
1. Connect the Computer serial port (48) on the rear panel of the Presenter Control with the corresponding serial port of your PC/ Laptop using the supplied programming/ communication cable. 2. Connect the Control Panel Port (38) of the Presenter Control with the 9-pin port of the Control Panel using the supplied programming/ communication cable. -
Page 12: Controlling An Electric Projection Screen With The Pc
Controlling an electric Projection screen with the Presenter Control Fig. 8 Light control with the Presenter Control Fig. 9 Switch detection with the Presenter Control Fig. 10 Attention: 1. Switches have to be NC types. They must be closed when the door is closed. -
Page 13: Controlling Audio Equipment
Connecting audio equipment with the Presenter Control Fig. 11 Connecting video equipment Fig. 12 Connecting VGA equipment Fig. 13... -
Page 14: Mic Input And Audio Input
Mic input and audio output Fig. 14 Infrared transmission Connect the supplied IR LED to the terminal. Be sure to check the polarity of the LED. (white = +, black = -). Attach the LED to the receive window on the device to be controlled. Fig. -
Page 15: Software Installation
Running the setup program. Run the setup wizard program. The computer will start searching for the Presenter Control and the window shown in figure 5 will appear. Fig. 16 If the computer fails to find the Presenter Control, the window shown in Figure 6 will appear. -
Page 16: Curriculum Schedule
Fig. 18 Curriculum schedule The first tab is called Curriculum Schedule. Use this tab to automate your Presenter Control. You can program the Presenter Control to start up and shut down (according the sequence referred to on page 6). You can program up to 10 events each day. -
Page 17: Serial Port Control
If your projector is not in the list, you have to setup the control protocol yourself, using the projectors information. Presenter control will support Projectors which are controlled by either serial port or IR-remote control. Please refer to your projectors operating manual or consult your dealer for the right control code. - Page 18 Example 1 Projector Code: Power on 02H 00H Power off 02H 01H Input select RGB 02H 03H Input select DVI (analog) 02H 03H Input select DVI (digital) 02H 03H 1AH 22H Input select video 02H 03H Input select S-video 02H 03H Input select vieuwer 02H 03H Picture mute on...
-
Page 19: Ir Remote Control
Example 2 Power-on command of the projector is POWR___1 (Enter) (_ signifies space) Then in the command field should contain: \50\4f\57\52\20\20\20\31\0d (upper/lower case is insensitive). Also see the ACII table in appendix 3. Infrared remote control If it is impossible to obtain the Control Code of a projector, but the projector can be controlled by infrared control, please select the “Infrared Remote Control”... - Page 20 host’s control panel. Press the corresponding software button (for the infrared function to study), The setup program will start a window for the button you pressed. See figure 23. Fig.23 Now, press the corresponding button on the projector’s remote control. After successful sampling of the infrared code, a pop up window shall appear asking you to confirm.
-
Page 21: Dvd Ir Remote Control
DVD IR remote control It is possible to control a DVD player with your Presenter Control by using it’s infra red remote control. Just like with a projector as described in the former chapter. 1. Connect the IR LED to the IR LED terminal (37) as shown in figure 15 on page 12. -
Page 22: Sending The Program To The Host
Now the data will be send to the host. The transmission speed shall be shown in the transmission process. When programming is completed successfully, the Presenter control will restart automatically. A pop-up window as shown in Figure 27 will appear. Confirm and the setup program will be closed. -
Page 23: Product Specifications
Interference on projection screen. Possible causes: The power supplies for the projector and other equipment don’t share common ground. Product specification Power supply: AC 90-230V - 50-60Hz Signal inputs: Video: (RCA) 3 lines RGB signal: 3 lines Audio: 6 stereo lines (3,5 mm jack) 1 mic (6,35 mm jack) Signal outputs: Video: (RCA) 2 lines... -
Page 24: Appendix 1: Pin Definition Of Programming Cable And Infrared Learning Cable
Appendix 1: Pin definition of programming cable, Infrared learning cable and projector remote cable. Programming cable. Fig. 1 Infrared learning cable. Fig. 2 Projector remote cable. This cable depends on the remote connector of your projector. This cable has to be bought separately or custom made. -
Page 25: Appendix 2: Block Diagram
Appendix 2: Block diagram of the Multimedia centralized control system. -
Page 26: Appendix 3: Ascii Table
Appendix 3 ASCI-table... - Page 27 2008 DMT.
