• Proper ventilation is important. Don’t block ventilation openings. Never operate this projector in an enclosed area. Do not place the projector on a tablecloth or other soft covering that may block the vents. With ceiling installations, use approved mounting hardware. Do not put the projector near heaters, air cleaners, transformers or other electrical devices.
Remote Control and do not point the laser light into anyone’s eyes. This remote control is equipped with a Class IIIA laser that emits radiation. NOTE: Do not leave the remote control close to the cooling fan outlet of the projector. Digital Projector User’s Guide...
Page 4
Declaration of Conformity We declare under our sole responsibility that the DLP Zoom Digital Projector conforms to the following directives and norms: Directive 89/336/EEC, Amended by 93/68/EEC EMI: EN 55022 (1992) Class B EMC: EN 50082-1 (1992)
Computer and Video Cables ...8 Others ...8 Product Profile ... 9 Front View...9 Rear View...9 Bottom Panel ...9 LED Indicator & Control Pad on Projector ...10 LED Indicators Message ...10 Control Pad Function ...10 Remote Control Instruction...11 Installation Steps ... 13 Getting Started ...13 Connecting the Projector...13...
Page 6
Digital Projector User’s Guide Language Menu ...24 Utilities Menu...25 Status Menu ...26 Reference ... 27 Positioning the Projector ...27 Remote Control Transmission Range ...29 Product Specification ...30 Timing Charts...31 Troubleshooting ...32 Power Indicator ...32 Remote Control ...32 Sound ...32 Image Source ...33...
In only minutes you can have your DLP Digital Projector ready to go. Just simply connect the projector to an image source, Computer, DVD, VCR, or HDTV.
Digital Projector User’s Guide Accessories Overview Power Cord There are four different power cords for options, US type, UK type, Euro type and China type. The appropriate Power Cord is included according to your geographical location & safety requirement. If the standard kit does not satisfy your needs, then please contact your dealer for further service.
The security lock corresponds to Kensington’s MicroSaver Security System. If you have any comment, contact : Kensington, 2853 Campus Drive, San Mateo, CA94403, U.S.A. Tel: 800-535-4242, http: www.kensington.com/ Digital Projector I/O Connectors AC IN Socket User’s Guide Control Pad...
Digital Projector User’s Guide LED Indicator & Control Pad on Projector Source Button (+) Same as Source button on the remote control Auto (-) Same as Auto button on the remote control Lamp Ready LED Indicator LED Indicators Message...
Do not leave the remote control close to the cooling fan outlet of the projector. For the information of remote control transmission range, please refer page 29. Digital Projector Laser aperture (pointer/beam) Power LED Laser pointer ON Mouse cursor...
Page 12
Digital Projector User’s Guide The following buttons are located on the projector Control Pad or on the Remote Control Power Button Switch power on or off. Use the Power button to begin the warm-up period. The power light blinks green during warm-up and stays green when the projector is ready to use.
Connecting the Projector 1. Connect the power cable 2. When you connect the power cable to the projector, the Power LED & Lamp Ready LED on the control pad will illuminate, wait until LED stop flashing before turning on the projector.
Digital Projector User’s Guide Connecting Input and Output Devices The cables are color coded to assist you in making the connections. You can connect more than one image source at a time. The input source will be detected automatically when enable the “Auto Source” function is enabled in the Status Menu of the OSD MENU.
The Source button on the control panel or remote control can be used to select a source. NOTE: • Always turn off the image source (computer or video) and projector before connecting or disconnecting cables. • When using a computer as the input device, set the resolution of your computer’s graphic card to 1024x768 for the optimal projected image.
Digital Projector User’s Guide Adjustment Adjusting Projector Angle Place the projector on a flat surface and position in the centre horizontally for best viewing. Height Adjustment Button Foot Adjusters Adjusting the Zoom and Focus Zoom Ring Focus Ring Adjust the projector angle using the Height Adjustment Buttons.
□ Make any necessary image adjustments by using the on-screen menus. (Refer page OSD Menu section for the details) Digital Projector To adjust image vertically and make a square image. Adjust the keystone function by pressing the keystone button on the remote control or through OSD menus.
Restart To restart the unit shortly after powering off, user must wait for 1 minute for the lamp to cool down. The lamp ready LED will stop flashing when the projector is ready to power up. CAUTION: The unit may remain HOT for up to 45 minutes upon power off. User should be careful before handling the unit to prevent any burn or injury.
Digital Projector Display Logo The projection image will appear in full brightness within 10-15 seconds and the “LUXEON” logo will appear on the screen. No Input Signal “No Input Signal” will show on the screen when there is no active signal detected within 16 seconds.
Digital Projector User’s Guide Ezkey OSD By repeatedly pressing EZKEY the following menu can be scrolled though. The user may adjust it to the desired level through keypads of Auto (-) and Source (+). Remote Control Buttons OSD Following menus/functions can be accessed through corresponding buttons on the remote control.
Use ↵ button to reset to default value. Reset In PC mode to reset contrast, brightness to default value. In Video mode to reset contrast, brightness to default value. Digital Projector ) for sub-menu or for adjustment selection. User’s Guide Video Mode...
Digital Projector User’s Guide Setup Menu PC Mode HDTV Mode Use arrow keys Left / Right ( / ) to adjust the sampling clock to Frequency eliminate flicker. Adjustment range: from low-high (0-100) by 32 steps. (Default value: auto detected) Use arrow keys Left / Right ( / ) to adjust the sampling number.
Use arrow keys Left / Right ( / ) to adjust video saturation. Adjustment range: from color off to color level (0 – 100) by 50 steps. (Default value:50) Digital Projector (0-100) by 32 steps. Video Mode User’s Guide...
Digital Projector User’s Guide Color Tint Use arrow keys Left / Right ( / ) to adjust the video tint/hue. Adjustment range: from red to green (0-100) by 100 steps. (Default value: 50) OSD Translucent Use arrow keys Left / Right ( / ) to select OSD background translucent or not.
In PC mode, to reset PIP size, PIP position, PIP input, blank color, OSD position, and OSD display time at default value. In Video/HDTV mode, to reset blank color, OSD position, OSD display time at default value. Digital Projector Video Mode User’s Guide...
Digital Projector User’s Guide Status Menu Auto Source To turn on or off the automatic function to detect one or more active input source. Auto Power Off To turn on or off the function for automatically lamp off when there is no active signal.
Positioning the Projector To adjust the size of the projected image, refer to figures 1 below and table 1 on the next page for Projection Distances to increase/decrease the distance between the projector and the projection screen. Figure 1 : Projection Distance vs. Image Size ...
For best operation, kindly refer to the following illustration of the Remote Control and IR transceiver transmission range and distance. Digital Projector The projector is equipped with an IR Transceiver located at the front cover of the unit for the receipt of remote control transmission.
Digital Projector User’s Guide Product Specification Display Type Panel Native Resolution Data Compatibility Zoom Ratio Color Reproduction Aspect Ratio Digital Keystone Correction Horizontal Frequency Vertical Scan Rate Projection / Installation Mode Lamp Type Projection Distance Projection Image Size (diagonal)
Timing Charts The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. Table 2: ANALOG Computer Timings (Resolution and Refresh Rate【fV】) Resolution FH(kHz) 640 x 350 640 x 480 640 x 480...
Poor sound quality No audio-out port on the image source Condition • Lamp is off but power cord is connected to the projector. • Projector is in standby mode. • Lamp is off and fan is running. • Projector is cooling down.
Some text or fonts are not as sharp on the projector as the are on the computer. • Be sure that the projector is at a 90° angle to the screen. Image isn’t centred on the screen. • Reposition the image.
To achieve a square image, raise or lower the front legs or prop up the back of the projector, or adjust keystone function thru remote, or use the EZ Key on the top cover of the main set.
Doing so many cause electric shock. To replace the lamp module Digital Projector 1. Turn off the projector and let the unit cool down for at least 45 minutes. 2. Unplug the power cord from projector. 3. Turn the projector upside down. Loosen the screw with a phillips screwdriver.
Digital Projector User’s Guide NOTE: 1. The lamp contains a trace amount of mercury. Some governments required special disposal of lamps containing mercury. Dispose of lamps in accordance with the law and any applicable local regulations. 2. Do not loosen or remove any screw other than lamp unit or its cover.
Cleaning the Projector Never attempt to clean the interior of the projector. Clean the exterior of the projector only. Make sure the projector is powered-off, cooled down and power cord has been disconnected prior.
Digital Projector User’s Guide Customer Support For most of your questions, it is suggested that you contact your dealer for assistance or ask your dealer to refer you to a service centre To facilitate after-sales service process, it is suggested that you fill in following information when you purchase this product.
