Summary of Contents for Matrix 7”

  • Page 1 7” TFT LCD TeLevision o W n e R ’ s M A n U A L...
  • Page 3: Table Of Contents

    CONTENTS CHAPTER 1: IMPORTANT INFORMATION & SAFETY PRECAUTIONS PAGES 1.1 Important Information 1.2 Important Safety Precautions CHAPTER 2: GETTING STARTED 2.1 Package Contents 2.2 Connection CHAPTER 3: DISPLAY AND CONTROL OVERVIEW 3.1 Controls CHAPTER 4: PROGRAMMING THE TELEVISION & ADJUSTING THE SETTINGS 4.1 Programming the Television 4.2 Picture Settings 4.3...
  • Page 4: Chapter 1: Important Information & Safety Precautions

    CHAPTER 1 : IMPORTANT INFORMATION & SAFETY PRECAUTIONS Thank you for purchasing the Matrix Liquid Crystal Television. To ensure safety and many years of trouble free operation of your product, please read the important safety precautions carefully before using this product.
  • Page 5: Important Safety Precautions

    • Servicing - DO NOT attempt to service the product yourself. Removing covers can expose you to high voltage and other dangerous conditions. Contact Matrix customer service to perform service on this product. • Repair - If any of the following conditions occur, unplug the power cord from the AC outlet, and request a qualified service person to perform repairs a.
  • Page 6 To prevent fire - Never place any type of candle or naked flames on the top or near the TV set. • To prevent fire or shock hazard - Do not expose this product to dripping or splashing. No objects filled with • liquids, such as vases, should be placed on the product. MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 7: Chapter 2: Getting Started

    RESET ENTER MATRIX F ITN E S S S YS TE M S CORP. 1 6 1 0 LA N DMA RK DRI VE COT TA GE GROVE W I 5 3 52 7 U S A w w w. m a t r i x fi t n e s s . c o m TOLL F R E E 8 6 6 .6 9 3 .48 6 3...
  • Page 8: Chapter 3: Display And Control Overview

    Execute a command Switch the television power ON or OFF VOLUME CHANNEL Select volume Select channel RESET LAST RESET LAST Previous channel jump button Clears numeric keypad selections CHANNEL SELECTION NUMBER PAD Set the television channel MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 9: Chapter 4: Programming The Television & Adjusting The Settings

    4.1 PROGRAMMING THE TELEVISION In order for your 7” LCD TV to broadcast the channels provided by your cable provider, you will need to program the TV to receive the channels. Ç Press and hold the volume button and the channel button until the menu screen STEP 1: appears. ™ CHANNEL VOLUME LAST RESET ENTER • Each menu heading is described below: Picture Settings Aspect Ratio Cable Broadcasting System Channel Setup Sleep Timer Ç * To cycle through the options that are available under a selected menu heading, use the channel buttons. To adjust a particular option, highlight the option and adjust the value using the Ç volume buttons. Press the “ENTER” button to advance to the next menu heading. MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 10: Picture Settings

    STEP 2: Ç Cycle through to the field that you want to modify using the channel buttons and STEP 3: Ç when that field is highlighted, use the volume buttons to adjust the setting. * Your 7” TV broadcasts in both 16:9 and 4:3 aspect ratio. Full is the 16:9 setting and zoom is 4:3. 4.4 CABLE BROADCASTING SYSTEM Ç Press and hold the volume button and the channel button until the menu screen STEP 1: appears. Press the “ENTER” button to advance to the cable broadcasting system heading. STEP 2: Ç Cycle through to the field that you want to modify using the channel buttons and STEP 3: Ç when that field is highlighted use the volume buttons to adjust the setting. * This TV has a global tuner and will broadcast NTSC358, NTSC443, PALM, PALN, PAL60, PAL443 and SECAM COLOR SYSTEMS. MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 11: Channel Setup

    CHAPTER 4 : PROGRAMMING THE TELEVISION & ADJUSTING THE SETTINGS 4.5 CHANNEL SETUP (SEE 4.1) 4.6 SLEEP TIMER Ç Press and hold the volume button and the channel button until the menu screen STEP 1: appears. Press the “ENTER” button to advance to the sleep timer heading. STEP 2: Ç Adjust the timer using the volume buttons. STEP 3: (The timer length can be set between 0-240 minutes) MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 12: Cycles, Ellipticals, Ascent Trainer And Stepper

    MAIN BRACKET bracket to the TV. L10 x2 STEP 3 PLATE 2 Fasten the TV to the main bracket using the button head L09 x2 hex socket screw (Z05) as PLATE 1 L08 x2 shown BOTTOM MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 13 Z51 x4 using the chrome bolts (Z51) that held the console mast badge in place. Z04 x4 STEP 7 Assemble the TV back cover to the mounting bracket using the phillips head machine screw (Z04). FINAL ASSEMBLY MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 14: Required Fasteners & Assembly Tools

    6.2 7” TV T3x/T3xi TREADMILL INSTALLATION 7” TV STEP 1 Assemble the TV to the bracket Z05 x4 using the button head socket screw (Z05). Insert the end cap into the bracket as shown. BRACKET END CAP MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 15 (Z01) and flat washer (Z02). Z02 x4 Z01 x4 STEP 4 Assemble the TV back cover to the mounting bracket using the phillips head machine screw (Z04). FINAL ASSEMBLY MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 16: Required Fasteners & Assembly Tools

    7.2 7” TV T5x TREADMILL INSTALLATION STEP 1 Assemble the TV to the bracket using the button head socket 7” TV screw (Z05). Insert the end cap into the bracket as shown. Z05 x4 END CAP BRACKET MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 17 Z03 x4 button head socket screw (Z01) and Z01 x4 the flat washer (Z03). STEP 4 Assemble the back cover to the bracket using the phillips head machine screw (Z04). FINAL ASSEMBLY MATRIX FITNESS SYSTEMS ENTERTAINMENT...
  • Page 18 MAT Ri x F iT n e s s s y sT e M s Co R p. 16 10 La n d m a r k dr i v e C o t ta g e gr o ve wi 5 35 2 7 U S a w w w.
