- Page 1 S E R V I C E IPL, CTH220 Twin, 2007-10, 544 34 16-06 96061019002 CTH220 Twin Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar 544 34 16-06...
- Page 2 ILLUSTRATED PARTS LIST MFG. ID NO. 96061019002 CUSTOMER CATALOG NO. CTH220TWIN PRODUCT NO. 960 61 01-90 532 41 57-96 Rev. 9...
- Page 3 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 DECALS 27 MAX + _ 90N MAX + _ 150N PART PART DESCRIPTION DESCRIPTION 532 40 03-89 Decal Warning Symbols CE 532 14 08-37 Decal Saddle Brake Parking 532 40 28-32 Decal Hood 532 16 69-60...
- Page 4 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 SCHEMATIC 38 SCH05 AMMETER (OPTIONAL) BATTERY SOLENOID STARTER FUSE PTO (DISENGAGED) WHITE BLACK WHITE BLACK BLACK FBI BUZZER SWITCH CLUTCH / BRAKE ELECTRIC CLUTCH (PEDAL UP) DIODE BLACK INTERLOCK BLACK BLACK...
- Page 5 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 ELECTRICAL 32 With Ammeter Option D .C Without Ammeter Option With Service Minder Option Without Service Minder Option...
- Page 6 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 ELECTRICAL 32 PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 61-38 Switch Interlock 532 18 37-59 Harness Asm Light w/4152J 532 00 41-52 Bulb Light #1156 532 10 84-23...
- Page 7 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 CHASSIS AND ENCLOSURES 39 26 25 chassis-CRD_TEX GT HUSQ_1...
-
Page 8: Chassis And Enclosures
TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 CHASSIS AND ENCLOSURES 39 PART PART DESCRIPTION DESCRIPTION 872 14 06-20 Bolt Rdhd Sqnk 3/8-16 x 2-1/2 Gr. 5 532 17 46-20 Chassis 532 18 03-84 Drawbar 819 13 20-16 Washer 13/32 x 1-1/4 x 16 Ga. - Page 9 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 DRIVE 40 169 171...
- Page 10 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 DRIVE 40 PART PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle Hydro Gear 321-0510 532 17 00-15 Control Asm Bypass Hydro 532 19 27-06 Rod, Shift Fender Adjust Lt 532 12 47-88 Spring, Retainer 1”...
- Page 11 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 ENGINE 24 OPTIONAL EQUIPMENT Spark Arrester engine-ko.twin_20...
- Page 12 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 ENGINE 24 PART DESCRIPTION 532 18 29-37 Control Throt/Ch Flag 532 19 16-11 Screw Hex 10 x 3/4 - - - - - - - - Engine Kohler SV715-0010 532 14 97-23 Muffler 532 14 66-99...
- Page 13 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 STEERING ASSEMBLY 41 PREM 2 HUSQ SR steering-CRD_special_2_w118...
-
Page 14: Steering Assembly
TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 STEERING ASSEMBLY 41 PART DESCRIPTION 532 41 64-80 Steering Wheel Husq SR 532 18 47-06 Front Axle Assembly 532 16 98-40 Spindle Assembly, LH 532 16 98-39 Spindle Assembly, RH 532 12 49-31 Bearing, Race, Thrust, Hardened 532 12 17-48... -
Page 15: Mower Deck
TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 MOWER DECK 44 107cm_deck-elect.(CRD)_2... - Page 16 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 MOWER DECK 44 PART PART DESCRIPTION DESCRIPTION 872 11 06-22 Bolt RhHd 3/8-16 unc x 2-3/4 Gr. 5 532 16 91-60 Housing Asm. Mower 873 68 06-00 Nut Crownlock 3/8-16 unc 872 14 05-06 Bolt Rdhd Sqnk 5/16-18 unc x 3/4 873 90 06-00...
- Page 17 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 MOWER LIFT 45 17 18 lift-rh.1piece_9_r1...
- Page 18 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 MOWER LIFT 45 PART DESCRIPTION 532 19 84-17 Wire Asm Inner Spring w/Plunger 532 19 80-70 Shaft Asm. Lift 532 18 88-22 Pin Groove 812 00 00-02 E Ring #5133-62 819 21 16-21 Washer 21/32 x 1 x 21 Ga.
-
Page 19: Seat Assembly
TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 SEAT ASSEMBLY 42 seat_lt.knob_7(CRD) PART PART DESCRIPTION DESCRIPTION 532 18 87-15 Seat 532 12 12-48 Bushing Snap Blk Nyl 50 Id 532 14 05-51 Bracket Pnt Pivot Seat (Blk) 872 05 04-12 Bolt Rdhd Sht Nk 1/4-20 x 1-1/2 532 12 12-49... - Page 20 TRACTOR - - MODEL NO. CTH220TWIN (96061019002), PRODUCT NO. 960 61 01-90 BAGGER 46 PART PART DESCRIPTION DESCRIPTION 532 16 52-49 Tube Handle Bagger CRD 532 16 57-87 Grip Handle 532 12 39-76 Nut Lock 1/4 Lge Flg Gr. 5 Zinc 532 16 94-84 Retainer Clip 532 16 99-16...
- Page 21 10.15.09 CL...
Need help?
Do you have a question about the CTH220 Twin and is the answer not in the manual?
Questions and answers
je ne peux plus régler la hauteur de coupe
The cutting height on a Husqvarna CTH220 Twin can be adjusted using the height adjustment mechanism. The relevant components include:
- Rod Adj Lift (Part 27): This rod helps in adjusting the lift of the mower deck.
- Knob Inf 3/8-16 unc Blk w/sym (Part 29): Likely used to control the height setting.
- Trunnion Infin Height (Part 30): Helps in fine-tuning the cutting height.
- Pointer Height Indicator (Part 36) and Scale Ind Height Blk (Part 41): These components indicate the selected cutting height.
To adjust the cutting height:
1. Locate the height adjustment knob or lever.
2. Turn or move it to the desired height setting.
3. Check the pointer height indicator to confirm the setting.
4. Ensure the mower deck is properly secured in the new position.
This answer is automatically generated
