Summary of Contents for Husqvarna CTH2036T

  • Page 1 CTH2036T Operator's Manual...
  • Page 2: Safety Rules

    Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: In order to prevent ac- ci den tal starting when setting up, trans port ing, ad just ing or making repairs, al ways dis con nect spark plug...
  • Page 3: General Service

    Safe Operation Practices for Ride-On Mowers III. CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the ma chine and the mowing activity. Never assume that children will remain where you last saw them. •...
  • Page 4: Table Of Contents

    Gasoline Capacity 2.5 Gallons (9,5 L) and type: Unleaded Regular Oil Type (API-SG-SL): SAE 10W30 (above 32°F/0°C) SAE 5W-30 (below 32°F/0°C) Oil Capacity: w/ Filter: Spark Plug: Champion RC12YC (Gap: .030"/ 7,6 mm) Ground Speed mph/kph: Forward: Reverse: Charging System: 15 AMPS @ 3600 RPM Battery: AMP/HR:...
  • Page 5: Unassembled Parts

    UNASSEMBLED PARTS Steering Wheel Steering (1) Large Flat Washer Wheel Insert Steering Wheel Adapter (1) Locknut Seat (1) Washer (1) Knob (1) Seat (1) Oil Drain Tube For Future Use Slope Sheet Keys (2) Keys...
  • Page 6: Assembly

    Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier.
  • Page 7 SEAT SEAT PAN FLAT WASHER ADJUSTMENT KNOB Fig. 3 • Pivot seat and pan forward and assemble adjustment knob and flat washer loosely. Do not tighten. Lower seat into operating position and sit on seat. • Slide seat until a comfortable position is reached which allows you to press clutch/brake pedal all the way down.
  • Page 8: Horizontal Adjustment

    CLEVIS PIN 3/8 X 11/16 CLEVIS PIN 3/8 X 2 SUPPORT BRACKET 13/32 FLAT WASHER RETAINER SPRING SUPPORT BRACKET Fig. 6 DISCHARGE CHUTE Fig. 7 TO ASSEMBLE BAGGER (See Figs. 8-10) • Unfold bag by pivoting front bagger tube all the way forward and pressing the bottom vinyl binding onto the tube.
  • Page 9 VERTICAL ADJUSTMENT • Slightly loosen the nuts securing the vertical adjustment brackets. Loosen only enough so the brackets keep their position, but allow them to be moved. • Move the brackets the amount up or down you wish the bag assembly to move. Retighten the nuts securely. •...
  • Page 10: Operation

    These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL REVERSE ENGINE ON ENGINE OFF OPERATION SYSTEM (ROS) OIL PRESSURE OVER TEMP FUEL LIGHT ATTACHMENT ATTACHMENT CLUTCH ENGAGED CLUTCH DISENGAGED LIGHTS ON FREE WHEEL (Automatic Models only)
  • Page 11: Know Your Tractor

    KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. CLUTCH/BRAKE PEDAL THROTTLE CONTROL...
  • Page 12: How To Use Your Tractor

    The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any adjustments or repairs. We rec om mend a wide vision safety mask over spectacles or stan dard safety glasses.
  • Page 13 TO ADJUST GAUGE WHEELS (See Fig. 15) Gauge wheels are properly adjusted when they are slightly off the ground when mower is at the desired cutting height in operating position. Gauge wheels then keep the deck in proper position to help prevent scalping in most terrain conditions.
  • Page 14: Before Starting The Engine

    IMPORTANT: THE MOTION CONTROL LEVER DOES NOT RETURN TO NEUTRAL (N) POSITION WHEN THE CLUTCH/ BRAKE PED AL IS DEPRESSED. • To restart movement, slowly release parking brake and clutch/brake pedal. • Slowly move motion control lever to slowest setting. •...
  • Page 15: Mowing Tips

    NOTE: Before starting, read the warm and cold starting procedures below. • Insert key into ignition and turn key clockwise to “START” position and release key as soon as engine starts. Do not run starter continuously for more than fifteen sec onds per minute. If the engine does not start after several attempts, push choke control in, wait a few minutes and try again.
  • Page 16 • If grass is extremely tall, it should be mowed twice to reduce load and possible fire hazard from dried clip pings. Make first cut relatively high; the second to the desired height. • Do not mow grass when it is wet. Wet grass will plug mower and leave undesirable clumps.
  • Page 17: Maintenance Schedule

    MAINTENANCE SCHEDULE Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check Mower Levelness Check V-Belts Check Engine Oil Level Change Engine Oil (with oil filter) Change Engine Oil (without oil filter) Clean Air Filter...
  • Page 18: Maintenance

    TRACTOR Always observe safety rules when per form ing any main te nance. BRAKE OPERATION If tractor requires more than five (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved surface, then brake must be checked and ad just ed. (See “TO CHECK BRAKE”...
  • Page 19: Blade Removal

    6 STAR PATTERN BLADE (See Fig. 26) The center of this blade has a 6 star pattern. The bolt at tach - ing this blade has Left Hand threads that loosens by turning ( ) clockwise and tight en by turning ( ) coun ter clock wise. BLADE FLAT WASHER...
  • Page 20 TO CHANGE ENGINE OIL (See Fig. 27) Determine temperature range expected before oil change. All oil must meet API service classification SG-SL. • Be sure tractor is on level surface. • Oil will drain more freely when warm. • Catch oil in a suitable container. •...
  • Page 21: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SE RI OUS IN JU RY, BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS: • Depress brake pedal fully and set parking brake. • Place motion control lever in neutral position. • Place attachment clutch in “DISENGAGED” position. •...
  • Page 22: Service And Adjustments

    SERVICE AND ADJUSTMENTS TO LEVEL MOWER HOUSING Adjust the mower while tractor is parked on level ground or driveway. Make sure tires are properly inflated (See “PROD UCT SPECIFICATIONS” section of this manual). If tires are over or underinflated, you will not properly adjust your mower.
  • Page 23 SERVICE AND ADJUSTMENTS BELT INSTALLATION - • Install new belt in reverse order of removal. See belt routing decal located on right mandrel cover. • Make sure belt is in all pulley grooves and in side all belt guides. • Install left and right mandrel covers and tighten se cure ly.
  • Page 24 SERVICE AND ADJUSTMENTS NOTE: If additional clearance is needed to get to ad just ment bolt, move mower deck height to the lowest position. After above adjustment is made, if the tractor still creeps forward or backward while motion control lever is in neutral position, follow these steps: •...
  • Page 25: To Remove Hood And Grill Assembly

    SERVICE AND ADJUSTMENTS TO ATTACH JUMPER CABLES - • Connect one end of the RED cable to the POSITIVE (+) terminal of each battery(A-B), taking care not to short against tractor chassis. • Connect one end of the BLACK ca ble to the NEGA TIVE (-) terminal (C) of fully charged battery.
  • Page 26: Storage

    Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. WARNING: Never store the trac tor with gas o line in the tank inside a building where fumes may reach an open flame or spark.
  • Page 27: Troubleshooting

    TROUBLESHOOTING POINTS PROBLEM CAUSE 1. Out of fuel. Will not start 2. Engine not “CHOKED” properly. 3. Engine flooded. 4. Bad spark plug. 5. Dirty air filter. 6. Dirty fuel filter. 7. Water in fuel. 8. Loose or damaged wiring. 9.
  • Page 28 TROUBLESHOOTING POINTS PROBLEM CAUSE 1. Faulty operator-safety presence control Engine continues system. to run when oper- ator leaves seat with attachment clutch engaged 1. Worn, bent or loose blade. Poor cut - uneven 2. Mower deck not level. 3. Buildup of grass, leaves, trash under mower. 4.
  • Page 30: Service Notes

    SERVICE NOTES...
  • Page 31 SERVICE NOTES...
  • Page 32 532 42 66-43 04.01.09 CL Printed in the U.S.A.
