Snelflight 2.4GHz RC System User Manual

2.4ghz rc system
Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for purchasing the Snelflight 2.4GHz RC system. Comprising the T4EU 5-channel
Transmitter and the R7F full-range receiver, the system is extremely easy to use and excellent value
for money. It is suitable for aeroplanes, many helicopters, and surface models. Binding is carried out
with a single push button, with no need for a special binding plug.
1)
Dual mode - Mode 2 transmitter may be easily changed to Mode 1
2)
Four proportional joystick channels plus one switched channel
3)
Elevon mixing switch
4)
Frequency Hopping Spread Spectrum (FHSS) technology
5)
Push-button binding
6)
High interference rejection
7)
60 frequency channels
8)
60dB adjacent channel suppression
Snelflight 2.4GHz RC System
Features
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2.4GHz RC System and is the answer not in the manual?

Questions and answers

Related Manuals for Snelflight 2.4GHz RC System

Summary of Contents for Snelflight 2.4GHz RC System

  • Page 1 Snelflight 2.4GHz RC System Thank you for purchasing the Snelflight 2.4GHz RC system. Comprising the T4EU 5-channel transmitter and the R7F full-range receiver, the system is extremely easy to use and excellent value for money. It is suitable for aeroplanes, many helicopters, and surface models. Binding is carried out with a single push button, with no need for a special binding plug.
  • Page 2 IMPORTANT SAFETY NOTICE • Do not operate radio controlled models at night or in wet weather. Water can permanently damage many of the components of the radio system, possibly causing loss of control. • Only fly at designated RC flying fields. Fly at safe distances away from people, buildings, electrical lines or other hazards.
  • Page 3 Aileron Control (CH1): When the aileron stick is moved to the right, the right aileron is raised and the left one lowered, and the aircraft rolls to the right. When the aileron stick is moved to the left, the ailerons move in the opposite directions and the aircraft rolls to the left.
  • Page 4 Nominal current drain 100mA 1000 yards air Power supply 8 x AA battery Weight Output power 10mW Antenna length Channel centres 1.5ms Snelflight Ltd, 48 Chalfont Way, Meadowfield, DH7 8XA, United Kingdom. Web: www.snelflight.co.uk Email: support@snelflight.co.uk V 2.0 Revised 09-03-2014...
