Snelflight MC-6 Manual

Ghost rc system
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Thank you for purchasing the Snelflight Ghost RC system. Comprising a specially commissioned
version of the MC6 6-channel transmitter and full-range receiver, the system is very easy to use and
excellent value for money. It is specifically designed for Naza-based multi-rotor aircraft, with a 3-
position switch on channel 5 and a rotary control on channel 6 for use with extra equipment such as a
camera gimbal. The joysticks are smooth and positive, and binding is extremely quick and easy.
1)
Six channels
2)
Four proportional joystick channels plus a 3-position switch pre-calibrated for the DJI Naza
3)
Self-centring throttle for barometric height control systems
4)
Rotary proportional control on channel 6
5)
Electronic trims
6)
Elevon and V-Tail mixing
7)
Frequency Hopping Spread Spectrum (FHSS) technology
8)
Quick binding and link-up
9)
Built-in antenna
Snelflight Ghost RC System

Features

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-6 and is the answer not in the manual?

Questions and answers

Related Manuals for Snelflight MC-6

Summary of Contents for Snelflight MC-6

  • Page 1 Snelflight Ghost RC System Thank you for purchasing the Snelflight Ghost RC system. Comprising a specially commissioned version of the MC6 6-channel transmitter and full-range receiver, the system is very easy to use and excellent value for money. It is specifically designed for Naza-based multi-rotor aircraft, with a 3- position switch on channel 5 and a rotary control on channel 6 for use with extra equipment such as a camera gimbal.
  • Page 2 IMPORTANT SAFETY NOTICE  Do not operate radio controlled models at night or in wet weather. Water can permanently damage many of the components of the radio system, possibly causing loss of control. Rain also inhibits 2.4GHz signal propagation.  Only fly at designated RC flying fields.
  • Page 3 Power switch: Slide up to turn on, down to turn off. Shown in the off position. Set-up switches: Note the positions shown, needed for Naza controllers as shipped. For other models channel reversing switches are provided, along with selections for V-Tail and Elevon mixing. Pitch/Roll joystick: The aircraft will tilt in the direction that this joystick is moved.
  • Page 4 Channel 5 Switch: 1.5 ± 0.3ms, forwards = short pulses Channel 6 Rotary: 1.5 ± 0.5ms, anticlockwise = short pulses Snelflight Ltd, Unit 11C Oakway Court, Meadowfield Industrial Estate, Durham, DH7 8XA, UK. V 1.0 Revised 31-05-2015 Web: www.snelflight.co.uk Email:...
