Summary of Contents for H.264 4 Channel
-
Page 2: Front Panel
H.264 Realtime DVR – QUICK USER GUIDE Use the designated HDD Please use the designated HDD. Otherwise, recording may be operated improperly. Maker HDD Capacity 80,160,250,320,500,750,1000GB each and Totally up to Western Digital 3TB is supported.(3pcs X HDDs) Seagate But, please combine same size HDDs (i.e 80GB x 80GB) USB2.0 for Memory Stick &... - Page 3 H.264 Realtime DVR – QUICK USER GUIDE (18) PAN / TILT (17) ZOOM - To control P/T/Z, press this button to - ZOOM P/T/Z camera in and out browse virtual key on screen. (19) AUDIO Selection (20) VOLUME UP & DOWN ( - Switches between audio channels - To increase or decrease the volume.
-
Page 4: Default Passwords
H.264 Realtime DVR – QUICK USER GUIDE DEFAULT PASSWORDS Front Panel A Password is required if you need to: enter the menus; search; down power; playback; stop recording or changing an IP setting. A prompt will be displayed asking for password. -
Page 5: Osd Description
H.264 Realtime DVR – QUICK USER GUIDE OSD DESCRIPTION PTZ icon Recording Standby This screen shows PTZ control of camera 2. The on screen arrows will allow control of this camera. The Status Bar shows HDD capacity, Network connection, Time, etc using by icons. - Page 6 H.264 Realtime DVR – QUICK USER GUIDE Mouse control Using the mouse allows the operator to enter the Menus to set up the DVR or enter the Search functions to play back and archive recorded data.. Right Clicking will bring up the following screen:...
- Page 7 H.264 Realtime DVR – QUICK USER GUIDE Global Within this section: Watermarking should be set to on, this allows the supplied software to verify the downloaded information to ensure it has not been tampered with or changed. Repeat recording can be set to continually overwrite or stop when the drives are full.
-
Page 8: Motion Sensitivity
H.264 Realtime DVR – QUICK USER GUIDE Alarm There are 16 Alarm inputs on the rear of the unit these can be used to initiate the Alarm record mode. The Alarm recording is set up in the same way as Normal Recording. -
Page 9: Program Update
H.264 Realtime DVR – QUICK USER GUIDE Duration The Duration mode allows the user to set the number of days that they require to record for. The resolution; whether cameras are active or not and whether audio is being recorded can each be set per channel. The user then sets the... -
Page 10: Searching Video Footage
H.264 Realtime DVR – QUICK USER GUIDE SEARCHING VIDEO FOOTAGE To access the search option, press the SEARCH button on the front panel or right click the mouse and select Search, (A password may have to be entered) after which the following screen will be displayed. -
Page 11: Archiving Evidence To Dvd/Cd Or Usb
H.264 Realtime DVR – QUICK USER GUIDE The minutes which have recorded data will be displayed as a coloured bar, click on the time required; the recorded data will be played back from this point. * Preview function Before actual viewing of recorded data from the calendar menu, it is possible to preview the selected time and date on the screen behind the search window. -
Page 12: Minimum Pc Specification
H.264 Realtime DVR – QUICK USER GUIDE Calculate Archive size Once the time and date and file format have been entered, it is necessary to confirm that the size of file created will not exceed the size of memory available on the disk or USB device. Move to Calculated Archive size and press SEL. - Page 13 H.264 Realtime DVR – QUICK USER GUIDE Appendix 1 INSTALLING WEB CLIENT ON WINDOW XP/2000 & VISTA SERVICE PACK 2. 1) Security Setup > Window XP / 2000 > Window Vista Tools-> Internet Options-> Security Tools-> Internet Options-> Security -> Select “Customer Level”...
- Page 14 H.264 Realtime DVR – QUICK USER GUIDE Select “ Automatic Prompting for Select “ Download unsigned Active X controls”-> Prompt Active X controls”-> Disable 2) Connection Select “ Temporary Allow Click here as described Pop-ups” Click “ To help protect security,...
- Page 15 H.264 Realtime DVR – QUICK USER GUIDE APPENDIX 2 DYNAMIC IP (Supporting DDNS Server) With DDNS Server, This allows a user to connect to the unit remotely without the need for a fixed IP address.(Please register your ID & Domain at www.ddns-dvr.com...
-
Page 16: Port Forwarding
H.264 Realtime DVR – QUICK USER GUIDE Appendix 3 SETUP FOR DVR PORT/ WEB SERVER PORT USING IP SHARING ROUTER (Port Forwarding) 1) To use IP sharing Router, “Use Dynamic IP” should be set to “NO”. - DVR Port: This can be set to any number between 2000 to 65535.
