    Table of Contents Hardware Installation and Connection................5 1.1 Check Unpacked DVR ..................5 1.2 About Front Panel and Real Panel ..............5 1.3 After Remove the Chassis..................5 1.4 HDD Installation .....................5 1.5 Front Panel ......................6 1.6 Rear Panel ......................9 1.7 Connection Sample ....................9 1.8 Alarm Input and Output Connection ..............10 1.8.1 Alarm Input and Output Details...............10 1.8.2 Alarm Input Port..................11...
  • Page 3 2.6.5 File backup and clip ..................17 2.6.6 Calendar .....................17 2.6.7 Slow playback and fast playback............18 2.7 Network Setup......................18 2.8 Pan/Tilt/Zoom .......................19 2.8.1 PTZ Setup ....................19 2.8.2 PTZ Operation ...................20 2.8.3 3D Intelligent Positioning Key ..............20 2.9 Card Overlay ......................21 2.9.1 COM Type ....................21 2.9.2 Network Type.....................21 Web Operation........................23 3.1 Network Connection ....................23...
  • Page 4 Welcome Thank you for purchasing our DVR! This quick start guide will help you become familiar with our DVR in a very short time. Here you can find hardware installation,cable connection information and general operations such as system setup, record, search, backup, alarm setup, PTZ operation, also here you can find web operation instruction.
  • Page 5: Hardware Installation And Connection

    1 Hardware Installation and Connection Note: All the installation and operations here should conform to your local electric safety rules. 1.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage.
  • Page 6: Front Panel

    ⑦Install the HDD bracket ⑧Install more HDD if necessary ⑨Fix the screws After HDD installation, please check connection of data ribbon and power cord. 1.5 Front Panel These series DVR has two types of front panels. One is without the LCD and the other is with the LCD.
  • Page 7 Power Powe Click it to boot up or shut down the button device. Connect to USB mouse or backup device. Cancel Cancel When playback, click it to restore real- time monitor mode Shift Use the front panel to switch the input method.
  • Page 8 Name Icon Function Remark When playback, click this button to In numeral input display previous file. mode, click this button Play previous In menu operation, go to previous menu to input 9. item,. ► In numeral input Various slow playback and normal mode, click this button playback.
  • Page 9: Rear Panel

    Go to the main menu In real-time monitor mode, click left/right In numeral input mode, direction keys to switch between one- Click to input 61 window and multiple-windows. In numeral input mode, Increase/decrease numeral Click to input 4. Modify setup Direction keys Switch PTZ control In 1-window real-time monitor mode,...
  • Page 10: Alarm Input And Output Connection

    Figure 1-4 1.8 Alarm Input and Output Connection There are two alarm input types for you to select: normal open (NO) and normal close (NC). 1.8.1 Alarm Input and Output Details You can refer to the following content and F igure 1-5 for alarm input and output information. X 2 8 8 H 2 8 8 H 2 8 8 H Figure 1-5 The value 1 to 6 represents ALARM1 to ALARM4 respectively.
  • Page 11: Alarm Input Port

    +12V is external alarm input. System needs external device to provide +12V power and you can connect it to the alarm device power below 1A. A/B is A cable and B cable to control 485 device. You can connect them to devices such as decoder.
  • Page 12: Overview Of Navigation And Controls

    2 Overview of Navigation and Controls Before operation, please make sure: You have properly installed HDD and all the cable connections. The provided input power and the device power are matched. The external power shall be: AC90~264V 50+2% Hz Always use the stable current, if necessary UPS is a best alternative measure. 2.1 Login, Logout &...
  • Page 13: Logout

    Figure 2-2 2.1.3 Logout There are two ways for you to log out. The first one is from menu option: In the main menu, click shutdown button, you can see an interface is shown as below. See Figure 2-3. Figure 2-3 There are several options for you.
  • Page 14: Live Viewing

    2.2 Live Viewing After you logged in, the system is in live viewing mode by default. You can see system date, time and channel name. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->General).
  • Page 15: Manual Record

    Figure 2-5 2.4 Manual Record Note: Please make sure you have the record operation right and you have properly installed the formatted HDD. You can right click mouse or in the main menu, from Advanced->Manual Record to go to record interface.
  • Page 16: Search And Playback

    Figure 2-7 2.6 Search and Playback Click search button in the main menu, search interface is shown as below. See Figure 2-8. Usually there are three file types: R: Regular recording file.- A: External alarm recording file. M: Motion detection recording file C: Card number recording file.
  • Page 17: Playback Operation

    Figure 2-8 Please refer to the following sheet for more information. Serial Number Function Play Backward Stop Slow play Fast play Previous frame Next frame Volume Previous file Next channel Next file Previous channel Search Backup Clip 2.6.1 Playback Operation There are various search modes: video type, channel number or time.
  • Page 18: Slow Playback And Fast Playback

    In t he following interface you can see there are video files in June 13 2007 and 14 2007. X 3 0 0 H 3 0 0 H 3 0 0 t Double click the date to view file list. Figure 2-9 2.6.7 Slow playback and fast playback Please refer to the following sheet for slow play and fast playback function.
  • Page 19: Pan/Tilt/Zoom

    Network download: System can process the downloaded data first if you enable this function. Advanced setting: Please refer to the user’s manual included in the resource CD for detail information. After completing all the setups please click save button, system goes back to the previous menu. Figure 2-10 2.8 Pan/Tilt/Zoom Please note:...
  • Page 20: Ptz Operation

    After completing all the setups please click save button, system goes back to the previous menu. 2.8.2 PTZ Operation In one window display mode, right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure 2-12. Figure 2-12 Click Pan/Tilt/Zoom, the interface is shown as below.
  • Page 21: Card Overlay

    Figure 2-15 Here is a sheet for you reference. Name Function function Shortcut Function function Shortcut Zoom Near ► Focus Near ► Iris close Open You can click set button in Figure 2-13 (or click REC button in the front panel) to set preset, tour, and pattern.
  • Page 22 For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number). Figure 2-17 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 2-18. Source IP refers to host IP address that sends out information (usually it is the ATM host.) Destination IP refers to other systems that receive information.
  • Page 23: Web Operation

    3 Web Operation Slightly difference may be found in the interface due to different series. 3.1 Network Connection Before web operation, please check the following items: Network connection is right DVR and PC network setup is right. Please refer to network setup(main menu->setting- >network) Use order ping ***.***.***.***(* DVR IP address) to check connection is OK or not.
  • Page 24 Click the channel name on the left side; you can view the real-time video. For detailed operation information, please refer to the User’s Manual included in the resources Figure 3-2 Note For detailed operation introduction, please refer to our resource CD included in your package for electronic version of the User’s Manual.
  • Page 25 Blue Box USB Backup Instructions 1. Insert USB Mouse into rear USB slot. 2. Insert USB memory stick into front USB slot. 3. Wait 10 seconds for the system to install the USB memory stick. 4. Right click mouse and drop down menu will appear. 5.
  • Page 27 Blue Box Cube Weekly Check Out                   Press power button if screen is dark         FOUR GREEN LEDS       ONE RED LED       RADAR IMAGE (RADAR MUST BE TURNED ON)       CAMERA IMAGE (MUST BE DONE DURING DAYLIGHT)              DATE:_______________________   INSPECTED BY:___________________________________________ ...
