Summary of Contents for Craig CMP738b
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS - 2 -... - Page 3 IMPORTANT SAFETY INSTRUCTIONS - - 3...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS - - 4...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS This manual contains important safety precautions and information for correct usage. Please be sure to read this manual carefully before use to avoid any damages to the device. Please do not place the product in hot, wet or dusty environment. Please do not place the product in hot environment.
-
Page 6: First Use
FIRST USE: Batter y Recharge The device has 2 (Two) built-in DC 3.7V, 1400 mAh rechargeable Lithium-ion Polymer battery. Recharge as follows: Insert the small plug from the supplied AC/DC Adaptor to the DC IN jack on the device. Plug the AC/DC Adaptor to wall outlet having AC 100-240V~, 50/60 Hz. -
Page 7: Power On/Off The Device
USB Host (Full size USB port) This device supports USB device for extending the memory size, or USB Thumb Driver/3G Driver, inserts it to the USB Host on the side of unit. Notes: Before replacing the USB driver, make sure the unit has been powered off. For 3G USB drive or USB thumb drive connection, check (icon will turn to green) the "USB mode Select"... -
Page 8: Earphone Jack
Connections: Connect to PC Press Menu button on the right top corner on the screen, set the "HOST MODE" in "USB Mode select" to disable (uncheck) (icon should be blank). Connect the Device to the PC via the Mini USB port on the side of cabinet to the USB port on your PC by the supplied connection cable. -
Page 9: Location Of Controls
Location of Controls Mic – Built-in microphone for sound recording. USB Host – to connect other external equipments such as USB thumb drive/3G module/USB Memory device. Mini HDMI – to connect external display device with support of maximum of 720p HDMI resolution. -
Page 10: B Asic Operation/Settings
B ASIC OPERATION/SETTINGS Description of Main Screen Power on the unit and wait until the following picture appears on the screen. Touch and slide the Key Bar shown on the screen upward to unlock. Home Screen Icons – There are 12 icons shown on the main screen. Tap individual icons to enter into each application. -
Page 11: Description Of Status Bar
Description of Status Bar The Status Bar shown below is located on the top of screen Home button - tap to return to home page Wi-Fi ON/Off and signal level (icon appears on the screen when it activates) Speaker on/off (icon appears on the screen when it activates) 3G connection status Battery Meter Clock... -
Page 12: Setting Menu
Setting Menu In home page, tap the Menu button on the right top corner on the screen, the setting menu will appear on the screen. Tap the setting ( ) button on the right bottom corner, the setting menu will appear on the screen as below. - Page 13 Tap the Wi-Fi” button, available networks are shown on the screen. (It may take a few minutes). Tap the desired network name to enter (may ask for password) then tap the “Connect” button to start connection. Wait until the Wi-Fi icon ( ) appears on the top of screen.
-
Page 14: Location & Security Settings
DISPLAY Brightness : Adjust the brightness of the screen. Auto-rotate screen: Enables or disables the screen orientation automatically. Animation : Enables or disables the Android Robot welcome start up display. Screen timeout: Set the auto power off period when the device is idle. Location &... - Page 15 Applications: Unknown sources: Allow installation of non-Market applications. Manage applications: manage and remove installed applications. Running services: view and control currently running services. Development: set options for application development. Account & sync Background data: Enables or disables applications can sync, and receive data at any time. Auto-sync: Enables or disables applications sync data automatically.
- Page 16 Privacy: Back up my data: Enables and disable back up all device setting and other data. Automatic restore: Enables and disables application, restore backed up setting or other data. Factory data reset: Erases all user's data in the device SD card & device storage: To read the status of the installed Micro SD card or remove the card in safe mode follows the on screen instructions.
- Page 17 Language & Keyboard: To select language for device and keyboard type settings. Voice input & output: To set or reset Test-to-speech settings. - 17 -...
- Page 18 Accessibility: To adjust accessibility setting. Date & time: Automatic: Enables and disables to use network time. Set date: To set your current date manually. Select Time zone: to set time zone manually. Set time: To set current time manually. (Note: For manual setting, you must disable Automatic so that no network time is provided.) Use 24 hour format: Set the display format of the clock to 12 or 24 hours format.
- Page 19 Touch panel calibration To calibrate the touch screen follow on screen instruction. USB mode select Host Mode: 1. Uncheck for PC connection(icon should be blank) 2. Check for USB thumb drive or 3G USB Module connection(icon will turn to green) About device To display information of the device.
-
Page 20: Home Screen Applications
The main Applications on Home Page Home Screen applications: Wi-fi – Tap to turn Wi-Fi connection open or close Note: It may take a few minutes to complete the connection. Please wait. Internet browser: Tap on the Browser to open web pages. Email: Tap “... -
Page 21: Photo Player
Photo Player: Tap the icon to enter into photo player to play photos. Ebook reader: Tap the icon to enter into the book shelf to select/manage and/or read ebooks. Amazon App Store: Click to browse the Amazon APP Store Main page. Input your email address at "Get Started"... -
Page 22: Video Player
VideoPlayer : Tap the icon to turn on the video player. Tap the desired file name to start play back. While watching a movie, change to HDMI out to TV, please follow instructions on page 8. Social networking: The Device is pre-loaded with the most popular social applications for usage.Tap on individual icon to log in with pre-registered login name and passwords, otherwise, you may register online by following the screen instructions. - Page 23 Unable to Read Ebook Application Kindle already installed in the device. Make sure you are using this apps “Kindle” to read the ebook bought from Amazon. Some online bookshops do require their own application to buy, download, read and manage your purchases.
- Page 24 Cannot hook up with Wi-Fi or the Wi-Fi signal is weak Make sure the Wi-Fi is available in your location and you are authorized (to have password) to hook up to it. The device may be too far from the signal source. Move your device closer to the signal source.
-
Page 25: Product Specifications
PRODUCT SPECIFICATIONS Hardware Configuration: Processing Speed 800 MHz Memory/ROM 4GB (Internal 2GB flash memory has been assigned for Android operating system and pre-loaded Apps, existing 2GB flash space is available for further operation needs) Memory/RAM 256 MB Memory Card Slot Micro SD (up to 32G), not included Color Display 7 inch TFT Color LCD with Resistance Non-glareTouch Screen... -
Page 26: Limited Warranty
Under no circumstance shall Craig be liable for any loss or consequential damage arising out of the use of this product. This warranty gives specific legal rights. However, you may have other rights which may vary from state to state.
