Summary of Contents for Craig CMP745d
- Page 1 10.1 inch Touch 10.1 inch Touch Screen Tablet Screen Tablet Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model: CMP745d...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS - 2 -... - Page 3 IMPORTANT SAFETY INSTRUCTIONS - - 3...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS - - 4...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS This manual contains important safety precautions and information for correct usage. Please be sure to read this manual carefully before use to avoid any damages to the device. Please do not place the product in hot, wet or dusty environment. In the Summer time, do not place apparatus in th car with all the windows closed.
-
Page 6: First Use
FIRST USE: Battery Recharge The device has 2 (Two) built-in DC 3.7V,2500mAh rechargeable Lithium-ion Polymer battery. Recharge as follows: Insert the small plug from the supplied AC/DC Adaptor to the DC IN jack on the device. Plug the AC/DC Adaptor to wall outlet having AC 100-240V~, 50/60 Hz. During charging, the charging indicator will turn on. - Page 7 Important: Formatting the Micro SD Card will delete all the data on the card. Download the data to your computer before formatting the card. USB Host (Full size USB port) This device supports USB device for extending the memory size, or USB Thumb Driver/3G Driver, insert it to the USB Host on the side of unit.
- Page 8 C. Touch the ( ) USB connected, the follows picture will appear: D. Touch the "Turn on USB storage" button on the screen then follow the on screen instructions to start the connection.
- Page 9 E. When finished, touch the "Turn off USB storage" button to save and exit in safe mode. Connect to HDMI TV Acquire an HDMI connection cable, on one side the HDMI Jack is full size, on the other the HDMI Jack is mini size. ( HDMI cable not supplied). During playback movie.
-
Page 10: Location Of Controls
Location of Controls Power (Standby) button – Press and hold the button approximately 3 seconds to power on the unit. In power on mode, press to turn off the screen for saving battery power. To power off, press and hold the button until the "Power off " window pop up then power off the unit as the on screen instruction. -
Page 11: Basic Operation/Settings
module/USB Memory device. Micro SD Card Slot—for Micro SD Card. Mini USB – to connect with computer for data transfer. Mini HDMI – to connect external display device with support of maximum of 1080p HDMI resolution. Earphone jack – Connect to external Earphone. Mic –... - Page 12 The following picture will appear: Press the " " button on the upper-right corner, the follows screen will appear. Control buttons on the tool bar on the screen: Wi-Fi ON/OFF and signal level (icon appears on the screen when it activates) Battery Meter Clock Volume –...
-
Page 13: Setting Menu
Adjust the screen size Reorganization location of widgets: To reorganize the location of the widgets from sub pages to home pages. Touch and hold the desired widget. To reorganize the location of the widgets within the same page/layer, touch and hold the widget approximately 1 second then slide it to the desired location. - Page 14 ）button on the screen, the setting menu will appear on the Touch the Menu（ screen,then: Touch the screen and slide Left or Right (Up or Down) to show more selections. Touch the corresponding button you need to set. The sub-setting menu will appear on the screen, follow on screen instructions.
- Page 15 1. After setting, you can turn it ON or OFF (saving bettery power) by touch the ( widget on the screen to turn it on/off as on screen instruction. 2. Touch the ( ) on the upper-right corner to enter to Advanced setting menu. Data usage: Touch the “Data usage”...
- Page 16 Language & Input To set the language and Keyboard & input method. Backup & reset To set back up the personal data and reset all settings to Factory Default settings. IMPORTANT: After Factory Data reset, all users’ data (users installed applications,passwords, e-mail accounts, g-mail accounts, media files ...) will be erased.
-
Page 17: Troubleshooting
Installation: Tap the “Install” button, the memory location list will appear on the screen. Select and tap where your APK file is located, either Internal memory or external SD Card. The files list will appear on the screen. Select and tap into the file to install the file onto your device. Select and Tap the “Manage”... - Page 18 Cannot go online Check if your Wi-Fi setting is correct, proper password may be needed. Check if your router is working properly. Check your signal bar on the Device. It may not be connected due to weak signal. How to buy/download the applications from the internet Make sure your device is already hooked up to Wi-Fi/3G networks.
- Page 19 PC as the on screen instructions. ~ Save the downloaded firmware into a micro SD card. ~ Insert the micro SD card to the CMP745d then power on the device. Install the new firmware to the device as the on screen instructions.
-
Page 20: Product Specifications
PRODUCT SPECIFICATIONS Hardware Configuration: Processing Speed 1GHz 4GB (Internal 2.6GB flash memory has been assigned for Android operating system and pre-loaded Apps, existing Memory/ROM 1.3GB flash space is available for further operation needs) Memory/RAM 1GB, DDR III Memory Card Slot Micro SD (up to 32G), not included 10.1 inch TFT Color LCD with Capacitance Non-glare Color Display... -
Page 21: Limited Warranty
Under no circumstance shall Craig be liable for any loss or consequential damage arising out of the use of this product. This warranty gives specific legal rights. However, you may have other rights which may vary from state to state.
