Biamp Vocia ANC-1 Operation Manual
Output level adjuster
Hide thumbs
Also See for Vocia ANC-1:
- Operation manual (5 pages) ,
- Manual (9 pages) ,
- Operation manual (21 pages)
Subscribe to Our Youtube Channel
Related Manuals for Biamp Vocia ANC-1
Summary of Contents for Biamp Vocia ANC-1
- Page 1 Vocia ® ANC-1 Operation Manual January 2012 Biamp Systems, 9300 SW Gemini Drive, Beaverton, Oregon 97008 U.S.A. (503) 641-7287 www.biamp.com...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 10) Protect the power cord from being walked on or pinched particularly at plugs, 2) Keep these instructions. convenience receptacles, and the point 3) Heed all warnings. where they exit from the product. 4) Follow all instructions.
-
Page 3: Table Of Contents
TABLE OF CONTENTS VOCIA AMBIENT NOISE COMPENSATION 1 (ANC-1) FEATURES . . . . . . . . . . . . . . . . . . . . . . . SETUP AND USE . -
Page 4: Vocia Ambient Noise Compensation 1 (Anc-1) Features
® a networked device for use with Biamp’s Vocia Amplifier (VA-8600). It accepts two ambient noise inputs at microphone or line level. Most high-quality dynamic and condenser microphones can be used in conjunction with the ANC-1. Input gain for each of the two inputs is user configurable via the Vocia software interface. -
Page 5: Setup And Use
ANC-1 SETUP AND USE Setup and Use The Vocia software provides an intuitive interface for configuration of the ANC-1. The information supplied by this manual relates to physical connections and assignment. For more details on setup of the ANC-1 operational parameters please consult the Vocia Help File. Device ID The rotary ID switches are located on the ANC-1 and give the unit a unique Device ID. -
Page 6: Ambient Noise Input Connections
ANC-1 SETUP AND USE Ethernet switch with PoE ANC-1 CobraNet Device ID ® PoE IEEE 802.3af Class 2 N24138 ANC-1 YEL:in use/conductor Input 1 Input 2 GRN:link/activity Ambient Sense Inputs (mic/line) Ethernet switch without PoE ANC-1 Device ID CobraNet ® PoE IEEE 802.3af Class 2 N24138... -
Page 7: Installation
ANC-1 INSTALLATION Installation The ANC-1 can be mounted on a wall using screws through the case flanges (#6 or 6mm dia. X 4) or two screws in the keyholes on the rear (#8 or 4.5mm dia., max 9mm dia. head). 120mm, 4.724"... -
Page 8: Specifications & Block Diagram
ANC-1 SPECIFICATIONS Ambient Noise Compensation 1 SPECIFICATIONS Ambient Noise Environment RT 2x balanced mic/line level 300mS to 2 Seconds Input Configuration: Phantom power: 48 VDC (7mA/ input) Compliant with IEC 1938 Plug-in barrier strip connectors Input Impedance: Metering: 8k ohms (mic/line balanced) Ambient Level;... -
Page 9: Warranty
9. Biamp systems shall not be liable for special, indirect, incidental, or consequential damages, including lost profits or loss of use arising out of the purchase, sale, or use of the products, even if BIAMP Systems was advised of the possibility of such damages. -
Page 10: Fcc Compliance
FCC COMPLIANCE FCC NOTICE - CLASS B DIGITAL DEVICE NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential as well as in a commercial installation. -
Page 11: Ec Declaration
DIRECTIVES below except as noted herein. Any alterations to the product not agreed upon and directed by Biamp Systems Corporation will invalidate this declaration. ® Product Model:... -
Page 12: Eu Rohs Compliant
COMPLIANCE...
