Epygi QuadroCS SW-Version Installation Manual

Quadrocs sw-version
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QuadroCS SW-Version and is the answer not in the manual?

Questions and answers

Related Manuals for Epygi QuadroCS SW-Version

Summary of Contents for Epygi QuadroCS SW-Version

  • Page 2: Quadro Manual I: Installation Guide

    FCC Statement (Part 15) Class B The Epygi Quadro has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Quadro. User further acknowledges that any interruption in the supply or delivery of electricity or network availability is beyond Epygi's control and that Epygi shall have no responsibility for losses arising from such interruption.

  • Page 4: Table Of Contents

    Step 2.4: Firewall Configuration ............24 Step 3: Registering on Epygi’s Technical Support ......25 Step 4: Registering a Conference on Epygi’s SIP Server ....27 Step 5: Configuring a Conference on the QuadroCS ....... 29 Appendix: PC DHCP Settings ............
  • Page 5 Before a QuadroCS conference can be registered on the Epygi SIP server, you must be registered with Epygi Technical Support. This section shows you how to gain ac- cess to the Epygi Technical Support Center and the Epygi SIP Server. If no SIP reg- istration is needed, skip to Step 5.

  • Page 6: About This Installation Guide

    Quadro Manual I: Installation Guide Requirements Requirements • One 120/240 VAC power outlet in close proximity to the Quadro. • One RJ-45 Ethernet 10/100 broadband Internet connection. • One CAT 5 Ethernet cable with an RJ-45 connector to connect to the Quadro LAN port •...

  • Page 7: Hardware Overview

    Quadro Manual I: Installation Guide Hardware Overview Hardware Overview QuadroCS Rear Panel Fig. I-1: QuadroCS Rear Panels Power socket. Use only the power adapter delivered with the QuadroCS. RJ-45 socket to attach the Local Area Network (LAN) via an Ethernet CAT 5 cable. If a PC is connected directly to this socket, a straight cable is used.

  • Page 8: Quadrocs Front Panel Leds

    Quadro Manual I: Installation Guide Hardware Overview QuadroCS Front Panel LEDs Fig. I-2:QuadroCS Front Panel LEDs Busy off: No power green on or blinking: Normal activity Status of CPU on: device is booting Info off: no information yellow blinking: an event occurred, details specified in the System information System Event section of the Management interface Fault...

  • Page 9: Step 1: Installing The Quadrocs

    In some scenarios, port forwarding on the router is required to make the QuadroCS accessible to other Quadro devices and the Epygi SIP Server on the Internet. The recom- mended configuration option is to connect the QuadroCS directly to the Internet eliminating the need to traverse the local NAT firewall.

  • Page 10: Wan Connection Options

    Quadro Manual I: Installation Guide Step 1: Installing the QuadroCS WAN Connection Options • QuadroCS behind a router, which is connected to a cable or DSL modem. Fig. I-3: Configuration: QuadroCS behind a router In this configuration, the IP router typically acts as a DHCP server for the LAN and assigns the IP addresses to the PCs and other devices.

  • Page 11: Connecting The Hardware

    Quadro Manual I: Installation Guide Step 1: Installing the QuadroCS Connecting the Hardware • QuadroCS behind a router Fig. I-5: Installation: QuadroCS behind a router • QuadroCS directly connected to the Internet Fig. I-6: Installation: QuadroCS directly connected to the Internet •...
  • Page 12 Quadro Manual I: Installation Guide Step 1: Installing the QuadroCS Please Note: The PC must be configured for DHCP to receive an IP address directly from the QuadroCS. Refer to the first Appendix for instructions on how to set up a PC for DHCP operation.

  • Page 13: Step 2: Configuring The Quadrocs

    Quadro Manual I: Installation Guide Step 2: Configuring the QuadroCS Step 2: Configuring the QuadroCS The QuadroCS does not require fur- ther network configuration in two cases: • The QuadroCS is connected behind a basic router that is compatible with the QuadroCS’s implementation of STUN •...

  • Page 14: Step 2.1: Logging In To Quadrocs

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration Step 2.1: Logging in to QuadroCS • Start a browser (MS Internet Explorer, Netscape, Opera) on a PC connected to the LAN port. • Enter http://172.30.0.1 (QuadroCS’s default LAN IP address) into the address field.

  • Page 15: Step 2.2: System Configuration Wizard

    The Host Name is very useful when many Quadro's are part of a network and one administrator has remote access to all of them. All Quadro pages show the host- name on the top right corner under Epygi logo. Fig. I-9: System Configuration page Clicking Next shows the page DHCP Settings for the LAN Interface.

  • Page 16: Dhcp Settings For The Lan Interface

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration DHCP Settings for the LAN Interface If the DHCP server is enabled, the Quadro will automatically assign dynamic IP addresses to the stations connected to its LAN port. If you didn’t change the default LAN IP address of the Quadro, you also may leave the de- fault values for the IP Address Range.

  • Page 17: Finishing The System Configuration Wizard

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration Proper configuration of Regional Settings is important for the functionality of the voice sub- system. The Regional Settings determine the proper telephony parameters on the LINE (ISDN) and PHONE ports of the Quadro for the specified country. Select the country where the Quadro is located.
  • Page 18 Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration After this is complete, the Quadro will reply with the Confirm Settings page requesting confirmation of the changes. Press on OK to confirm the settings. Fig. I-14: Confirm Settings page Please Note: you must confirm the settings within 20 minutes, otherwise the device will re- vert back to the previous configuration and reboot.

  • Page 19: Step 2.3: Internet Configuration Wizard

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration Step 2.3: Internet Configuration Wizard Open the Internet Configuration Wizard by selecting the corresponding menu item on the System menu. The Internet Configuration Wizard is a tool for the administrator to config- ure the WAN settings and to adjust Quadro's connectivity in the global network.

  • Page 20: Uplink Configuration

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration This information will be needed to be inserted in the Internet Configuration Wizard. Uplink Configuration Select the desired WAN Inte rface Protocol and enter the WAN Interface Bandwidth to as- sure the quality of IP calls. Fig.

  • Page 21: Wan Ip Configuration

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration WAN IP Configuration Your Internet Service Provider (ISP) should provide this information. • Assign automatically via DHCP - The parameters are set automatically by the ISP. This is common with cable modem and DSL service. •...

  • Page 22: Ppp Settings

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration PPP Settings Enter the IP address of the PPTP server into the PPTP Server text field. Choose the encryption for the traffic over the PPTP interface from the Encryption drop down list. Fig.

  • Page 23: Wan Interface Configuration

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration WAN Interface Configuration If your ISP requires a specific MAC address, (for example, for authentication), it can be en- tered on this page. The required MAC address can be entered into the User defined field. If a specific MAC address is not required, leave the default selection This device selected.

  • Page 24: Finishing The Internet Configuration Wizard

    Reviewed QUIG by Thomas/Isolde Step 2.2: Basic Configuration The Quadro will suggest the correct settings. If Dynamically by Provider is selected, the DNS server settings will be set automatically whenever a connection to the Internet is es- tablished. If Fixed Nameserver Address is selected, manually enter the IP addresses provided by your ISP for the name server and the alternative name server.

  • Page 25: Step 2.4: Firewall Configuration

    SIP server to register automatically. If you want to use the Epygi SIP Server to register your conference, you have to register at Epygi Technical Support first (see next step below) to get a login to the Epygi SIP server.

  • Page 26: Step 3: Registering On Epygi's Technical Support

    Step 3: Registering on Epygi’s Technical Sup- port It is recommended that you register your Quadro on the Epygi Technical Support web page. Registration will give you access to the Technical Support Database. There, you can send requests concerning technical problems as well as refer to the frequently asked ques- tions.
  • Page 27 Quadro Manual I: Installation Guide Step 3: Registering on the Epygi's Technical Support Complete all fields and record the Login Name and Password in a safe place. You will need it for the SIP server. Please Note: In some cases the...

  • Page 28: Step 4: Registering A Conference On Epygi's Sip Server

    Center. If you have not registered with Epygi Technical Support, you will not be able to login to the Epygi SIP Server. Using the same login name and password you use for Epygi Support, login to the Epygi SIP Server at www.epygi.com...
  • Page 29 Quadro Manual I: Installation Guide Step 4: Registering a Conference on Epygi's SIP Server Fig. I-26: SIP Services Add New Extension page The Authentication password is used to validate the entry and must match the password entered on the Quadro at a later time. Make sure to record the name, Authentication Pass- word and SIP extension number so you can enter them into the Quadro later.

  • Page 30: Step 5: Configuring A Conference On The Quadrocs

    Quadro Manual I: Installation Guide Step 5: Configuring a Conference on the QuadroCS Step 5: Configuring a Conference on the QuadroCS Open the Conferences page from the Conference Management menu. Fig. I-28: Conferences page Click Add to open the Conference Wizard to guide you through the basic settings needed to generate a new conference.
  • Page 31 Quadro Manual I: Installation Guide Step 5: Configuring a Conference on the QuadroCS Fig. I-29: Conference General Settings page Fill in the following information on this page: Conference ID is used to enter a unique ID for the call conference. This ID will be also used in Conference Server's Auto Attendant to reach the local conference.
  • Page 32 Registration SIP Server indicates the host address of the SIP server. The field is not limited regarding symbol usage and length. It can be either an IP address (ex: 192.168.0.26) or a host address (ex: sip.epygi.com). Registration SIP Port indicates the host port number to connect to the SIP server. The SIP server port may only contain digit values.
  • Page 33 Quadro Manual I: Installation Guide Step 5: Configuring a Conference on the QuadroCS Press Finish to create a conference with the provided settings. Please Note: You may also duplicate an existing conference using its common settings (like participants, scheduling options, SIP registration settings and other configuration set- tings).

  • Page 34: Appendix: Pc Dhcp Settings

    Quadro Manual I: Installation Guide Appendix: PC DHCP Settings Appendix: PC DHCP Settings The QuadroCS has a DHCP server on its LAN interface that provides DHCP IP addresses to devices connected to the LAN. This appendix describes how to configure Windows PCs for DHCP.
  • Page 35 Quadro Manual I: Installation Guide Appendix: PC DHCP Settings Select Obtain an IP address automati- cally, then click on Advanced. You will see the entry DHCP Enabled. Click OK three times to close all windows. TCP/IP and DHCP under Windows 95/98/ME Click the Start button.

  • Page 36: Appendix: Changing The Admin Password

    Quadro Manual I: Installation Guide Appendix: Changing the Administrator's Password Appendix: Changing the Admin Password For security reasons, it is recommended that you change the default admin password. The username of the administrator (admin) cannot be changed. To change the administrator password, go to the System menu, User Rights Manage- ment.
  • Page 37 Quadro Manual I: Installation Guide Appendix E - Checking the Connections QuadroCS (SW Version 3.1.x)
