- Page 2 Please install and operate the fixture with following instructions. Meanwhile, please keep this manual well for future needs. G-Lites Quad Wash 360 LED Wash Moving Head is made of a new type of high temperature strength of engineering plastics and cast aluminum casing with nice outlook. The fixture is designed and manufactured strictly following CE standards, complying with international standard DMX512 protocol.
- Page 3 During initial start-up some smoke or smell may arise. This is a normal process and does not necessarily mean that the device is defective, it should decrease gradually. Please don't project the beam onto combustible substances. Fixtures cannot be installed on combustible substances, keep more than 50cm distance with wall for smooth air flow, so there should be no shelter for fans and ventilation for heat radiation.
- Page 4 Be sure to complete all rigging and installation procedures before connecting the main power cord to the appropriate wall outlet. Clamp Mounting: G-Lites Quad Wash 360 provides a unique mounting bracket assembly that integrates the bottom of the base, the included “Omega bracket,” and the safety cable rigging point in one unit (see the illustration below).
- Page 5 integrated in the base assembly. Regardless of the rigging option you choose for your G-Lites Quad Wash 360, always be sure to secure your fixture with a safety cable. The fixture provides a built-in rigging point for a safety cable on the hanging bracket as illustrated above. Be sure to only use the designated rigging point for the safety cable and never secure a safety cable to a carrying handle.
- Page 6 6. Menu operations 6 ...
-
Page 7: Dmx Channels
7. DMX channels 7 ... - Page 8 8 ...
-
Page 9: Photometric Data
8. Photometric data 9 ... - Page 10 9. Features 36PCS 10W high power CREE Quad Color LEDs Specific optic system 50,000 hours lifespan and low power consumption Smooth and precise resolution for PAN/TILT movement 540°/630° pan and 265° tilt movement Scan position memory, auto reposition after unexpected movement RGBW color mixing system Color temperature adjustable for white LED shutter...
- Page 11 In order to make the lights in good condition and extend the life time, we suggest a regular cleaning to the lights. 1) Clean the inside and outside lens each week to avoid the weakness of the lights due to accumulation of dust.
