Summary of Contents for g-lites STAR SEARCH 4000
- Page 2 Check upon receipt When you receive the product, please open the box to check whether the parts of the light to be damaged during transmit. Please inform the delivery company and keep the damaged box as the proof if you find there has some parts are damaged. Installation 1.
- Page 3 Xenon lamp operation illustration • Search light have the power from 2KW-7KW. Light upon power. • Pay more attention to the sign of “+” and on the lamp. The big size screw and with the piece are “+”. The small is “-” . The lamp must connect right with the power otherwise the lamp will burn •...
- Page 4 Adjust the center of light beam: the light beam adjust well or not is the hinge of the light effect. After finished the lamp installation, please do not stand in front of the lamp when the front cover was open. Switch on power the lamp will light up.
- Page 5 make fir, it maybe the trigger has out of work. Please replace the parts according to the above method to obviate trouble. Exchange Xenon Lamp Step1: Take off the lamp head cover. Take off the 10 pieces six screws with hexangular screwdriver on the lamp head cover.
- Page 6 Technical Data Lamp Xenon Lamp XHA - 4KW - 5KW Lamp-house: Ultrahigh pressure gas light Light Beam Depending on your requirements, you can choose either: 6, 12, 18, 24 and 28 light beams. Light beam circles 80º - 120º. Range: 1-5 Km 110º...
- Page 7 MAINTENANCE This chapter includes information on replacing parts and cleaning the fixture. This fixture must be serviced by qualified personnel. The information listed in this chapter only is intended to assist qualified personnel Important Information: o Disconnect the fixture from power before servicing. o Exterior surfaces can reach 200˚...
- Page 8 This Chapter provides information on diagnosing and solving operational problems. If a solution to your problem cannot be found in the following subsections, contact your authorized dealer or G-Lites Technical Support. Unit functions but lamp does not strike: o Make sure the correct lamp has been installed in the fixture.
