Am-6000 Rear I/O Panel Configurations; Figure 2-2: Front Panel Controls And Indicators (Am-990) - Alpha Microsystems AM-6000 Owner's Manual

Installation

Figure 2-2: Front Panel Controls and Indicators (AM-990)

For information on various display codes that might appear on the AM-6000's front panel digital display,
see Chapter 8, "Status Display Codes."

AM-6000 Rear I/O Panel Configurations

The types and number of connectors on the rear panel of your AM-6000 computer will vary depending
on the chassis and the equipment included with your order. The illustrations on the next few pages show
the AM-6000 rear panel configurations on a deskside chassis and the AM-990 chassis:
AM-6000 Computer Owner's Manual, Rev. 00
LOCK
STATUS
MEMORY
DISPLAY A
DISPLAY B
DISPLAY C
SELECT RESET
SELECT POWER
Page 2-5
RUN
