Summary of Contents for healing HHT896
-
Page 2: Notes
HHT896 HD Digital Terrestrial Receiver Operating Manual NOTES... -
Page 3: Hht896 Features
HHT896 HD Digital Terrestrial Receiver Operating Manual HHT896 FEATURES Sensitive Tuner – responds to weak signals Signal Strength and Quality bars colour coded Receives all ‘freeview’ channels Stores up to 400 TV and Radio channels 7 Day Electronic Program Guide with 8 day cross over... -
Page 4: Preface
Media Player function, yet is easy to install with all AV outputs active simultaneously. Built in a small footprint case less than 220mm wide with a removable mains power lead, HHT896 also includes up to 8 day Electronic Program Guides, Optical Digital Audio for full surround sound and embedded Closed Caption Subtitles. -
Page 5: Table Of Contents
HHT896 HD Digital Terrestrial Receiver Operating Manual INDEX NOTES ......................2 HHT896 FEATURES ................... 3 PREFACE..................... 4 SAFETY ....................... 4 GENERAL OPERATION OF THE RECEIVER ......... 4 INDEX......................5 FRONT PANEL.................... 6 REAR PANEL ....................7 REMOTE CONTROL UNIT - KEY FUNCTIONS ........8 REMOTE CONTROL UNIT - KEY FUNCTIONS ........ -
Page 6: Front Panel
HHT896 HD Digital Terrestrial Receiver Operating Manual FRONT PANEL a. STANDBY key - Switches between Operational and Standby modes b. LED display - Shows channel selected, Load status etc. c. Power LED, green - Indicates power supply active d. Signal Lock LED, Orange - No Light = No Signal = No Pictures or Sound. -
Page 7: Rear Panel
HHT896 HD Digital Terrestrial Receiver Operating Manual REAR PANEL 1. ANTENNA LOOP OUT: passes antenna signal to another receiver, Antenna Loop Out becomes idle when receiver on STANDBY! 2. ANTENNA IN: connect your antenna, essential for stable pictures. 3. COMPONENT VIDEO: Y,Pb,Pr outputs for high picture quality. -
Page 8: Remote Control Unit - Key Functions
HHT896 HD Digital Terrestrial Receiver Operating Manual REMOTE CONTROL UNIT - KEY FUNCTIONS... -
Page 9: Remote Control Unit - Key Functions
HHT896 HD Digital Terrestrial Receiver Operating Manual REMOTE CONTROL UNIT - KEY FUNCTIONS • STANDBY. Standby and Operational / On Off modes switch. • MUTE. suspends or re-instates sound. • RECALL. selects the last tuned channel, when the Menu is off. -
Page 10: Preparing Remote Control For Use
HHT896 HD Digital Terrestrial Receiver Operating Manual PREPARING REMOTE CONTROL FOR USE Fresh batteries help ensure your Remote Control Unit is reliable. 1. Open the battery compartment lid on the back of the RCU. 2. Insert the batteries, negative terminals first. Take care that battery polarity markings correspond with those of the Remote Control. -
Page 11: Rcu Battery Safety Precautions
HHT896 HD Digital Terrestrial Receiver Operating Manual RCU BATTERY SAFETY PRECAUTIONS Save your RCU from damage by following these precautions: 1. Check that polarities of batteries and RCU battery terminals correspond. 2. If storing your receiver for weeks or longer, remove the batteries. -
Page 12: Setting Up Your Receiver
Operating Manual SETTING UP YOUR RECEIVER Your healing HHT896 High Definition Receiver comes with a selection of Video and Audio outputs. The outputs you use will be determined by the inputs available on your TV monitor and/or HI-FI equipment. This receiver delivers excellent picture and sound quality from High Definition and Standard Definition broadcasts. - Page 13 HHT896 HD Digital Terrestrial Receiver Operating Manual 1. BASIC SET UP using COMPOSITE VIDEO output Uses the single Yellow RCA Video connector for Composite Video (CVBS) with the Red and White RCA AUDIO R & L connectors at the back of your receiver.
- Page 14 HHT896 HD Digital Terrestrial Receiver Operating Manual 2. BASIC SET UP using COMPONENT VIDEO (Red Green Blue) For component connection, use the Red Green Blue video and the Red White audio RCA connectors on the back of the receiver. The RCA leads included with your receiver can assist.
- Page 15 HHT896 HD Digital Terrestrial Receiver Operating Manual e) You can also obtain premium quality Digital Audio from the OPTICAL SPDIF terminal to a Digital Audio input on your Audio Decoder or TV set. Optical connections also provide a high level of electrical isolation.
-
Page 16: Getting Started
3. Turn on your monitor or TV. 4. Turn on your HHT896 receiver. 5. Select the appropriate Input on your monitor or television and connect. 6. The HHT896 Menu should be visible on your Monitor or TV. FIRST TIME USE To simplify installation, default options are pre-selected for Australia. -
Page 17: Channel Search
HHT896 HD Digital Terrestrial Receiver Operating Manual Should [Channel Search] be finding transmitters not required, you can truncate Search by connecting the antenna for required channels only. To use your receiver press the ‘▲’ ‘▼’ or 0 – 9 keys to change channels, ‘◄’... -
Page 18: Picture
HHT896 HD Digital Terrestrial Receiver Operating Manual Manual Search: Press the ‘▼’ key to select [Manual Search] and ‘◄’ or ‘►’ keys to select a Channel to search. The [Quality] bar indicates an active channel. Press the ‘OK’ key to initiate scan. -
Page 19: Program
HHT896 HD Digital Terrestrial Receiver Operating Manual OPTION Press the ‘MENU’ key to enter the Main Menu, then ‘◄’ or ‘►’ keys to select a sub menu option. Press ‘▼’ or ‘OK’ keys to enter. OSD Language: enables users to select On Screen Display in English, French, Spanish, Czech or Slovenian by pressing ‘◄’... -
Page 20: System
HHT896 HD Digital Terrestrial Receiver Operating Manual Press the ‘Green’ key. Skipped programs are marked in the All TV List. Lock: press the ‘Yellow’ key to Lock or Unlock a program or channel. Enter Password (default 000000) to access. Locked programs are marked with a padlock in the All TV List. -
Page 21: Usb Recorder And Media Player
‘EXIT’ key to [Cancel] and Return. USB RECORDER AND MEDIA PLAYER HHT896 includes a useful USB Recorder and Media Player. It can Record programs to view at your leisure, TimeShift (Rewind and Fast Forward) live TV, or play a wide variety of media files. - Page 22 HHT896 HD Digital Terrestrial Receiver Operating Manual Aspect Ratio: [Keep] original picture shape; or [Discard] displays picture full screen. Movie Configure Subtitle Specific: select subtitle size. Subtitle BG: set subtitle background. Subtitle Font Color: set subtitle color. PVR Configure Record Device: shows USB device’s...
- Page 23 HHT896 HD Digital Terrestrial Receiver Operating Manual Press ‘PLAY’ to Play, ‘PAUSE’ or ‘PLAY’’ to pause. ‘STOP’ stops Play. The ‘◄’ ‘►’ keys regulate sound volume level. Music files will run during a Photo show. Photo: Press ‘▲’ or ‘▼’ and ‘OK’...
-
Page 24: Electronic Program Guide (Epg)
HHT896 HD Digital Terrestrial Receiver Operating Manual ELECTRONIC PROGRAM GUIDE (EPG) G is a 7 day (with 8 day crossover) TV Guide that is always current. Press the ‘EPG’ key to enter , from viewing mode. ►’ keys to change Press the ‘◄’... - Page 25 HHT896 HD Digital Terrestrial Receiver Operating Manual Two [Time Offset] methods are provided: [Auto] which by selecting [Country Region] adds Summer or Daylight Saving Offset automatically, or [Manual] where the user selects their offset from GMT in hours. Factory Default is [NSW], which works for most Eastern Australian locations.
-
Page 26: Specifications
HHT896 HD Digital Terrestrial Receiver Operating Manual SPECIFICATIONS Tuner Input Frequency range: 174 MHz - 806 MHz VHF High Band: 174 to 230 MHz UHF Band: 470 to 806 MHz Input Signal Level 28dBμV - 92dBμV Input Impedance 75 Ω... - Page 27 HHT896 HD Digital Terrestrial Receiver Operating Manual Audio Audio Decoding MPEG-1, MPEG-2 (layer I/II) Sampling Rate 32/44.1/ 48KHz Frequency Response 20Hz - 20kHz Output Level Adjustable, 600 Ω unbalanced Media Player .dat, .mpg, .mpeg, .ts, .trp, .tp, .m2ts, .vob, .mp4, .mkv, .divx, .avi, .mjpg, .mp3, .m4a, .aac, .wma, .asf...
-
Page 28: Media Player Codec Specification
HHT896 HD Digital Terrestrial Receiver Operating Manual MEDIA PLAYER CODEC SPECIFICATION File extension Container Video Codec SPEC Profile 1920x1080 dat, mpg, mpeg MPG, MPEG Mpeg1,2 Main Profile @ 30P H264: Main Profile and High Profile MPEG2 1920x1080 ts, trp, tp, m2ts MPEG2 ,H.264... - Page 29 HHT896 HD Digital Terrestrial Receiver Operating Manual MPEG2, MPEG4 MPEG2: Main Divx 3.11, Divx 4.Divx Profile 5, Divx 6, Xvid 1.00, AVI(1.0, 2.0), 1920x1080 MPEG4: Simple divx, avi Xvid 1.01, Xvid 1.02, DMF0,1,2 @ 30P Profile Xvid 1.03, Xvid Advanced Simple 1.10-beta1/2...
- Page 30 HHT896 HD Digital Terrestrial Receiver Operating Manual 48KHz(Sampling rate) 24Kbps 384Kbps(Bit rate) M4A/AAC AAC, HEAAC 8KHz ~ 48KHz(Sampling rate) Bitrate: 128bps 320Kbps WMA/ASF Sampling Rate: 8KHz ~ 48Khz Bitrate: 64Kbps 1.5Mbps LPCM (video files only) Sampling Rate: 8KHz ~...
-
Page 31: Twelve Month Warranty
In the event of a claim, proof of purchase in the form your Tax Invoice and this warranty slip may be required. - Page 32 HHT896 HD Digital Terrestrial Receiver Operating Manual ©2011 www.healingdigital.com errors and omissions excepted...
