  • Page 1: Quickstart Guide

    M-Series QuickStart Guide Publication Number 843-0151 (Rev J)

  • Page 2: Technical Support

    Datalogic Automation Inc. reserves the right to revise this publication from time to time and to make changes in the content hereof without obligation to notify any person of such revision or changes.

  • Page 3: Getting Started

    Getting Started Thank you for using Datalogic M-Series. This guide provides a brief overview to help you get started with your new sys- tem. For more detailed instructions, please refer to the Reference Guide (843-0093) and the M-Series Processor and Cam- era Guide (843-0148).

  • Page 4: Processor Specifications

    All the required software was installed on the M-Series processor at the factory. If you want to change the system config- uration, you will need to connect an optional monitor, mouse, and keyboard to the processor. For more details, refer to the M-Series Hardware Guide and Impact Reference Guide.
  • Page 5 IMPORTANT NOTE: Change only the Local Area Connection named LAN1 or LAN2. These correspond to Ethernet Ports 1 and 2 on the front of the processor. DO NOT change any of the other Local Area Connections. Changing any other connection can cause the M-Series cam- eras to stop functioning.
  • Page 6 Changing the M-Series Processor’s IP Address (Windows 7) M-Series QuickStart Guide 5. In the list of items, select Internet Protocol Version 4 (TCP/IPv4), then click Properties. 6. Select Use the following IP address. 7. Enter the desired IP address. 8. Click OK to close all the open dialog windows.

  • Page 7: Flat Surface Mounting

    Place the slots over the screws and slide the Processor down until the screws fit snugly into the mounting bracket slots. DIN Rail Mounting The M-Series Processor may be bottom-mounted on a DIN rail using the optional DIN Rail Mount kit (MX20/MX40: Part # 606-0683; MX80: Part # 95A906038). Page 5...
  • Page 8 DIN Rail Mounting M-Series QuickStart Guide DIN Rail Mount Kit Installation NOTE: If the Processor uses a Compact Flash card, horizontal mounting is recommended (the Processor front facing upward) so the card does not fall out due to vibration. To mount the Processor using the DIN Rail Mount kit (see diagram): To fasten the mounting bracket to the bracket holding plate, insert the bracket mounting screws from the reverse side of the bracket holding plate.
  • Page 9 @ 30VDC. Datalogic recommends using a 24 Connect - terminal to Power Supply Minus VDC power supply capable of providing 3.5A current. The M-Series processor runs most effi- Connect + terminal to Power Supply 10 to 30VDC* ciently at this voltage which is commonly used in many manufacturing environments.
  • Page 10 MX80 Processor Power Supply Connection M-Series QuickStart Guide MX80 Processor Power Supply Connection The MX80 power input uses a Datalogic-supplied Power Connector connector. Wire the power supply cable to the con- nector, then plug it into the power connector on the rear of the processor.
  • Page 11 M-Series QuickStart Guide MX20 and MX40 Rear Panel Connections MX20 and MX40 Rear Panel Connections This is the MX20 and MX40 Pro- cessors’ rear panel. Symbol Function USB Port Serial Port 2 Speaker and Microphone Power Switch MX80 Front Panel Connections These are the connections for the MX80 Processor’s front panel.
  • Page 12 MX80 Rear Panel Connections M-Series QuickStart Guide MX80 Rear Panel Connections MX80 Processor’s rear panel connections Symbol Function Do Not Use. (For future expansion) Serial Ports 2-4 (COM 2-4) Speaker and Microphone MX20 and MX40 Status Lights These are the status lights on the front of the MX20 and MX40 Processors.
  • Page 13 Green: 100 Mbps Orange: 1000 Mbps (Gigabit) LAN 1 and 2 Activity/Link On: Link is established Blinking: Data is being transferred M-Series Processor Serial Outputs MX20 and MX40 Serial Cable Pin Number Signal Name Carrier Detect (CD) Received Data (RxD)

  • Page 14: Input Characteristics

    The rear panel connector has three serial port connections for Serial Ports 2, 3, and 4 (COM 2, 3, and 4 respectively). CAM 2 controls Serial Port 2, CAM 3 controls Serial Port 3, and CAM 4 controls Serial Port 4. Use the Datalogic pro- vided cable which has a DB-62P connector on one end and three standard serial port connectors (DB9) on the other end.

  • Page 15: Output Characteristics

    All output connections must use properly grounded and shielded cable. The Trigger Signal and Strobe Output for M-Series cameras are separate and not part of the M-Series Processor inputs and outputs. See M-Series Cameras on page 3-1 for details.
  • Page 16 Pullup Jumpers to Enable Sourcing M-Series QuickStart Guide Pullup Jumpers to Enable Sourcing Jumpers JP1 through JP16 enable and disable the connection between their respective Output and the “Outputs Sourcing Pullups VCC” signal on the terminal block. If a jumper is in the Enable position, the Sourcing VCC is connected to the Output and it provides a sourcing signal (it is normally low and goes high when On).
  • Page 17 M-Series QuickStart Guide General Purpose Output Circuit (Sourcing) General Purpose Output Circuit (Sourcing) This is not an output voltage source. An external power source must be con- nected to VCC, as indicated. Note: To turn PLC On, turn M Output Off. To turn PLC Off, turn M Output On.
  • Page 18 Datalogic M1xx Camera M-Series QuickStart Guide Terminal Name Signal Notes Trigger In** Camera Trigger In 0 to +24 VDC recommended Maximum +30 VDC As sinking input Off: 0 to +1.4 VDC On: +2.2 to +24 VDC; 5 to 15 ma As sourcing input (see Trigger Pullup +VCC) Off: +2.2 to +24 VDC;...
  • Page 19 M-Series QuickStart Guide Datalogic M1xx Camera M1xx Strobe Trigger Output Circuit M1xx Terminal Connections Page 17 Datalogic Automation, Inc.
  • Page 20 Datalogic M2xx and M3xx Camera M-Series QuickStart Guide Datalogic M2xx and M3xx Camera To connect M2xx and M3xx camera power, trigger signals, and strobe outputs, use cable 606- 0673-xx (12-pin to HD-15) with terminal block 661-0400. Terminal Signal Name Notes...
  • Page 21 M-Series QuickStart Guide Datalogic M2xx and M3xx Camera M2xx and M3xx Trigger In Circuit M2xx and M3xx Strobe Trigger Out Circuit Page 19 Datalogic Automation, Inc.
  • Page 22 Datalogic M5xx Camera M-Series QuickStart Guide M2xx and M3xx Terminal Connections Datalogic M5xx Camera To connect the M5xx, use terminal block 661-0401 with cable 606-0673-xx (12-pin to HD- 15 camera I/O) and cable 606-0674-xx (6 pin to DB9 camera power). For details about pro- gramming the Line Trigger, refer to the Impact Reference Guide (843-0093).
  • Page 23 M-Series QuickStart Guide Datalogic M5xx Camera Terminal Signal Name Notes Input 2 - No Connection DO NOT USE Input 2 + Single Line Trigger As sinking input Off 0 to +0.8 VDC Phase A Line Trigger On: +2.0 to +5 VDC...
  • Page 24 Datalogic M5xx Camera M-Series QuickStart Guide M5xx Frame Trigger Circuit M5XX Single Line Trigger Circuit Datalogic Automation, Inc. Page 22...
  • Page 25 M-Series QuickStart Guide Datalogic M5xx Camera M5XX Quadrature Encoder Line Trigger Circuit M5XX Trigger Terminal Connections Page 23 Datalogic Automation, Inc.
  • Page 26 Datalogic M5xx Camera M-Series QuickStart Guide Datalogic Automation, Inc. Page 24...

This manual is also suitable for:

M seriesMx20Mx40Mx80
