- Page 1 Micro2 Series Quick Start Guide Quick Start Guide...
-
Page 2: Getting Familiar With Your Micro2
This document provides an easy reference for operating and maintaining the Micro2 Series Mobile Printer. A complete documentation for this printer series is provided by the VersaJet Micro2 Series User Guide available on the Internet at http://www.cino.com.tw. 10. Media Compartment Cover 1. -
Page 3: Installing And Charging The Battery
Installing and Charging the Battery Ins talling the Battery Pull up the battery door. pen the battery door. Push the battery door latch to the left. Slide the battery pack into Close the battery door. Push the battery door the battery compartment. latch to the right. -
Page 4: Loading The Media Roll
Loading the Media Roll The Micro2 is designed to print either receipt or label. Please decide the printing mode, media type and sensor type before loading the media roll. Printing Mode The Micro2 supports both line (default) mode and page mode. Media Type Continuous Receipt, I-Mark Media and Gap Label can be applied to Micro2. -
Page 5: Conduct Length Measurement
Conduct Length Measurement You can conduct length measurement by using reflective sensor (default etting) for I-Mark media roll or transmissive sensor for gap label roll. Please refer to the VersaJet Programming Reference for changing the sensor from reflective to transmissve, if the gap label roll is used. 1. -
Page 6: Verify Micro2 Is Working
Using Your Micro2 Connecting the Printer Via Bluetooth Please refer to the VersaJet Micro2 User’s Guide on the Internet at www.cino.com.tw for establishing Bluetooth connection. Connecting the Printer Via RS232 Host Interface Connector 1. Plug the connector of the RS232 cable into the Host Interface Connector of the printer. -
Page 7: Using The Accessories
Using the Accessories Using the Belt Clip This belt clip accommodates the users to carry the printer by wearing it on the belt. Before locking the belt clip to the printer, please screw the belt buckle to the back of the printer first. Then follow the step 2-4 to lock the belt clip to the printer. -
Page 8: Battery Charging Indicator
Indications Beeping Indications Beeping Indications Description 3 short beeps in ascending tone Power on indication 3 short beeps in descending tone Power off indication 1 beep at 5 seconds intervals 20%~30% of battery remains 2 beeps at 5 seconds intervals 10%~20% of battery remains 2 long beeps Error warning... -
Page 9: Warning And Error Messages
Warning and Error Messages LED1 LED2 LED3 LED4 Description Orange Green Paper jam (*1), or Label length measurement error (*2) Start blinking after steady on for 10 seconds Orange Green Green Media compartment cover opened (*3) Start blinking after steady on for 10 seconds Orange Green Green... -
Page 10: Maintenance And Troubleshooting
Maintenance and Troubleshooting Cleaning Instructions Please refer to following procedures and figures to clean the printer. 1. Power off Micro2. 2. Open the Media Compartment Cover. Print Head 3. Remove the Media Roll. Tear Bar Platen Roller Areas Methods Use the cleaning pen or a cotton swab moistened with isopropyl Print Head alcohol to clean the surface of the print head from end to end. -
Page 11: Product Disposal
Don’t disassemble or modify a rechargeable battery pack. Otherwise, it will leak, overheat or crack. Always use a Cino charger to charge. The use of any other kind of charger may damage the battery pack. Remove the battery pack from the printer if you will not use it for a long time.
