Clipcomm CP-100 User Manual

Voip phone
Hide thumbs
Table of Contents

Advertisement

Quick Links

Keison Products
www.keison.co.uk
sales@keison.co.uk
Tel: +44 (0)1245 600560

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Clipcomm CP-100

Summary of Contents for Clipcomm CP-100

  • Page 1 Keison Products www.keison.co.uk sales@keison.co.uk Tel: +44 (0)1245 600560...

  • Page 2: Table Of Contents

    Contents 1. CP-100/100D FEATURES..........................2 2. PARTS CHECKLIST ............................3 3. INSTALLATION ............................... 4 4. CONTROLS AND FUNCTIONALITIES ....................... 6 5. PHONE CONFIGURATION..........................8 6. MAKING / RECEIVING PHONE CALLS ....................22 7. ADDITIONAL FUNCTIONS ......................... 23 8. WIRELESS-LAN EXTENSION........................29 9.

  • Page 3: Cp-100/100D Features

    1. CP-100/100D Features 1. CP-100/100D Features Stand-alone H.323/SIP-based VoIP phone. Easy menu system with 16*2 character LCD and keypad. Applicable for private Internet line, ADSL (by PPPoE) and Cable Modem (by DHCP). Operable as a switching hub in a 2 IP environment.(CP-100D only) Automatic Answering Machine function.

  • Page 4: Parts Checklist

    2. Parts Checklist 2. Parts Checklist Please check to ensure that you have all the following components in the package: Item Quantity Usage CP-100/100D CP-100/100D Main Body User Manual This user manual Handset CP-100/100D Handset Power Adaptor DC 12V power supply...

  • Page 5: Installation

    3. Installation 3. Installation Check the location of each port and follow the below instruction to install your CP-100/100D correctly. 3.1. CP-100 ① Connect handset to your CP-100 body. ② Connect UTP cable linked with ADSL/cable modem/hub to the ‘LAN’ port at the rear panel of your CP-100/100D.
  • Page 6 ④ Connect the LAN cable from PC’s LAN port to the ‘PC’ port to use NAT. (Figure’s “B”) ⑤ Connect the wired headset. (Figure’s “D”) Caution: Please be sure to use only the supplied AC power adapter. Otherwise, proper function of your CP-100/100D is not guaranteed. Keison Products www.keison.co.uk sales@keison.co.uk...

  • Page 7: Controls And Functionalities

    4. Controls and Functionalities 4. Controls and Functionalities Keison Products www.keison.co.uk sales@keison.co.uk Tel: +44 (0)1245 600560...
  • Page 8 Controls Functionality ♦ Used for normal telephone functionality. Handset ♦ Displays system status and user information. LCD display ♦ Restarts network access via ADSL, DHCP, Static IP mode. START ♦ Deactivates your handset microphone. MUTE ♦ Initial state: activates main menu. ♦...

  • Page 9: Phone Configuration

    After installation, you need to configure your CP-100/100D according to your environment. You can configure your CP-100/100D by either the LCD menu or internal Web interface. From now on, LCD and keypad based configuration method is going to be explained. For Web based configuration, please refer to section 5.6 “Internal Web Interface.”...
  • Page 10 2: DHCP 3: ADSL ② Select “1:Static IP”, if you want to configure your CP-100/100D in static IP environment. ③ Select “1:IP Address” and enter required IP address using keypad. To confirm or cancel your input, press ENTER or END button. You can enter dots (“.”) in the IP address using # button.
  • Page 11 ③ Select “Yes” and press ENTER. Your CP-100/100D will automatically restart in DHCP client mode after a few seconds. 5.1.3. ADSL Setting ① Select MENU “3: Phone Mgmnt” “1: Set Network” “2:Change Config”. 1: Static IP 2: DHCP 3: ADSL ②...
  • Page 12 5.2. VoIP Configuration - H.323 version You need to subscribe for an ITSP (Internet Telephony Service Provider) to use versatile VoIP services. You can use this VoIP configuration menu to configure your CP-100/100D according to your local ITSP’s requirements. To begin VoIP configuration using LCD and keypad, select MENU button “3:Phone Mgmnt”...
  • Page 13 5.2.3. Restart System after VoIP Configuration ① When you press CLEAR button to exit VoIP configuration sub menu, your CP-100/100D asks you whether to restart. By selecting “Yes,” your CP-100/100D will restart with the new VoIP configuration. If you select “No,” the modified configuration is stored and takes effect only after restarting.
  • Page 14 5.3. VoIP Configuration - SIP version You need to subscribe for an ITSP (Internet Telephony Service Provider) to use versatile VoIP services. You can use this VoIP configuration menu to configure your CP-100/100D according to your local ITSP’s requirements. To begin VoIP configuration using LCD and keypad, select MENU button “3:Phone Mgmnt”...
  • Page 15 Success 2: Outbound Proxy 192.168.0.1 3: Registrar Server 192.168.0.1 4: SIP Server www.clipcomm.co.kr 5: Expiry[sec] 3600 ② “1:Registration” shows the state of the registration. ③ Select “2:Outbound Proxy” and enter the address of outbound proxy. Outbound Proxy ④ Registrar Server, SIP Server, and Expiry can be set by the similar procedure. Usually, registrar server is same as outbound proxy.
  • Page 16 ② Select “1:User ID” and enter proper number for SIP. To confirm or cancel your input, press ENTER or END button. User ID is used for phone number after registration. [1] User ID 20002 ③ Display name and password can be set by similar procedure. Display name is user name, and password is PIN code for registration to registrar.
  • Page 17 ② After selecting “1:NAT Function”, select “2:STUN Address”. Enter the address of STUN server. This address can be FQDN. [a] STUN Address clipcomm.co.kr:5088 5.3.4.2. NAT Traversal without STUN server ① If you use NAT traversal without STUN server, you should know the external IP address of NAT router.

  • Page 18: Call Forwarding

    5.4. Call Forwarding You can configure that CP-100/100D can forward incoming call to selected number. ① Select Menu ”3:Phone Mgmnt” ”3:Call Forward” 1: Setting Disable 2: Forwarding No. ② Select “1:Setting”, and choose condition when you want to enable call forwarding function.

  • Page 19: Changing Password

    5.5. Changing Password ① A default password of CP-100/100D is set as “0000.” We recommend that you change this default password to prevent any unwanted access to your phone. To change the 4-digit password, select MENU ”3:Phone Mgmnt”...
  • Page 20 CP-100/100D but will not take effect until restarts. Note: Please refer to the following terminology for your network setting. Static IP: If you want to assign static IP address to your CP-100/100D, choose “Static IP” radio button and fill the following items.
  • Page 21 NAT Router IP : If you are using NAT traversal, you can set external IP address of NAT router. 5.6.2.3. SIP setting If your CP-100/100Dis equipped with SIP firmware, you have to change the configuration related to the URI and proxy server. Please inquire of the administrator about the specific parameters.
  • Page 22 NAT Timer: you can set time to send packets for keeping NAT session 5.7. Wireless LAN Configuration Before using the wireless LAN functions of your CP-100/100D, make sure that an interoperable wireless LAN PC card is used. An interoperable 802.11b PC card is based on Intersil’s Prism chipset and original Intersil firmware.

  • Page 23: Making / Receiving Phone Calls

    6. Making / Receiving Phone Calls 6. Making / Receiving Phone Calls 6.1. Making VoIP Phone Calls 6.1.1. Calling by IP Address in VoIP Service Mode ① Pick up the handset (or press SPEAKER button). ② Enter callee’s IP address. Use “#” button for dot (“.”) between IP numerals. Use CLEAR button to correct telephone number.

  • Page 24: Additional Functions

    7. Additional Functions 7. Additional Functions There are many additional functions besides just making or receiving calls in your CP-100/100D. This chapter explains how to invoke and use the additional functions. 7.1. Automatic Answering Press MENU select “1:Auto answer” menu to configure and manage automatic answering functionality of your CP-100/100D.
  • Page 25 New msg : 0 Total msg : 1 9/25 05:26 PM 192.168.0.186 ③ To adjust volume during message playing, use VOL (▲,▼) buttons. ④ Press ENTER button for next message and MENU for previous message. ⑤ To delete current message, press CLEAR button. 7.1.3.
  • Page 26 7.2.2. Searching for a Phonebook Entry You can find a phonebook entry either by name, phone number or phonebook entry number. ① Select “4:Search”. ② Select a sub-menu among “All Entries”, “By Name”, “By Phone No.” or “By Entry No.” ③...
  • Page 27 ENTER or END button. 7.3.4. Time Zone ① Using this menu, you can set proper time zone of your location. The CP-100/100D displays current wall-clock time according to the time information from a time-server interpreted by this time zone. To set current time-zone of your CP-100/100D, select “4:Time Zone.”...
  • Page 28 __h:__m ⑤ Select “3:Alarm Melody”, then, you can change alarm melody and volume. 7.3.6. Locking your CP-100/100D ① To prevent others from using your CP-100/100D, you can lock your phone. To enable phone locking, select “6:Lock Phone.” Input Passwd ② After entering password, select option to restrict use of phone ③...
  • Page 29 7.4. Firmware Management Your CP-100/100D automatically checks the updated version. ① Press MENU and select “5:Firmware” to enter the firmware update menu of CP-100/100D. 1:Firmware Ver. 2:Update 3:Update Server ② Select “1:Firmware Ver.” to check the current firmware version. ③ Select “3:Update Server” to check the IP address of update server.

  • Page 30: Wireless-Lan Extension

    8. Wireless-LAN 8. Wireless-LAN Extension Insert Clipcomm’s wireless LAN extension card into the CP-100/100D PCMCIA extension slot as shown in the figure below. After inserting the IEEE 802.11b wireless LAN extension card, the CP- 100/100D can be used as a wireless LAN access-point or wireless LAN station. For its configuration, refer to the section “5.7 Wireless LAN Configuration”...

  • Page 31: Firmware Upgrade

    100/100D.fls”) to the CP-100/100D. Its IP address is 192.168.0.36. Enter “admin” as the user name and type in the password that is set in the VoIP configuration web page of the CP-100/100D. The default password is “0000.”The system will reboot automatically when upgrading the firmware by FTP is completed.
  • Page 32 Firmware upgrade by UTP cable is performed by the following procedure: ① Turn-off your CP-100/100D. ② Connect your CP-100/100D and PC with UTP cable. You can connect PC and “LAN” port of CP- 100/100D directly with UTP cable. Or you can configure that PC and CP-100/100D are connected to same HUB.

  • Page 33: Character Input Using Keypad

    10. Character Input Using Keypad 10. Character Input Using Keypad In character input mode during menu manipulation, you can change current character set by pressing MENU button repetitively. The character set circulates as follows: English upper case ( [A] ) / English lower case ( [a] ) / Numeric ( [1] ) / Symbolic( [@] ) 10.1.
