Summary of Contents for Clipcomm CWP-100
-
Page 2: Table Of Contents
Table of Contents 1. CWP-100 OVERVIEW ... 4 2. PRODUCT DESCRIPTION... 5 3. HARDWARE OVERVIEW... 6 4. LCD ICON OVERVIEW ... 8 5. INSTALLATION OVERVIEW... 9 5.1. CWP-100 I ... 9 NSTALLATION 6. BASIC CONFIGURATION ... 10 6.1. W LAN A... - Page 3 7.3.3. Call hold... 19 7.3.4. Call mute ... 19 7.3.5. Call Transfer... 19 7.3.6. Call Waiting ... 20 8. SUPPLEMENTARY SERVICES... 21 8.1. P ... 21 HONEBOOK 8.1.1. Register ... 21 8.1.2. Search ... 22 8.1.3. Delete... 22 8.2. C ...
- Page 4 10.1. F IRMWARE PGRADE VIA 10.2. F IRMWARE PGRADE VIA 10.3. S YSTEM ESET BY ACTORY 11. CHARACTER INPUT USING KEYPAD ... 39 11.1. E ... 39 NGLISH HARACTER 11.2. S YMBOLIC HARACTERS ... 36 ISPLAY FTP ... 37 ... 38 ALUE ...
-
Page 5: Cwp-100 Overview
1. CWP-100 Overview 1. CWP-100 Overview Conform to Wireless LAN standard 802.11b. Operate on wireless LAN AP (Access Point) with static IP, ADSL and dynamic IP(DHCP). Provide VoIP calls. Provide CID service. Provide NAT traversal function that enables external calls with private IP address behind NAT network environment. -
Page 6: Product Description
Please check and make sure that you have the following package contents. Item CWP-100 Body Charger Battery Power Adaptor (DC 5V 2A) User Manual Quantity Description CWP-100 main body CWP-100 proprietary charger CWP-100 proprietary Battery Power supply device User guide that explains features, functions and implementation examples... -
Page 7: Hardware Overview
3. Hardware Overview 3. Hardware Overview... - Page 8 Activate the call with the dialed number. Return to the main menu. Deactivate the call. Press this button for few seconds to turn the CWP-100 on or off. Adjust the receiver volume during the call. Adjust the ring melody volume on the melody setting menu.
-
Page 9: Lcd Icon Overview
4. LCD Icon Overview The descriptions of the icons displayed on CWP-100 LCD are as below. Please refer to the table below for the descriptions of each icon. Icons Category AP connection status Icon Proxy server register status Icon Vibration mode Icon... -
Page 10: Installation Overview
5. Installation Overview 5. Installation Overview Please check the parts of the CWP-100 and then follow the steps bellow to instal CWP-100 properly. Caution: Use only the power adaptor, charger and battery supplied by the provider. Using other power adaptor, charger and battery may cause the CWP-100 to deteriorate the voice quality and malfunction. -
Page 11: Basic Configuration
To set the system with LCD and keypad, press ”LEFT SOFT KEY”. Then you will enter the main menu and see the displays as below. 6.1. Wireless LAN Access Point Scan Before you use the CWP-100, you need to get connected to the wireless LAN access point. Follow the steps as MENU “3: System Setting”. -
Page 12: System Setting
If the CWP-100 succeeds in searching the AP, the CWP-100 LCD display “AP Scan Success” and restart automatically. If there is no AP around or if the CWP-100 fails in searching the AP, the CWP-100 LCD display “AP Not Found” and return to the previous menu. -
Page 13: Current Setting
Follow the steps as MENU “3: System Setting” 6.2.1. Current Setting ① Follow the steps as MENU “3: System Setting” the current settings. You can check current network mode and network parameters. 6.2.2. Static IP Setting ① Follow the steps as MENU ②... -
Page 14: Dynamic Ip (Dhcp) Setting
③ Select “1: ADSL ID” and input the ADSL ID. ④ In the same way, input the ADSL password. ⑤ Select “3: Connect ADSL” and press ENTER button. Then the CWP-100 will automatically attempt the ADSL connection. ⑥ In case ADSL connection fails, follow the steps as MENU connection. -
Page 15: Oip Setting
You need to register with the Internet Telephony Service Provider (ITSP) to utilize various VoIP services. You may set the CWP-100 as your ITSP requests. To set the system with the LCD and the keypad, follow the steps as MENU Setting”. -
Page 16: Name Setting
Follow the steps as MENU will see the current codec for a moment and then see the menu as below. You may select the codec that you wish to use and then restart the CWP-100 to utilize the selected codec. - Page 17 Follow the steps as MENU “4: NAT Traversal”. 6.3.4.1. NAT Traversal using STUN server ① To use NAT traversal function with the STUN server, follow the steps as MENU “1: NAT Function” “2: Use STUN”. ② Follow the steps as MENU server address.
- Page 18 6.3.4.3. NAT Session Timer When using the NAT traversal function, you need to set the session time for transmitting the packet periodically so that the CWP-100 maintains the NAT router and the NAT session. Follow the steps as MENU “4: NAT Traversal”...
-
Page 19: Basic Services
7. Basic Services 7.1. Making a Phone Call ① Dial the phone number that you wish to make a call. In case making a direct call to the devices’ IP address, press “LEFT SOFT KEY” to and then press 1 to express “.” between the numbers. Press CANCEL button to edit the numbers. -
Page 20: Extra Functions On Call
⑤ If you press SEND during the call with person B, you can talk to person A again. In the meantime, person B will be in the waiting mode. ⑥ If you press END during the call with person B, the CWP-100 will end the call. Person A and person... -
Page 21: Call Waiting
7.3.6. Call Waiting When there is an incoming call while you are on the phone, the CWP-100 can put the incoming call in the waiting mode and do not reject the call. To enable call waiting, you need to use the embedded web interface. -
Page 22: Supplementary Services
8. Supplementary Services 8. Supplementary Services The CWP-100 provides various supplementary services addition to basic services. 8.1. Phonebook You can save and delete the phone number on the phonebook. Follow the steps as MENU Phonebook”. 8.1.1. Register ① Follow the steps as MENU ②... -
Page 23: Search
You can delete the registered phone number. ① Follow the steps as MENU ② If you select “1: One By One,” the CWP-100 display all the saved phone numbers. Select the phone number that you wish to delete and then press “Enter”. -
Page 24: Call History
8.2.2. Delete Calls ① Select “4. Delete Call”. ② If you select “1. One By One”, the CWP-100 display all the saved phone numbers on the call history. Select the phone number that you wish to delete and then press Enter button. -
Page 25: Melody Setting
8.3.2 Screen Message Setting ① Select “2. Screen Message”. ② If you select “1: User Defined”, the CWP-100 display the main screen message and you can edit the screen message here. ③ If you select “2: Registration ID”, the default phone number will be set as the main screen message. -
Page 26: Time Zone Setting
8.3.4. Time Zone Setting You can set the time zone according to your region. Select “4: Time Zone”, then CWP-100 will display the current wall-clock time according to the time information from the time server interpreted by this time zone. -
Page 27: Firmware Management
② Select “1: Setting” and then choose the conditions for enabling the call forwarding functions. ③ Select “2: Forward NUM” and then input the phone number to forward the call. ④ Once you enable the call forwarding function, the CWP-100 will display “CallForward ON” on the LCD main screen. -
Page 28: Configuration With Internal Web Interface
CWP-100 is available for networking after the configuration with the keypad, you can use the web interface by inputting the CWP-100 IP address on the web browser. With the web interface, you can check the current settings and set the parameters that are hard to configure with the phone buttons. -
Page 29: Network Configuration
④ The CWP-100 will restart with the new parameters. 9.1.2. Miscellaneous Network Configuration You can configure miscellaneous network configuration parameters besides the CWP-100 IP network mode. Parameter The user can assign up to two DNS addresses. In this case, the... -
Page 30: Oip Configuration
9.2. VoIP Configuration VoIP configuration is required to enable VoIP calls. Please contact your service provider or the network administrator for more information on VoIP configuration. Select “System Configuration” ① Set each configuration parameters with appropriate value. ② Parameter Standard SIP server name for service area, which is also called SIP Server SIP Domain. -
Page 31: Supplementary Function Configuration
9.3. Supplementary Function Configuration The CWP-100 provides various additional functions. 9.3.1. Call Waiting The CWP-100 enables the user to accept incoming call from a third party during an active call. By default, it is enabled. Parameter The user hears a beep when there is an incoming call from a third party enable during the call. -
Page 32: Incoming Call Processing Configuration
The CWP-100 provides the services as below for incoming calls. 9.3.3.1. Auto Answering The CWP-100 answers the incoming call automatically and records the message that the caller leave. (You can use Auto Answering function only with G.723.1A codec.) The description and default value for auto answering function is as follows. -
Page 33: Outgoing Call Processing Configuration
The CWP-100 provides the services as below for outgoing calls. 9.3.4.1. Dial Plan The CWP-100 edits the outgoing phone number according to the rules that the user assigns. The user can set up to 20 entries for dial plan. Parameter The pattern that the user input while dialing. - Page 34 In case the user dials the phone number that starts with 00 and press ‘#’ to make an outgoing call, the CWP-100 will eliminate the first 2 digits, add “555” at the front as prefix and add “1004” at the end as postfix and then attempt the outgoing VoIP call with the final phone number.
-
Page 35: Nat Traversal Configuration
In case the user dial “5550001” and press “#” to make an outgoing call; The CWP-100 will not edit the final dialing number since there is no pattern that coincide with the dial plan entries, and attempt the outgoing call to “5550001”... - Page 36 NAT Router IP for Manual The user should assign the SIP local port, RTP port, CWP-100 IP address etc that the CWP-100 uses behind NAT router. Setting up these ports is called Port mapping, which enables the CWP-100 to run behind the NAT router.
-
Page 37: Firmware Upgrade And Factory Reset
You easily upgrade the new firmware with a simple process. 10.1. Firmware Upgrade via Display Menu You can upgrade the firmware with the CWP-100 LCD display menu. This process is available only when the network is in normal state and connected properly. -
Page 38: Firmware Upgrade Via Ftp
The following example shows how a command line FTP client is used to upload new firmware (“CWP- 100.fls”) to the CWP-100 when its IP address is 192.168.0.36. Enter “admin” as the user name and type in the password that is set on the VoIP configuration web page. The default password is “0000.”... -
Page 39: System Reset By Factory Value
After booting the CWP-100 successfully, follow the steps as [MENU] Firmware” “1: Load Default”. Then the CWP-100 will ask to input the password for resetting the system. Input the correct password and then press ENTER. Then the CWP-100 will automatically reboot with the factory value. -
Page 40: Character Input Using Keypad
11. Character Input Using Keypad 11. Character Input Using Keypad In character input mode during menu manipulation, you can change current character set by pressing SOFT Key 1 repetitively. The character set circulates as upper case letter, lower case letter, numeric character and symbolic character.
