Thuraya FDU-2500 User Manual

Fdu-2500 thuraya
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Table of contents

Introduction ....................................................................................
Package Contents...........................................................................
Installation Instructions.....................................................................
Antenna Installation............................................................ 5
Installing Satellite Antenna................................................... 5
Installing GPS Antenna......................................................
External Accessories ......................................................... 6
Getting Started................................................................................. 7
Connection Interface............................................................ 7
Setting up FDU-2500......................................................... 8
Using FDU-2500 as a desktop unit....................................... 8
Using FDU-2500 as a wall mounted unit................................. 8
Mounting FDU-2500 on the wall..........................................
Connecting Satellite Antenna.............................................
Connecting GPS Antenna...................................................
Connecting Extension Phone to FDU-2500........................... 9
Docking Thuraya Terminal in FDU-2500 .............................. 10
Undocking Thuraya Terminal from FDU-2500........................ 11
Receiving / Making Calls.....................................................................12
Important...........................................................................12
Receiving Calls ..................................................................12
Making Calls ......................................................................13
Ending Calls ..................................................................... 13
Transferring Calls ...............................................................14
Volume Control ..................................................................14
Receiving / Sending Fax Message...................................................... 15
1
.................................16
3
4
5
6
8
8
9
9
10

Advertisement

Table of Contents
loading

Related Manuals for Thuraya FDU-2500

Summary of Contents for Thuraya FDU-2500

  • Page 1: Table Of Contents

    Getting Started……………………………………………………………………… 7 Connection Interface…………………………………………………… 7 Setting up FDU-2500………………………………………………… 8 Using FDU-2500 as a desktop unit………………………………… 8 Using FDU-2500 as a wall mounted unit…………………………… 8 Mounting FDU-2500 on the wall…………………………………… Connecting Satellite Antenna……………………………………… Connecting GPS Antenna…………………………………………… Connecting FDU-2500 to Power Supply Adapter………………...
  • Page 2 Receiving / Sending Data Calls …………………………………………………17 Receiving Data Calls …………………………………………………17 Sending Data from PC ………………………………………………17 Charging the Thuraya Terminal Battery …………………………………………17 Code Locking Function ……………………………………………………………18 How to set up the Code locking function…………………………18 How to make a call …………………………………………………19 In the case of Forgetting the PIN Code……………………………20 Supplementary Services …………………………………………………………20...

  • Page 3: Introduction

    The Thuraya terminal when used with FDU-2500, becomes a communication center providing voice, fax and data communication. The built-in battery charger in FDU-2500 makes it possible for you to charge your Thuraya terminal while locked in the FDU. Attention Do not connect FDU-2500 with other products such as PSTN or general telephone...

  • Page 4: Package Contents

    Package Contents FDU-2500 Package consists of the following FDU-2500 with Auxiliary handset AC/DC Power adapter Satellite antenna and mounting adapter Satellite antenna cable (25meter) GPS antenna with cable (25meter) USB driver CD, USB cable, RJ-11cable and FDU-2500 User Manual...

  • Page 5: Installation Instructions

    Installation Instructions After unpacking and ensuring that carefully. If you encounter any difficulty FDU-2500 and all its accessories are in installation, contact your service intact and present, proceed with the provider for assistance. installation. Please read the instructions Antenna Installation...

  • Page 6: Installing Gps Antenna

    “GPS” on the FDU-2500. top for fixing the antenna. External Accessories FDU-2500 needs to have external accessories for full functionality. Please make sure that you have the following: Group 3 Fax machine for Thuraya terminal with active sending/ receiving Fax.

  • Page 7: Getting Started

    FDU-2500 is intended to be used as a desktop or wall-mounted phone while the Thuraya terminal is docked. Slots are provided at the base of the unit to allow FDU-2500 to be hooked securely to a wall. Interfaces for connecting external equipments such as Group 3 fax machine and PC are provided at the back side of the unit.

  • Page 8: Setting Up Fdu-2500

    Setting up FDU-2500 Using FDU-2500 as a desktop unit To use FDU-2500 as a desktop unit, find an appropriate location on your desktop where you can easily access the unit. Make sure that you have an electrical outlet nearby for powering up FDU-2500.

  • Page 9: Connecting Gps Antenna

    FDU-2500. coaxial Tighten the connector by antenna cable to the connector turning it clockwise. marked “GPS” on the Connecting FDU-2500 to Power Supply Adapter Plug Power Supply Adapter connector into the DC IN connector on The power LED on the FDU-2500.

  • Page 10: Connecting Group 3 Fax Machine To Fdu-2500

    RJ-11 interface Note: Contact your service provider to marked “FAX”. check for Fax service on the SIM Card. Plug one end of the RJ-11 Connecting a PC to FDU-2500 through USB port your FDU-2500 interface of FDU-2500. connecting a PC through the USB interface on FDU-2500.

  • Page 11: Undocking Thuraya Terminal From Fdu-2500

    FDU-2500, Locker device is installed for mechanical locking. Thuraya terminal can’t be undocked until the locker is unlocked. rst, find the status of FDU-2500 Locker device, If the Locker is locked, unlock it and do the next steps: Allow the...

  • Page 12: Receiving / Making Calls

    Receiving a call. Thuraya terminal display. FDU-2500 is switched ON. Important Thuraya terminal is switched When FDU-2500 is switched on it would SIM card is valid. take upto ten seconds to reach the The connections are done normal working condition. FDU-2500 is...

  • Page 13: Making Calls

    Making Calls You can use the FDU-2500 for making Method 2 : outgoing calls. Make sure that FDU-2500 Dial the destination number is activated before proceeding with the using Thuraya terminal keypad call. while the Auxiliary handset is on the cradle.

  • Page 14: Transferring Calls

    Speakerphone, auxiliary handset, and Switch ON FDU-2500. ringer tone using the Volume Up and Press the Volume Up/Volume Volume Down buttons on FDU-2500. Down button repeatedly to > Adjusting auxiliary handset volume increase /decrease the ringer Pick up the Auxiliary handset.

  • Page 15: Muting Microphone During Speakerphone Call

    > Muting a speakerphone call Press the Mute button again. Receiving / Sending Fax Message You can use FDU-2500 for receiving and through a PC connected at the USB or sending fax messages. This can be done DTE interface of FDU-2500. For sending...

  • Page 16: Receiving / Sending Fax Through Pc

    Dock Thuraya terminal in you must have appropriate fax software FDU-2500. installed in your PC. Connect the PC to the USB or DTE interface of FDU-2500. Note Switch ON FDU-2500. While sending fax through PC connected Invoke the PC fax software.

  • Page 17: Receiving / Sending Data Calls

    (Look up the S/W guide book shown below. for the specific explanation). Charging Thuraya Terminal Battery FDU-2500 comes with a built in battery FDU will start charging the battery. The charger for charging the Thuraya terminal. charging status will be indicated by the...

  • Page 18: Code Locking Function

    This How to set up the Code Locking Function is successfully enabled. The PIN Code of FDU-2500 is set to > Disable PIN Code Locking Function “0000” as a default. Connect the extension phone to RJ-11 interface marked >...

  • Page 19: How To Make A Call

    How to make a call Calling Methods with PIN Code disabled Voice Call EXT interface Telephone Number → # FAX Call FAX interface FAX Number → # → 32 → # → Start Button PC FAX S/W : FAX Number Data Call USB interface Running PC S/W...

  • Page 20: In The Case Of Forgetting The Pin Code

    In the case of Forgetting the PIN Code If you forget the PIN Code that you set should remember the PIN Code you set up, you should reset your FDU-2500 by up, and write it down in a safe place. visiting the service center. So, you...

  • Page 21: Troubleshooting

    Do not attempt to open it. Mishandling of enjoy this product for many years. the device may damage it. Do not use or store FDU-2500 in dusty, dirty areas. Do not drop, apply pressure or shake it. Rough handling can break internal circuit Do not store it in hot areas.

  • Page 22: Common Problems

    Unable make/receive - Check the PIN Code. calls - Dial through Thuraya terminal if OK, then check the RJ-11 connection. - If Extension Phone is not working, try with Auxiliary Handset of FDU-2500 and confirm it’s working. If you can make a call with the auxiliary handset of FDU-2500, then check Extension phone, else call the service provider.

  • Page 23: Led Indications

    FDU-2500 is powered ON. FDU-2500 is Red. Thuraya terminal battery is charging. The BATT LED on top middle of Thuraya terminal battery is fully charged. FDU-2500 turns Green. Speakerphone LED is flashing Incoming call indication. The Red LED on the Mute button The microphone is OFF.

  • Page 24: Warranty

    Warranty Limited Warranty FDU-2500 This Limited Warranty is provided to the original purchaser of FDU-2500. This Limited Warranty is non-transferable in nature. Warranty Coverage and Service APSI warrants all new FDU-2500 terminals to be free from defects in material and workmanship under normal use and wear, for a period of one year (1 year) from the date of purchase.
