Replacement Parts - White Outdoor 606 Operator's Manual

11
Replacement
Parts
For parts and/or
accessories refer to
customer support on
page 2.
This Operators
Manual covers a range
of product specifications
for various models.
Characteristics and
features discussed
and/or illustrated in
this manual may not be
applicable to all models.
MTD LLC reserves the
right to change product
specifications, designs
and equipment without
notice and without
incurring obligation.
NOTE: Download a complete Parts Manual free of charge at www.mtdcanada.ca
or phone (800) 668-1238 to purchase a Parts Manual. Be sure to have your model
number and serial number ready. These can be found on the model plate located
under the seat. Refer to page 2 for more information regarding locating your model
and serial numbers.
Automatic Lawn Tractor
Upper Drive Belt (Transmission)
Lower Drive Belt (Transmission)
Drive Belt (Mowing Deck) 42" Deck
Drive Belt 90.24" Lg.(Mowing Deck) 46" Deck
Drive Belt 79.10" Lg.(Mowing Deck) 46" Deck
Deck Blade (42" Deck) two each
Deck Blade (46" Deck) Center Blade (one ea.)
Deck Blade (46" Deck) Outer Blades (two ea.)
Deck Spindle (42" Deck) two each
Deck Spindle (46" Deck) (three ea.)
Deck Wheel 5.0 x 1.38 (two each)
Battery
Tire (Front) 15" x 6" x 6" Square Shoulder
Tire (Rear) 20" x 8" x 8" Square Shoulder
Hub Cap
Fuel Tank Cap
Throttle/Choke Control Cable (Kohler Single Cylinder)
Choke Control Cable (Kohler Twin Cylinder)
Throttle Control Cable (Kohler Twin Cylinder)
Discharge Chute Assembly
WARNING: If a safety feature is not functioning properly, do not use the tractor.
Contact your authorized ervice dealer or call (800) 668-1238.
754-0468
754-0467
754-04045
754-04122
754-0349
742-0616A
742-0612A
742-0611A
618-04456
618-0625
734-0973
925-1707D
734-1731
734-1730
731-2290A
951-3111
746-4364
746-1085A
746-04417
931-1032B
3
