DIGITAL VIDEO CAMERA
GR-DVL145
Please visit our Homepage on the World Wide Web and
answer our Consumer Survey (in English only):
http://www.jvc-victor.co.jp/english/index-e.html
For Accessories:
http://www.jvc-victor.co.jp/english/accessory/
INSTRUCTIONS
CONTENTS
AUTOMATIC DEMONSTRATION
GETTING STARTED
RECORDING & PLAYBACK
RECORDING ................................ 15 – 18
PLAYBACK .................................. 19 – 22
ADVANCED FEATURES
FOR RECORDING .......................... 24 – 31
USING MENUS FOR
DETAILED ADJUSTMENT ............. 32 – 37
DUBBING .................................... 38 – 39
USING THE OPTIONAL REMOTE
CONTROL UNIT .......................... 40 – 44
SYSTEM CONNECTIONS ........................ 45
REFERENCES
DETAILS ............................................ 47
TROUBLESHOOTING ..................... 48 – 52
USER MAINTENANCE ........................... 53
CAUTIONS ................................... 54 – 56
SPECIFICATIONS ................................. 57
INDEX ........................................ 58 – 62
TERMS ............................ 63 – Back Cover
LYT1023-001A
ENGLISH
6
7 – 13
14 – 22
23 – 45
46 – Back Cover
EN
Advertisement
Chapters
Table of Contents
Troubleshooting
Related Manuals for JVC GR-DVL145
Summary of Contents for JVC GR-DVL145
-
Page 1: Digital Video Camera
DIGITAL VIDEO CAMERA GR-DVL145 Please visit our Homepage on the World Wide Web and answer our Consumer Survey (in English only): http://www.jvc-victor.co.jp/english/index-e.html For Accessories: http://www.jvc-victor.co.jp/english/accessory/ INSTRUCTIONS CONTENTS AUTOMATIC DEMONSTRATION GETTING STARTED RECORDING & PLAYBACK 14 – 22 RECORDING ... 15 – 18 PLAYBACK ... -
Page 2: Safety Precautions
Dear Customer, Thank you for purchasing this digital video camera. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of this product. Using This Instruction Manual • All major sections and subsections are listed in the Table Of Contents on the cover page. •... - Page 3 However, live recording and LCD monitor/viewfinder playback are possible anywhere. Use the JVC BN-V408U/V416U/V428U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter and Power Cord. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.)
- Page 4 The following notes concern possible physical damage to the camcorder and to the user. When carrying, be sure to always securely attach and use the provided shoulder strap. Carrying or holding the camcorder by the viewfinder and/or the LCD monitor can result in dropping the unit, or in a malfunction.
-
Page 5: Provided Accessories
In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter. If a cable has only one core filter, the end that is closest to the filter should be connected to the camcorder. -
Page 6: Automatic Demonstration
• Wind the cable so that it is not slack. NOTE: Take care not to damage the cable. When connecting cables, attach the end with the Core Filter to the camcorder. AUTOMATIC DEMONSTRATION Automatic Demonstration takes place when “DEMO MODE” is set to “ON” (factory-preset). -
Page 7: Table Of Contents
GETTING STARTED GETTING STARTED CONTENTS Power ... 8 – 9 Grip Adjustment ... 10 Viewfinder Adjustment ... 10 Shoulder Strap Attachment ... 10 Tripod Mounting ... 10 Date/Time Settings... 11 Loading/Unloading A Cassette ... 12 Recording Mode Setting ... 13... -
Page 8: Power
Battery pack Cord to the AC Adapter Plug the Power Cord into an AC outlet The CHARGE lamp on the camcorder blinks to indicate charging has started. When the CHARGE lamp stops blinking but stays lit, charging is finished. Unplug the Power Cord from the AC outlet. -
Page 9: Power
VU-V856 KIT : BN-V856U battery pack & AA-V80EG or AA-V80EK AC Power Adapter/Charger Read the kit's instruction manual before using. Also, by using the optional JVC VC-VBN856U DC Cord, it will be possible to connect BN-V840U or BN-V856U battery packs to the camcorder and supply power directly to the camcorder. -
Page 10: Grip Adjustment
Strap . Confirm the strap is not twisted. Tripod Mounting When attaching the camcorder to a tripod, extend its legs to stabilise the camcorder. It is not advised to use small sized tripods. This may cause damage to the unit by falling over. -
Page 11: Date/Time Settings
Set the Power Switch to “ ” while pressing down the Lock Button located on the switch. The power lamp lights and the camcorder is turned on. Press the MENU/BRIGHT wheel in to access the Menu Screen. Rotate the MENU/BRIGHT wheel to select “... -
Page 12: Loading/Unloading A Cassette
If the tape does not load properly, open the cassette holder cover fully and remove the cassette. A few minutes later, insert it again. When the camcorder is suddenly moved from a cold place to a warm environment, wait a short time before opening the cassette holder cover. -
Page 13: Recording Mode Setting
It is recommended that tapes recorded in the LP mode on this camcorder be played back on this camcorder. During playback of a tape recorded on another camcorder, blocks of noise may appear or there may be momentary pauses in the sound. -
Page 14: Recording & Playback
RECORDING & PLAYBACK RECORDING & PLAYBACK CONTENTS RECORDING ... 15 – 18 Basic Recording ... 15 Journalistic Shooting ... 16 Self-Recording ... 16 Operation Mode ... 16 Zooming ... 17 Time Code ... 18 PLAYBACK ... 19 – 22 Normal Playback ... 19 Still Playback ... -
Page 15: Recording
Shooting while using the viewfinder: Close the LCD monitor. • The power lamp lights and the camcorder enters the Record-Standby mode. “PAUSE” is displayed. Press the Recording Start/Stop Button. “ appears while recording is in progress. -
Page 16: Journalistic Shooting
Self- Recording To turn on the camcorder, set the Power Switch to any operation mode except “OFF”while pressing down the Lock Button located on the switch. Power Switch Power lamp When the Power Switch is set to “ appears. When set to “... -
Page 17: Zooming
Zoom in (T: Telephoto) 1x W 1 x W 2 x W Zoom out (W: Wide angle) Zoom display 1 x W Digital zoom zone 16X (optical) zoom zone Approximate zoom ratio Power Zoom Lever Zooming FEATURE: PURPOSE: To produce the zoom in/out effect, or an instanta- neous change in image magnification. -
Page 18: Time Code
If during recording a blank portion is left partway through the tape, the time code is interrupted. When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent this, perform “Recording From The Middle of A Tape”... -
Page 19: Playback
Speaker NOTES: If Stop mode continues for 5 minutes when power is supplied from a battery, the camcorder shuts off automatically. To turn on again, set the Power Switch to “OFF”, then to “PLAY”. The playback picture can be viewed in the LCD monitor, viewfinder or on a connected TV ( You can also view the playback picture on the LCD monitor with it flipped over and pushed against the camera body. -
Page 20: Connections
Use the provided Cable Adapter. Audio/Video cable [mini-plug to RCA plug] (provided) To AV Camcorder To S-VIDEO * The Audio cable is not required for watching still images only. NOTE: Set the video out select switch of the cable adapter as required: : When connecting to a TV or VCR which accepts Y/C signals and uses an S-Video cable. - Page 21 Make sure all units are turned off. Connect the camcorder to a TV or VCR as shown in the illustration ( pg. 20). If using a VCR . . . go to step 3. If not . . . go to step 4.
-
Page 22: Blank Search
... press 5. NOTES: In step 3, if the current position is at a blank portion the camcorder searches in the reverse direction, and if the current position is at a recorded portion the camcorder searches in the forward direction. -
Page 23: Advanced Features
ADVANCED FEATURES FOR RECORDING ... 24 – 31 USING MENUS FOR DETAILED ADJUSTMENT ... 32 – 37 DUBBING ... 38 – 39 USING THE OPTIIONAL REMOTE CONTROL UNIT ... 40 – 44 SYSTEM CONNECTIONS ... 45 ADVANCED FEATURES CONTENTS Night-Scope ... 24 Programme AE With Special Effects ... -
Page 24: For Recording
• “GAIN UP” in the CAMERA Menu ( • “DIS” in the MANUAL Menu ( During Night-Scope, it may be difficult to bring the camcorder into focus. To prevent this, use of manual focus and/or a tripod is recommended. MENU/BRIGHT Wheel... - Page 25 When using “SLOW”, the image takes on a strobe- like effect. When using “SLOW”, it may be difficult to bring the camcorder into focus. To prevent this, use of manual focus and/or a tripod is recommended. , but CLASSIC FILM...
-
Page 26: Fade/Wipe Effects
IMPORTANT Some Fade/Wipe Effects cannot be used with certain modes of Programme AE with special effects pg. 24, 25). If an unusable Fade/Wipe Effect is selected, its indicator blinks or goes out. MENU/BRIGHT Wheel Power Switch Lock Button Recording Start/Stop Button FOR RECORDING Fade/Wipe Effects These effects let you make pro-style scene... - Page 27 Fader And Wipe Menu Menu FADER — WHITE FADER — BLACK FADER — B.W WIPE — CORNER WIPE — WINDOW WIPE — SLIDE WIPE — DOOR WIPE — SCROLL WIPE — SHUTTER Effect Fade in or out with a white screen. Fade in or out with a black screen.
-
Page 28: Snapshot
Rotate the MENU/BRIGHT wheel to select the RETURN” and press it twice. The Menu Screen SNAPSHOT RECORDING Press SNAPSHOT. “PHOTO” appears while the for approx. 6 seconds, then the camcorder re-enters the Record-Standby mode. for approx. 6 seconds, then the normal recording resumes. -
Page 29: Auto Focus/Manual Focus
FEATURE: PURPOSE: The camcorder’s Full Range AF system offers continuous shooting ability from close-up (as close as approx. 5 cm to the subject) to infinity. However, correct focus may not be obtainable in the situations listed below (in these cases use manual focusing): •... -
Page 30: Exposure Control
Exposure Control Manual exposure adjustment is recommended in the following situations: • When shooting using reverse lighting or when the background is too bright. • When shooting on a reflective natural background such as at the beach or when skiing. •... -
Page 31: White Balance Adjustment
If the white balance is correct, all other colours will be accurately reproduced. The white balance is usually adjusted automatically. However, more advanced camcorder operators control this function manually to achieve a more professional colour/tint reproduction. Set the Power Switch to “... -
Page 32: Using Menus For Detailed Adjustment
D I SPL Normal Screen USING MENUS FOR DETAILED ADJUSTMENT For Recording Menu This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings ( Set the Power Switch to “ down the Lock Button located on the switch. - Page 33 • When shooting scenes with movement in various directions. • When shooting scenes with low-contrast backgrounds. Switch off this mode when recording with the camcorder on a tripod. The “ ” indicator blinks or goes out if the Stabiliser cannot be used.
- Page 34 Menu Screen Explanations (cont.) TELE MACRO WIDE MODE CINEMA SQUEEZE WIND BEEP BEEP MELODY : Factory-preset NOTES: The “ MANUAL” settings are effective only when the Power Switch is set to “ “ SYSTEM” functions which are set when the Power Switch is set to “ is set to “PLAY”...
- Page 35 The date/time is always displayed. TIME Time code is not displayed. CODE Time code is displayed on the camcorder and on the connected TV. Frame numbers are not displayed during recording. CLOCK ADJ. Allows you to set the current date and time (...
-
Page 36: For Playback Menu
MENU/BRIGHT Wheel Power Switch Lock Button Recording Start/Stop Button Display V I DEO SOUND MODE SYSTE 12B I T MODE D I SPL MODE COPY SOUND 12B I T REC M COPY RETUR BEEP – MELODY DEMO MODE – R SET RETUR ON SC RE N... -
Page 37: Playback Sound
Playback Sound During tape playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. According to the menu access explanation on pg. 36, select “SOUND MODE” or “12BIT MODE” from the Menu Screen and set it to the desired parameter. -
Page 38: Dubbing
Repeat steps 4 through 6 for additional editing, then stop the VCR and camcorder when finished. NOTES: As the camcorder starts to play your footage it will appear on your TV. This will confirm the connections and the AUX channel for dubbing purposes. -
Page 39: Dubbing To A Video Unit Equipped With A Dv Connector
( If the remote control is used when both the player and recorder are JVC video units, both units will perform the same operation. To prevent this from happening, press the buttons on both units. -
Page 40: Using The Optiional Remote Control Unit
Remote sensor USING THE OPTIONAL REMOTE CONTROL UNIT The Full-Function Remote Control Unit can operate this camcorder from a distance as well as the basic operations (Playback, Stop, Pause, Fast-Forward and Rewind) of your VCR. It also makes additional playback functions possible. - Page 41 PAUSE Button PLAY Button Infrared beam Transmits the beam signal. transmitting window START/STOP Button Functions the same as the Recording Start/Stop Button on the camcorder. VISS Button* ZOOM (T/W) Buttons Zoom in/out ( VCR CTL Button* A.DUB Button STOP Button INSERT Button &...
-
Page 42: Playback Zoom
1) Press PLAY (4) to find the scene of interest. 2) Press the Zoom Buttons (T/W) on the remote control. Make sure the remote control is pointed at the camcorder's remote sensor. Pressing T zooms in. To end zoom, press and hold W until magnification returns to normal. -
Page 43: Audio Dubbing
Make sure you only edit recorded areas. If feedback or howling occurs during TV playback, move the camcorder’s microphone away from the TV, or turn down the TV’s volume. If you change from 12-bit to 16-bit in mid-recording and then use the tape for Audio Dubbing, it is not effective from the point where 16-bit recording began. -
Page 44: Insert Editing
PAUSE (6). Press and hold INSERT (w) on the remote control, then press PAUSE (6). “6w” and the Time Code (min.:sec.) appear and the camcorder enters Insert-Pause mode. Press START/STOP to begin editing. • Confirm the insert at the time code you checked in step 1. -
Page 45: System Connections
DV connector-equipped capture board. When using a DV cable, be sure to use the optional JVC VC-VDV206U or VC-VDV204U DV cable depending on the type of DV connector (4 or 6 pins) on the PC, or use the DV cable provided with the capture board. - Page 46 REFERENCES CONTENTS DETAILS ... 47 TROUBLESHOOTING ... 48 – 52 USER MAINTENANCE ... 53 CAUTIONS ... 54 – 56 SPECIFICATIONS ... 57 INDEX ... 58 – 62 Controls, Connectors And Indicators ... 58 – 59 Indications ... 60 – 62 TERMS ...
-
Page 47: Details
Be sure to use it only in well-ventilated areas. • Set the Power Switch to “PLAY”, “ • Disconnect the AC adapter from the camcorder. • Unplug the AC adapter from the AC outlet. • Detach the battery from the camcorder. -
Page 48: Troubleshooting
If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Adapter, etc.) and wait a few minutes;... - Page 49 SYMPTOM The colour of Snapshot looks strange. The image taken using Snapshot is too dark. The image taken using Snapshot is too bright. Digital Zoom does not work. The Black & White Fader does not work. Even when Slow Shutter is not selected, the image looks like it is activated.
- Page 50 LCD monitor become dark. Consult your nearest JVC dealer. • The light used to illuminate the LCD monitor causes it to become hot. • This may occur when the surface or the edge of the LCD monitor is pressed.
- Page 51 SYMPTOM Coloured bright spots appear all over the LCD monitor or the viewfinder. During recording, sound cannot be heard. Play, Rewind and Fast- Forward functions do not work. The LCD monitor image is distorted. Images on the LCD monitor are jittery. Blocks of noise appear during playback, or there is no playback picture and the...
-
Page 52: Troubleshooting
If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. Do not eject the cassette. This will cause damage to the tape. • Eject the cassette once and re- insert it, then check if the indication clears. -
Page 53: User Maintenance
USER MAINTENANCE After Use Turn off the camcorder. Slide and hold OPEN/EJECT in the direction of the arrow, then pull the cassette holder cover open until it locks. The cassette holder opens automatically. Remove the cassette. Press “PUSH HERE” to close the cassette holder. -
Page 54: Cautions
Battery Packs The supplied battery pack is a lithium-ion battery. Before using the supplied battery pack or an optional battery pack, be sure to read the following cautions: 1. To avoid hazards ..do not burn..do not short-circuit the terminals. When transporting, make sure the provided battery cap is attached to the battery. - Page 55 1. To prevent damage to the LCD monitor, DO NOT ..push it strongly or apply any shocks..place the camcorder with the LCD monitor on the bottom. 2. To prolong service life . . .
-
Page 56: Cautions
20 seconds, it stops automatically. Also refer to the cleaning cassette’s instructions. If, after using the cleaning cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time. -
Page 57: Specifications
Audio output Output Power requirement Output Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice. Camcorder General : DC 11.0 V (Using AC Adapter) DC 7.2 V (Using battery pack) : Approx. -
Page 58: Index
INDEX Controls, Connectors And Indicators & ^ 3 4 5 6 7... - Page 59 Controls Monitor Open Button [PUSH OPEN] ... Dioptre Adjustment Control ... Battery Release Button [BAT. RELEASE] ... • MENU Wheel [+, –, PUSH] ... • LCD Monitor BRIGHT (Brightness) Control [+, –] ... Snapshot Button [SNAPSHOT] ... • Power Zoom Lever [T/W] ... •...
-
Page 60: Indications
Appears when the focus is adjusted manually. pg. 17) Displays the Time Code. pg. 26, 27) INDEX 0 min & monitor. 5 seconds after turning on the camcorder. Indications pg. 34) pg. 15) pg. 13) pg. 15) pg. 15) pg. 28) pg. 44) pg. - Page 61 LCD Monitor/Viewfinder Indications During Playback SOUND BLANK SEARCH VOLUME 116 : 21 : 25 Displays the sound mode. Displays the Blank Search mode. Displays the tape speed. Appears while a tape is running. 64 : Forward slow-motion 16 : Reverse slow-motion 6e : Audio Dubbing Pause Displays the date/time.
-
Page 62: Index
Appears when the date/time is not set. Appears when the built-in clock battery runs out and the previously set date/time is erased. Consult your nearest JVC dealer for replacement. Appears for 5 seconds after power is turned on if the lens cap is attached. -
Page 63: Terms
Brighten The LCD Monitor ... Channels (Left/Right) ... Charge The Battery Pack ... Cinema ... Classic Film ... Clean The Camcorder ... Connections ... pg. 8, 9, 20, 21, 38, 45 Darken The LCD Monitor ... Date/Time Display ... Date/Time Settings ... - Page 64 Self-Recording ... Sepia ... Shuttle Search ... Shutter Speed ... Slow Shutter ... Snapshot ... Snapshot Mode ... Snow ... Sound Mode ... Speaker Volume ... Specifications ... Sports ... Spotlight ... Squeeze ... Still Playback ... Strobe ... COPYRIGHT© 2002 VICTOR COMPANY OF JAPAN, LTD. pg.
