Installation of the coffee machine

o The width of the furniture housing cut-out will be affected by the
thickness of the sides of the furniture. The side plates can be
used to compensate for any empty spaces.
o Four plates are supplied to compensate for the different width
measures. There are two which are 2mm thick (6) and two
which are 1 mm thick (5). They can be used to obtain the
required width dimensions for installation of 560 mm.
o Position the fixed machine support
(1) by resting it on the base surface
of the furniture cut-out.
30
