Summary of Contents for Gembird Airbird
- Page 1 Wireless USB adapter 802.11b/g 54M USB 2.0 wireless LAN adapter...
- Page 2 Wireless USB adapter...
- Page 3 Wireless USB adapter...
- Page 4 We spared no efforts to make sure that the information in this manual is correct and complete. · However no liability is accepted for any errors or omissions. Gembird Electronics reserves the right to change the specifications of the hardware and software described in this manual without prior notice.
- Page 5 Wireless USB adapter...
- Page 6 Wireless USB adapter NICW-U3 User manual Introduction Thank you for buying the Gembird® 802.11b/g 54M USB 2.0 wireless LAN adapter! This manual will help you install and use it properly. Features Supports data transfer rate up to 54Mbps · Auto fallback data rate under noisy environment ·...
-
Page 7: Specification
Wireless USB adapter Specification Complies with IEEE802.11g, IEEE802.11b · Transmit Speed Auto-Negotiation, up to 54M · USB 2.0 connector · Supports Ad-Hoc/Infrastructure modes · Standard / protocol: IEEE 802.11g; IEEE 802.11b; USB2.0; CSMA/CA with ACK · Frequency Range: 2.4-2.4835GHz · Data Rate: 54/48/36/24/18/12/9/6/11/5.5/2/1... -
Page 8: Installation
Wireless USB adapter Installation Install illustration: "The CD-ROM installs method" is belong to a method of normal install drive, if appear an unconventionality during the period of installation, Please handle according to "System install method automatically" or "Equipments management machine install method" (the following instruction setup the USB wireless adapter under Windows XP). - Page 9 Wireless USB adapter Please put the driver CD into the CD-ROM, and double click "Setup.exe". (Fig 3) ·...
- Page 10 Wireless USB adapter The system appears a dialog box automatically for drive to install. Customer according to · "drive to install a wizard to carry on to install gradually". The installs procedure finished, click "Finish". · If at installs procedure doesn’t pass the Microsoft Attestation, click "still continue" here. Note:...
- Page 11 Wireless USB adapter System installs method automatically First time, Refer to "CD-ROM installs method" step 2 to installs driver, the system appear · "find out a new hardware wizard" dialog box open automatically, after find out the equipments, the choice "from the software automatically", the Click "next move".
- Page 12 Wireless USB adapter In "Please choose your search and installation options" dialog box, Click "Browse" to · designate paths of driver, and click "Next". Example: (CD-ROM) E:\driver\RTL8187\WINXP...
- Page 13 Wireless USB adapter The system appear installs software procedure. · Then installs finished, Click" finish" to complete installs. · If at installs procedure doesn’t pass the Microsoft Attestation, click" still continue" here. Note:...
- Page 14 Wireless USB adapter Equipments management installs method First insert the USB wireless adapter to USB port of the computer. After turn on the · computer power to enter operation system, the system could show “FOUND NEW HARDWARE WIZARD”, and click "cancel" close dialog box Use right key to Click "my computer", appear attribute dialog box, choose "properties →...
- Page 15 Wireless USB adapter On “device manger” dialog box, Choose “ Ethernet Controller” ·...
- Page 16 Wireless USB adapter...
- Page 17 Wireless USB adapter Use right key click the equipments , choose " Update driver …". · Appear dialog box, and choose “Install from a list or specific location (Advanced)”, click · “Next”.
- Page 18 Wireless USB adapter Last step refer to “The system installs method automatically” step 2 … 4. ·...
- Page 19 Wireless USB adapter Configuration your wireless adapter The Wireless Client Configuration Utility screen will appear automatically. ·...
- Page 20 Wireless USB adapter...
- Page 21 Wireless USB adapter Chose Available Network into Available Network dialog box, then click Refresh button to · search for available wireless networks.
- Page 22 Wireless USB adapter To connect to one of the networks on the list, select the wireless network, and click Add to · profile button.
- Page 23 Wireless USB adapter Then Click OK button, appear a Wireless network properties dialog box, click OK button · back to PROFIL option screen...
- Page 24 Wireless USB adapter Then click General option screen, View network state on the option screen ·...
- Page 25 Wireless USB adapter Congratulations! You’ve successfully configured your wireless adapter!
- Page 26 Wireless USB adapter...
