44
EN
These are some basic types of connections. When making connections, refer also to your VCR and TV
instruction manuals.
A.
Connection to a TV or VCR equipped with an S-VIDEO
Basic Connections
Use optional Video and Audio cables.
Connector cover*
A.
Connection to a TV or VCR equipped with an S-VIDEO
Connection For Tape Dubbing
Use optional Video and Audio cables.
Connector cover*
* When connecting the cables, open this cover.
PLAYBACK
To Video Output
Video cable (optional)
Audio cable (optional)
To Audio Output
To Video
Video cable
Output
(optional)
Audio cable (optional)
To Audio Output
Basic Connections And Tape Dubbing
To VIDEO IN
To TV or VCR
To AUDIO IN
Power Switch
PLAY/PAUSE (4/6)
Button
To
VIDEO IN
To AUDIO IN
TV
VCR
TV
VCR (Recording deck)
