1
Getting to know your computer
Right side
Component
(1)
(2)
(3)
(4)
(5)
Power connector
AC adapter light
Memory card reader
USB 2.0 port
SIM slot (select models only)
Description
Connects an AC adapter.
●
White: AC adapter is attached
●
Amber: Battery is charging.
●
Blinking white: The AC adapter is connected and
battery capacity is low
●
Off: Running on battery power.
Reads optional memory cards that store, manage, share, or
access information.
To insert a card:
Hold the card label-side up, with connectors facing the slot.
Insert the card into the slot, and then press in on the card
until it is firmly seated.
To remove a card:
Press in on the card until it pops out.
Connects an optional USB device, such as a keyboard,
mouse, external drive, printer, or USB hub.
Supports a wireless subscriber identity module (SIM).
Right side
1
