This is a specially designed antenna for both analog and digital TV
broadcast reception. It can receive all the TV signals in your area in
the VHF and UHF bands, as well as FM radio signals. An ideal
solution for home or portable TV reception. It is easy to install and
use.

PACKAGE CONTENTS

• Indoor HDTV antenna
• Quick Setup Guide

FEATURES

• Receive free local HDTV broadcasts
• Adjustable VHF and UHF antennas receive 1080i and 720p HDTV
signals
• Fine Tuning Dial to improve reception
• Large, stable base with integrated 5' coaxial cable for simple
connection to your TV
Before using your new product, please read these instructions to prevent any damage.
VHF antenna
UHF antenna
Coaxial cable
Base
Fine tuning knob
Quick Setup Guide |
Indoor HDTV Antenna with Fine Tuning

SETTING UP AND USING YOUR ANTENNA

1 Connect the end of the coaxial cable to the coaxial jack on the
back of your TV or digital converter box.
Connect to HDTV
Antenna
Coaxial cable
OR
Connect to TV through digital converter box
Digital converter box
Antenna
OR
Coaxial cable
Video/audio cable
(such as a coaxial or composite cable)
NS-ANT514
HDTV
TV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-ANT514 and is the answer not in the manual?

Questions and answers

Summary of Contents for Insignia NS-ANT514

  • Page 1 Quick Setup Guide | NS-ANT514 Indoor HDTV Antenna with Fine Tuning This is a specially designed antenna for both analog and digital TV SETTING UP AND USING YOUR ANTENNA broadcast reception. It can receive all the TV signals in your area in 1 Connect the end of the coaxial cable to the coaxial jack on the the VHF and UHF bands, as well as FM radio signals.
