COMPACT VHS CAMCORDER
GR-AX475
INSTRUCTIONS
CONTENTS
Basic Recording ......................... 12
Basic Features ...........................13
Video Light .............................. 15
Advanced Features .....................16
Effects .................................... 16
Exposure Control ...................... 17
Focusing .................................. 18
Fader ....................................... 20
Wide ....................................... 20
Instant Titles............................. 21
Character Generator ................. 21
Adjustment ............................. 24
Self-Timer ................................ 26
Animation ................................ 27
Time Lapse ............................... 27
PLAYBACK ......................... 28
Basic Connections .......................29
Basic Playback ..........................30
Features ..................................31
EDITING ............................ 32
Tape Dubbing ............................32
CONTROL UNIT .............. 36
Installing The Battery .................. 36
Insert Editing ............................38
Audio Dubbing ...........................39
TROUBLESHOOTING ...... 41
INDEX ............................... 43
PAL
Viewfinder ...............................43
Controls ..................................44
Connectors ...............................45
Indicators ................................45
Other Parts .............................. 45
Terms .....................................46
CAUTIONS ........................ 47
SPECIFICATIONS .............. 49
6
12
LYT0002-026B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR-AX475 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JVC GR-AX475

Summary of Contents for JVC GR-AX475

  • Page 1: Table Of Contents

    COMPACT VHS CAMCORDER GR-AX475 INSTRUCTIONS CONTENTS GETTING STARTED RECORDING Basic Recording ... 12 Basic Features ...13 Video Light ... 15 Advanced Features ...16 Programme AE With Special Effects ... 16 Exposure Control ... 17 Focusing ... 18 Fader ... 20 Wide ...

  • Page 2: Safety Precautions

    Dear Customer, Thank you for purchasing the JVC Compact VHS camcorder. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of your new camcorder. Using This Instruction Manual • All major sections and subsections are listed in the Table Of Contents ( cover page).

  • Page 3: Some Do's And Don'ts On The Safe Use Of Equipment

    This camcorder is designed to be used with PAL-type colour television signals. It cannot be used for playback with a television of a different standard. However, live recording and viewfinder playback are possible anywhere. Use the BN-V12U/BN-V22U/BN-V25U battery packs and, to recharge them, the provided multi-voltage AC Power Adapter/Charger.

  • Page 4: Provided Accessories

    REMEMBER The Logical Choice The only compact video cassettes that can be used with your VHS VCR* Programme AE with Special Effects ( pg. 16) Auto Mode Lock Auto Mode Release Electronic Fog Filter ND Effect Sepia Twilight Sports 1/1000 sec. High Speed Shutter 1/2000 sec.

  • Page 5: Quick Operation Guide

    Hook on. BATT. RELEASE Using the battery pack Hook-on the battery pack's top end to the camcorder. (Charging procedure, Push in the battery pack until it locks into place. To remove the battery pack Slide BATT. RELEASE and pull out the battery pack.

  • Page 6: Getting Started

    BN-V22U BN-V25U USING THE BATTERY PACK ATTACH BATTERY PACK Hook its top end to the camcorder and push the battery pack in until it locks in place. DETACH BATTERY PACK Slide BATT. RELEASE and pull out the battery pack. BATT. PACK Push in.

  • Page 7: Using Ac Power

    The CHG. indicator may not light properly with a brand new battery pack, or with one that’s been stored for an extended period. In this case, remove and reattach the battery pack and recharge it. The CHG. indicator should light during recharging. If not, contact your nearest JVC dealer. To DC in jack...

  • Page 8: Viewfinder Adjustment

    Set POWER to “CAMERA”. Clock (Lithium) Battery Insertion/Removal This battery is necessary for clock operation and to perform date/time settings. SWITCH OFF POWER Switch off the unit’s power and remove the power supply unit. OPEN COVER Open the clock battery compartment cover while pressing the release tab.

  • Page 9: Select Function

    MENU PROGRAM AE select dial NEAR – GAIN UP Menu Screen TELE MACRO INTERVAL TIMER REC TIME JLIP ID NO. SET CHARACTER DATE/TIME END :MENU KEY Set Time and Date Screen 1. 1. 00 CANCEL Date Day/Month/Year Time 24-hour indication Date/Time Setting SELECT MODE First set the power switch to “CAMERA”.

  • Page 10: Recording Mode Setting

    If not, slide the tab. Some cassettes have removable tabs. If the tab has been removed, cover the hole with adhesive tape. The cassette holder can’t be opened while the camcorder is in the Record mode. GETTING STARTED pg. 12) displayed in the (cont.)

  • Page 11: Grip Adjustment

    Recording Start/Stop button Grip Adjustment EXPAND LOOP Separate the Velcro strip. INSERT HAND Pass your right hand through the loop and grasp the grip. ADJUST STRAP LENGTH Adjust so your thumb and fingers can easily operate the Recording Start/Stop button and Power Zoom lever.

  • Page 12: Recording

    If you’re recording on a cassette from the middle, use the RETAKE function ( the last recording so you don’t erase any of it. The LENS COVER warning blinks for about 10 seconds when the camcorder is turned on, when the cover is closed.

  • Page 13: Basic Features

    RECORDING Basic Features Power zoom switch Zoom-in Zoom-out Zoom indicator FEATURE: Zooming PURPOSE: Varies the focal length of the lens and produces the zoom in/out effect. OPERATION: Zoom In 1) Pull the power zoom switch down toward “T”. Zoom Out 1) Push the switch up toward “W”.
  • Page 14 This is normal. FEATURE: Retake PURPOSE: To re-record certain segments. OPERATION: 1) Make sure the camcorder is in the Record–Standby mode. 2) Press either RETAKE button to reach the start point for new recording. Pressing “F” fast-forwards the tape and pressing “R”...

  • Page 15: Video Light

    •Do not use near flammable or explosive materials. •It is recommended that you consult your nearest JVC dealer for replacing the video light. ) does not blink in the pg. 16) is engaged, the...

  • Page 16: Advanced Features

    SYMBOL INDICATION LOCK AUTO LOCK Auto Mode Lock Locks the camcorder in Full Auto mode, preventing incorrect operation due to accidental button pressing during shooting. • In this mode the following controls are disabled; FADE, WIDE, TITLE, DISPLAY, M.W.B (Manual...

  • Page 17: Exposure Control

    DIAL VIEWFINDER SYMBOL INDICATION SEPIA Sepia The scene being shot is recorded in sepia-tinted (reddish-brown) monochrome, giving the effect of an older movie. Use together with Wide ( for the authentic look of a classic Hollywood movie. TWILIGHT Twilight Dusk, twilight scenery, fireworks, etc., look more natural and dramatic.

  • Page 18: Focusing

    This feature locks the focus in place, which is especially helpful in the following situations: •When things pass between your subject and the camcorder. Engage the focus lock function to lock your subject in before recording. •When you want your subject to be focused, and to appear in a corner of the screen.

  • Page 19: Adjust Focus

    Power zoom lever NEAR PROGRAM AE select dial Manual Focus NOTE: You should already have made the necessary viewfinder adjustments ( pg. 8). If you haven’t, do so before continuing. SELECT MODE Turn the PROGRAM AE select dial to any position except AUTO LOCK.

  • Page 20: Fader

    Function indication Fade-Standby indication SELECT button PROGRAM AE select dial SET button FADE IN FADE OUT RECORDING Fader This feature allows smooth fade-in and fade-out to black blank screen. Fade-in works at recording start, and FADE fade-out works at recording end or when you enter Record–Standby mode.

  • Page 21: Instant Titles

    0 1 2 3 4 5 6 7 8 9 I L I KE YOU CLEAR Instant Titles The camcorder has eight preset titles in memory. You can superimpose one of them above a previously stored title as shown in the illustration to the left. DISPLAY...

  • Page 22: Date/Time Character Insert

    25.12.97 display mode using SET. Auto date record executed AUTO DATE RECORD Your camcorder automatically records the day, month and year for about 5 seconds after recording is initiated in the following situations: •After changing the date. IN PARIS, FRANCE •After loading a cassette.

  • Page 23: Manual White Balance Adjustment

    SELECT MODE Turn the PROGRAM AE select dial to any position except AUTO LOCK. ADJUST FOCUS Point the camcorder at a white, flat object such as a sheet of white paper, and adjust focus manually pg. 19). ADJUST WHITE BALANCE pg.

  • Page 24: Using Menu For Detailed Adjustment

    RECORDING Using Menu For Detailed Adjustment This camcorder is equipped with Programme Manager, an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings. SELECT MODE Turn the PROGRAM AE select dial to any position except AUTO LOCK.
  • Page 25 1/4 S 1/2 S JLIP ID NO. This number is necessary when connecting the camcorder to a device such as a computer using the J terminal (JLIP). The numbers range from 01 to 99. Factory setting is 07. SET CHARACTER Allows you to input characters.

  • Page 26: Self-Timer

    Self-Timer You can set the delay between pressing RECORDING START/STOP and the actual start of recording. If you 1MIN secure the camcorder, you (or whomever is operating the 1/2S camcorder) can enter the scene before recording starts. NOTE: Make sure the camcorder is in the Record-Standby mode before performing the following steps.

  • Page 27: Animation

    NOTE: Make sure the camcorder is in the Record-Standby mode and the recording mode is set to "SP" before performing the following steps. ACCESS MENU SCREEN...

  • Page 28: Playback

    Recording safety hole PLAYBACK Cassette Adapter Use this to play back a VHS-C video cassette recorded with this camcorder. It is fully compatible with any VHS video cassette recorder. The C-P7U adapter is battery powered and automatically performs tape loading and unloading.

  • Page 29: Basic Connections

    AUDIO and VIDEO connectors on the camcorder and those on the VCR. SUPPLY POWER Turn on the camcorder, the VCR and the TV. SELECT MODE Set the VCR to its AUX input mode, and set the TV to its VIDEO mode.

  • Page 30: Stop Playback

    Tape counter : Still Playback NOTE: PLAY/PAUSE Make sure you connect your camcorder as directed in “Basic Connections” ( LOAD A CASSETTE Slide EJECT to open the cassette holder, then insert the cassette with the label facing out. Press PUSH to ensure the holder is closed and locked.

  • Page 31: Features

    PLAYBACK Features – COUNTER R/M PLAY/PAUSE STOP FEATURE: Manual Tracking PURPOSE: To eliminate noise bars that appear on the screen during playback. OPERATION: 1) Press either +/– button as many times as necessary for best picture. NOTES: To reset TRACKING to the original preset, press both + and –...

  • Page 32: Tape Dubbing

    SELECT VCR MODE Engage the VCR’s AUX and Record-Pause modes. FIND EDIT-IN POINT To AUDIO and Engage the camcorder’s Play mode to find a spot VIDEO OUT just before the edit-in point. Once it’s reached, press connectors PAUSE on the camcorder.

  • Page 33: Random Assemble Editing [R.a.edit]

    REC STBY (you don’t need to press VCR CTL for this one). You’re now ready to try Random Assemble Editing. IMPORTANT Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with yours or may offer limited functions. BUTTONS...

  • Page 34: Make Corrections

    NOTES: The MBR can be used to operate other camcorder functions as well. Point the MBR at the camcorder’s remote sensor and press any of the following buttons (function appears in parentheses): — ON/OFF (camcorder R.A. EDIT) —...
  • Page 35 R.A. Edit-capable JVC VCR. The recording deck can be... AV OUT a VCR other than JVC, or a JVC VCR which has neither a Remote PAUSE nor an R.A. EDIT connector How to use: — Connect the playback deck and MBR as shown on the AV IN left.

  • Page 36: Using Remote Control Unit

    The Full-Function Remote Control Unit can operate this camcorder from a distance as well as the basic operations (PLAY, STOP, PAUSE, FF, and REW) of your VCR. This remote control unit makes additional recording functions possible. RM-V704U or RM-V700U (provided)
  • Page 37 Infrared beam effective area Remote Sensor When using the remote control, be sure to point it at the remote sensor. The above illustration shows the approximate transmitted beam effective area for indoor use. The transmitted beam may not be effective or may cause incorrect operation outdoors or when the remote sensor is directly exposed to sunlight or powerful lighting.

  • Page 38: Insert Editing

    ENGAGE INSERT EDITING MODE Press and hold INSERT, and without releasing INSERT, press and release PAUSE. The Insert mode is engaged, and the scene the camcorder is aimed at appears on the screen. BEGIN INSERT EDITING Press RECORDING START/STOP. When the counter reaches “0:00:00”, editing stops automatically and...

  • Page 39: Audio Dubbing

    A. DUB, press and release PAUSE. BEGIN AUDIO DUBBING Press PLAY/PAUSE. When the counter reaches “0:00:00”, Audio Dubbing stops automatically and the camcorder enters the Audio Dub-Standby mode. END AUDIO DUBBING Press STOP. NOTES: Do not press FF or REW during Audio Dub-Standby, or the edit points will not be accurate.

  • Page 40: User Maintenance

    PUSH. Press BATT. RELEASE to remove the battery pack. Slide the LENS COVER open/close switch to close the lens cover. Cleaning The Camcorder CLEAN EXTERIOR Wipe gently with a soft cloth. CLEAN LENS Blow it with a blower brush, then wipe gently with lens cleaning paper.

  • Page 41: Troubleshooting

    Remove the cassette and disconnect the power source, then after a few minutes, try turning the power back on. If it still doesn’t come on, consult your nearest JVC dealer. The recording tape’s Erase Protection tab is missing. Cover the hole with adhesive tape. (Some tapes have sliding tabs.
  • Page 42 Lens Cover Warning indicator blinks. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Power Adapter/Battery Charger, etc.) and clock battery; and then re-connect it and proceed as usual from the beginning.

  • Page 43: Index

    10 when power is turned on. Also displayed for about 5 seconds when clock pg. 13 battery becomes exhausted while using the pg. 12 camcorder. pg. 20 For inserting or replacing the clock battery. pg. 26 Condensation Warning pg. 12 When this indication appears, all functions are pg.

  • Page 44: Controls

    Controls Diopter Adjustment ... Power Zoom Lever ... BATT. [Battery] RELEASE Switch ... Recording Start/Stop Button ... POWER Switch ... STOP Button ... Tape Length [T30•45•60] Select Button ... COUNTER R [Reset]/M [Memory] Button ... EDIT Button ... Recording Mode [SP/LP] Select Button ...

  • Page 45: Connectors

    • Connect the Editing Cable when performing Random Assemble Editing ( •It is used to connect the camcorder to a device such as a personal computer. For further detail consult your nearest JVC dealer. Information (in English) is also availble at our home page: http://www.jvc-victor.co.jp/ DC IN Jack ...

  • Page 46: Terms

    AC Power Adapter ... pg. 6 Animation Recording ... pg. 27, 37 Audio Dubbing ... pg. 39 Auto Date Record ... pg. 22 Auto Focus ... pg. 18 Auto Mode Lock Mode ... pg. 16 Auto Mode Release Mode ... pg. 16 Battery Pack ...

  • Page 47: Cautions

    • Do not us e near flammable or explosive materials. Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC General Battery Precautions • When the C-P6U or C-P7U (cassette adapter) is not functioning even when correctly operated, the batteries are exhausted.

  • Page 48: Main Unit

    If the picture is not clear, repeat steps 1 to 3 up to two more times. If the picture is still unclear, consult your local JVC dealer. Important Note: If heads have become dirty, the associated tape will also be damaged, please do not use the tape again.

  • Page 49: Specifications

    •Wireless Remote Control Unit (MBR) RM-V704U or RM-V700U * Some acccessories are not available in some areas. Please consult your nearest JVC dealer for details on accessories and their availability. Specifications shown are for SP mode unless otherwise indicated. E. & O. E. Design and specifications subject to change without notice.
  • Page 50 MEMO...
  • Page 51 MEMO...
  • Page 52 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan COPYRIGHT© 1997 VICTOR COMPANY OF JAPAN, LTD. 0397TOV...
