Nitto APS-125 Instruction Manual

PNEUMATIC ORBITAL SANDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
PALM OBITAL SANDER
Model APS-125,APS-150 (Non Vacuum Type)
Model APS-125SV,APS-150SV (Self Vacuum Type)
Model APS-125CV,APS-150CV (Central Vacuum Type)
PROFESSIONAL TOOL
Maximum Operating Pressure
Air Consumption(No Load)
Rated Speed
(No Load)
Orbit Diameter
Pad Size
Pad Mass(Weight)
Sound Pressure Level
Sound Power Level
Vibration Level
Mass(Weight)
Thread Size of Air Inlet
Due to continuous product development/improvement the specifications and configurations in
this document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Specifications
Model
Non Vacuum Type
SV Type
CV Type
Non Vacuum Type
SV Type
CV Type
APS-125
0.6 MPa
3
0.45 m /min
-1
10,000 min (r/min) 10,000 min
-1
11,000 min (r/min) 11,000 min
-1
10,000 min (r/min) 10,000 min
O.D.5mm
O.D.125mm(5")
0.1 kg
77 dB(A)
88 dB(A)
2
1.6 m/s
0.69 kg
0.73 kg
0.71 kg
Rc1/4
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
Tel : (81)-3-3755-1111
Fax : (81)-3-3753-8791
E-mail : overseas@nitto-kohki.co.jp
URL : www.nitto-kohki.co.jp
Original Instructions
APS-125SV
APS-150
-1
(r/min)
-1
(r/min)
-1
(r/min)
O.D.150mm(6")
0.12 kg
77 dB(A)
88 dB(A)
2
3.7 m/s
0.72 kg
0.76 kg
0.73 kg
