PNEUMATIC RECIPROCATING SANDER
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
LINE SANDER
PROFESSIONAL TOOL
Maximum Operating Pressure
Air Consumption (No Load)
Rated Speed (No Load)
Stroke Length
Pad Size
Abrasive Paper Size
Mass (Weight)
Sound Pressure Level
Sound Power Level
Vibration Level
Thread Size of Air Inlet
Due to continuous product development/improvement the specifications and configurations in
this document are subject to change without prior notice.
Keep the manual handy – so you can use it whenever necessary.
Specifications
Model
Model LS-10
LS-10
0.6MPa
3
0.11 m
/min
-1
4,000 min
4mm(5/32")
55mm x 103mm(2-5/32" x 4-1/16")
57mm x 140mm(2-1/4" x 5-1/2")
0.75 kg
87 dB(A)
89 dB(A)
2
8.4 m/s
Rc1/8
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
Tel
: (81)-3-3755-1111
Fax
: (81)-3-3753-8791
E-mail : overseas@nitto-kohki.co.jp
URL
: www.nitto-kohki.co.jp
Original Instructions
Advertisement
Table of Contents
Related Manuals for Nitto LS-10
Summary of Contents for Nitto LS-10
- Page 1 Thread Size of Air Inlet Rc1/8 Due to continuous product development/improvement the specifications and configurations in this document are subject to change without prior notice. Manufactured by : NITTO KOHKI Co., Ltd. 2-9-4, Nakaikegami, Ohta-ku, Tokyo, 146-8555, Japan : (81)-3-3755-1111 : (81)-3-3753-8791 E-mail : overseas@nitto-kohki.co.jp...
-
Page 2: Table Of Contents
9. ORDERING SERVICE PARTS ………………………… 6 Landessprache. 10. OPTIONAL PARTS ……………………………………… 6 French : S'il vous plait, veuillez demandez ・ 11. EXPLODED DIAGRAM : LS-10 ………………………… 7 á votre foumisseur de manuel instruction en langue locale. PICTOGRAM Spanish : Por favor, cantacte con su ・... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY BEFORE OPERATION INSTRUCTIONS Inspect tool before use. ● Before using, check that screws are securely When using the tool, please observe the safety tightened, that any protective cover or guard is precautions below to prevent possible accident or securely in place, other parts are free from damage injury. -
Page 4: General: Pneumatic Tools
Use only Nitto genuine parts. ● CAUTION Use of improper parts may result in serious accident. To obtain a Nitto genuine part, consult this Manual Handle tool carefully. ● or contact the sales agent from which you have Abusive use of tool could invite failure or accident. -
Page 5: Instructions For This Tool
NPT thread included as standard accessories, if you would like to have American NPT thread instead. Package Contents Qty check LINE SANDER LS-10 1set 5. ATTACH ABRASIVE PAPER Hose E Ass'y 1set Bushing R1/4 x NPT1/4... -
Page 6: How To Operate The Tool
oxide abrasive grains to prevent clogging, improve 5-3. In Case of Using Double-Sided Adhesive Tape grinding efficiency, and prolong the life of the paper. Attach double-sided adhesive tape to the sponge part then attach the Abrasive Paper to the tape. 5-4. -
Page 7: Storage
In ordering parts and components give each part number, part name and quantity required. Use only NITTO genuine parts. 10. OPTIONAL PARTS Part No. Description TP03803 Adhesive Spray... -
Page 8: Exploded Diagram : Ls-10
This diagram is for your reference only. Do not attempt to service or repair the Tool. Do not take the Tool apart. Contact an authorized Nitto dealer for all service and repair of the Tool. Improper service and repair can cause accidents and service injuries. - Page 10 Tel: (65)-6227-5360 Fax:(65)-6227-0192 http://www.nitto-kohki.co.jp/e/nksb/ NITTO KOHKI EUROPE Co., Ltd. Unit 21, Empire Centre, Imperial Way, NITTO KOHKI Co., Ltd. Shanghai Representative Office Watford Hertfordshire, WD24 4TS, United Kingdom #1117 Ruijing Building, Maoming South Road, Shanghai 200020 China Tel: (44)-01923-239668 Fax:(44)-01923-248815 http://www.nitto.co.uk/...
