- Page 1 Installation and configuration manual Compatibility with vehicles which have a Concert RMC Radio and a 6,5” colour display...
- Page 2 Index 1. Component identification – Page.3 1.1. Multimedia interface components– Page.3 1.2. GPS Box components – Page.4 1.3. Voice module components – Page.4 2. Installation – Page.5 2.1. Multimedia interface installation diagram – Page.5 2.2. Setting up the multimedia interface before installing it – Page.6 2.3.
- Page 3 Basic knowledge before installation: • Please, read fully and carefully this installation handbook before you attempt to install the kit in your vehicle. • Start the installation once you have the car stopped and the key out of the ignition slot, supply power must be the last step in installation.
- Page 4 1. Component identification: 1.1. Multimedia interface components: Additional module - SUB BOARD IR cable ((4P)*1ea) Multimedia interface MODE cable (*1ea) POWER cable ((24P) *1ea) AV cable (*1ea) TOUCH OUT cable (*1ea) REAR CAMERA POWER cable (*1ea) LVDS cable (*1ea) TOUCH cable (*1ea) Remote Control (*1ea) Original LCD cable HSD (*1ea) (*1ea= 1 unity)
-
Page 5: Installation
1.2. GPS Box components: GPS Box Touch screen GPS Box POWER cable GPS antenna Hidden microphone Speaker (Specific for overhead courtesy lights panel) (Optional installation) USB extension cable 1.3. Voice module components: Voice module Quadlock cable Voice module audio cable Voice module 2. - Page 6 MULTIMEDIA VIDEO INTERFACE SUB BOARD Navigation - GPS Box Touch cable LVDS cable Original LCD cable HSD Offered Touch cable Monitor Touch Screen Head unit Original LCD cable ...
- Page 7 2.2. Setting up the multimedia interface before installing it: DIP Switches: Using the DIP Switches of the multimedia interface you will be able to enable/disable the external multimedia devices, Navigation, DVD, rear cameras, etc… anything that you connect. For example, if you are going to connect a multimedia device in the AV1, and another in the AV3, we will just enable the corresponding DIP Switches (DIP2 and DIP 4) and we will disable all the remaining DIP Switches, if we do like this, we will only have that 2 enabled sources in the interface (AV1 and AV3), and when you change from one source to the other, the interface will skip...
- Page 8 2.3. Multimedia interface installation and connections: The first step will be to disassemble the screen from the dashboard, see on the image below. Unplug the switches from the center of the aerators and then unscrew the screw. Leverage the screen’s support using the removal tool 3094. Remove the radio using the removal tools T10057 and disassemble the rear connectors.
- Page 9 Disconnect the electric connector of the auto glove compartment, and remove the auto glove compartment. Once you have removed it, you will have enough space to perform the connections between the multimedia interface, the additional module and the vehicle’s screen and you will have too, space to place the multimedia interface. Now we will proceed to place the touch screen.
- Page 10 NOTE: Before ensambling the monitor again, we recommend to cut down the outside plastic frame where the touch panel has to be holded (see the images below). Connect the Touch Panel cable to the touch screen, the other side to the ”TO TOUCH” INPUT of the SUB BOARD module, and then you will be able to assemble again the screen on its original position.
- Page 11 Then, connect the LVDS cable (*1ea) to the “FROM I/F” connection port of the additional module (SUB BOARD) and connect the other side to the multimedia interface LVDS OUT.
- Page 12 2.4. POWER connector cables and connections: NOTE: The supply connection must always be the last step in the installation process. • ACC – Connect to +12V Ignition • GND – Connect to the vehicle’s Ground point • GPIO-ZO: MMI – No function •...
- Page 13 • DIP Switch 7 Down – enable the aftermarket camera Attention; new Audi cars model year from 2011 to nowadays, rear light signal needs to install a relay to filter signal pulses. Please pay attention to the information below. The rear gear signal mustn’t pass through any box (Filter FUSE BOX) so, you must cut the cables connected to the filter fuse box incoming from the rear gear signal and the output from this.
-
Page 14: Gps Antenna
2.6. GPS Box installation and connections: • GPS: Antenna GPS connection port • USB: USB devices connection port • POWER & DATA: Connection and supply cables connection port • RESET: Press this button to reset GPS Box to default factory settings •... - Page 15 USB extension cable: Connect to the USB port interface GPS Box of the GPS Box POWER cable: Connect to the interface GPS Box POWER & DATA port interface GPS Box RCA and Jack connectors: • White Conector: AUDIO L OUT, connect to the left side audio IN of the voice module •...
- Page 16 RGB OUT and TOUCH SCREEN connectors: • RGB OUT: Connect to the “RGB” port of the multimedia interface POWER connector • TOUCH SCREEN: Connect to the multimedia interface “Touch cable” – (4 wire) (TOUCH OUT cable *1ea) Make sure that you are doing correctly the connection from the GPS Box “TOUCH SCREEN” cable to the multimedia interface “Touch cable”...
-
Page 17: Voice Module
2.7. Voice module installation and connections: Voice module: fig.1 fig.2 fig.3 Voice Module with a LED Light that indicates that is working (fig. 1), Quadlock cable connection port (fig.2), Jack connection port for the Audio cable connection and volume regulator (fig.3) NOTE: Voice module for the audio signal to the vehicle’s front speakers. - Page 18 Connect the 12 pin White connector to the Voice module Quadlock cable connection port and connect the yellow loose cable to a +12V ACC ignition source. NOTE: The POWER connection always must be the last step in installation. Check that you can switch the screen’s image pushing the NAV button of the multifunction steering wheel. 2.8.
- Page 19 3. GPS Box Configuration – System Configuration: 3.1. Calibrating touch and setting the image: When starting the vehicle, it will appear on its screen, the OEM original menu image: Don’t insert the SD Card map yet, Push briefly the NAV button of the steering wheel for 2 sec. to enter NAVI mode, Screen’s image will change and it’s going to show NAVI mode (GPS Box) image, wait some seconds, until appears calibration image: Push this cursor “+”...
- Page 20 ◀ Now, push the button for 5 seconds to enter to the interface advanced settings menu or push the following button combination: ▲→ ▼→ ▲→ MENU. Move the selector to UTIL, using ▲ or ▼ buttons of the remote control and push OK, push OK again on TOUCH CALIBRATION, select YES option by the ▲...
- Page 21 The default settings of the “Adjust Size” menu is the next one: Horizontal 5 & Vertical 7 Once you have adjusted image, you have to calibrate the touch screen again, push on “Settings”, then push on “Touch Screen”, and repeat the steps for calibration process mentioned before. NOTE: Remember to do again a calibration of the touch screen after adjusting the image on the screen.
- Page 22 ◀ You must check that the MMI control option is ON in the Advanced Settings menu (push the button for 5 seconds to enter to the interface advanced settings menu or push the following button combination: ▲→ ▼→ ▲→ MENU) Push MENU button of the remote control until the advanced menu settings of the multimedia interface disappears from the screen.
- Page 23 3.3. Maps SD card and GPS signal: Once you have insert the Maps SD card, we have to setup the route of the executable file (.exe), follow the next steps: Push on Settings, then in Navigate Setup, uncheck the auto initialitzation software option, and push on the folder icon.
- Page 24 3.4. Checking the GPS: Perform these steps on a space with good GPS reception Don't try to perform the steps with the vehicle inside of a building or a garage • Disconnect the GPS Box antenna • In the main menú push on Settings •...
- Page 25 4. FAQ’S/Solving problems: 1. ¿Why do I can’t change the interface mode? • Check if the IR cable is connected or not. • Check if the interface red LED light is shining or not. If it isn’t shining, check if the “POWER” connector is right connected.
