Rubi DT250EVO Operator's Manual

10 in. tile saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATOR'S MANUAL
10 in. TILE SAW
MANUEL D'UTILISATION
SCIE À CARREAUX DE 254 mm (10 po)
MANUAL DEL OPERADOR
SIERRA DE LOSAS DE 254 mm (10 pulg.)
DT250EVO
Your tile saw has been engineered and manufactured to our high standards for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Cette scie à carreaux a été conçue et fabriquée conformément
à nos strictes normes de fiabilité, simplicité d'emploi et sécurité
d'utilisation. Correctement entretenue, elle vous donnera des
années de fonctionnement robuste et sans problèmes.
AVERTISSEMENT :
Pour réduire les risques de blessures, l'utilisateur doit
lire et veiller à bien comprendre le manuel d'utilisation
avant d'employer ce produit.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
Su sierra de losas ha sido diseñada y fabricada de conformidad
con nuestras estrictas normas para brindar fiabilidad, facilidad
de uso y seguridad para el operador. Con el debido cuidado, le
brindará muchos años de sólido funcionamiento y sin problemas.
ADVERTENCIA:
Para reducir el riesgo de lesiones, el usuario debe leer
y comprender el manual del operador antes de usar
este producto.
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT250EVO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rubi DT250EVO

Summary of Contents for Rubi DT250EVO

  • Page 1 MANUAL DEL OPERADOR SIERRA DE LOSAS DE 254 mm (10 pulg.) DT250EVO Your tile saw has been engineered and manufactured to our high standards for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    ADDITIONAL LIMITATIONS: Any implied warranties granted under state law, including warranties of merchantability or fitness for a particular purpose, are limited to two (2) years from the date of purchase. RUBI, its subsidiaries, affiliates, and partners are not responsible for direct, indirect, or incidental damages, so the above limitations and exclusions may not ap- ply to you.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES  ALWAYS WEAR SAFETY GLASSES WITH SIDE WARNING: SHIELDS. Everyday eyeglasses have only impact- resistant lenses, they are NOT safety glasses. Read and understand all instructions. Failure to follow all instructions listed below, may result in  SECURE WORK. Use clamps or a vise to hold work electric shock, fire and/or serious personal injury.
  • Page 4 GENERAL SAFETY RULES  KEEP HANDS AWAY FROM CUTTING AREA. Keep  KEEP TOOL DRY, CLEAN, AND FREE FROM OIL AND hands away from wheels. Do not reach underneath work GREASE. Always use a clean cloth when cleaning. Never or around or over the wheel while wheel is rotating. Do not use brake fluids, gasoline, petroleum-based products, or attempt to remove cut material when wheel is moving.

  • Page 5: Specific Safety Rules

    SPECIFIC SAFETY RULES  SECURE WORK firmly against the miter guide or fence.  ALWAYS TURN OFF SAW before disconnecting it, to avoid accidental starting when reconnecting to power  NEVER stand or have any part of your body in line with supply.

  • Page 6: Symbols

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will result DANGER: in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could result WARNING: in death or serious injury.

  • Page 7: Electrical

    ELECTRICAL EXTENSION CORDS ELECTRICAL CONNECTION Use only extension cords with twist-lock connectors that This tool is powered by a precision built electric motor. It should be connected to a power supply that is 120 V, AC accept the tool’s plug. When using a power tool at a con- only (normal household current), 60 Hz.
  • Page 8 ELECTRICAL Ground Fault Circuit Interrupter (GFCI) protection should be provided on the circuit(s) or outlet(s) to be used for the tile saw. Outlets are available having built-in GFCI protection and may be used for this measure of safety. If the saw is used with an extension cord, ensure the con- nection of the tool’s power cord and the extension cord are not on the ground.

  • Page 9: Features

    FEATURES PRODUCT SPECIFICATIONS Wheel Diameter ............10 in. Diagonal Capacity (tile size) ........18 in. Wheel Arbor .............. 5/8 in. Maximum Depth of Cut ......... 3-3/4 in. Throat Capacity ............13 in. Rating ...........120 V~, 15 Amps, 60 Hz Rip Capacity (tile size) ..........24 in. No Load Speed ........4,000 r/min.

  • Page 10: Tools Needed

    FEATURES KNOW YOUR TILE SAW LEG STAND - Attached to the saw base, the leg stand opens and closes with ease making transportation simple. See Figure 3. MITER GUIDE - The easy-to-read indicator on the miter The safe use of this product requires an understanding of guide shows the exact angle for a miter cut with detents at the information on the tool and in this operator’s manual as 0°, 22.5°, and 45°.

  • Page 11: Loose Parts

    LOOSE PARTS The following items are included with your tile saw: Fig. 5 A - Water tray frame assembly ........1 T - Tile drying rack ............1 B - Tile cutting wheel ........... 1 U - Left outer tube............1 C - Motor head assembly ..........

  • Page 12: Assembly

     If any parts are damaged or missing, please call  Place a washer and long cap screw through the rubber 1-866-872-RUBI for assistance. foot. From the underside of the right outer tube, slide the bolt/foot into the last hole (curved side) of the tube.
  • Page 13 ASSEMBLY HEX HEAD RIGHT BOLT RIGHT UPPER OUTER LOCK TUBE TUBE TILE RACK LOCK HEX HEAD SPACER BOLT LOWER CARRIAGE BRACE BOLT RUBBER FOOT CENTER INNER LEG FLAT CAP SCREW BRACE ASSEMBLY WASHER (LONG) STOP LEFT HEX HEAD UPPER WHEEL BOLT TUBE LEFT...
  • Page 14 ASSEMBLY INSTALLING THE WATER TRAY FRAME SLIDING TABLE LOCK LEVER ASSEMBLY TO THE LEG STAND See Figure 7.  Lock the table stop by-pass by pulling up on the stop and turning it until the slot in the center of the lock is horizontal (left to right).
  • Page 15 ASSEMBLY CONNECTOR WATER TRAY FRAME WATER TRAY WATER FILL LINE CLEAR TUBE Fig. 10 RUBBER BOOT WATER TRAY FRAME WATER TRAY EXTENSION INNER LEG ASSEMBLY Fig. 9 Fig. 11 INSTALLING TH E WATER TRAY AND TRAY EXTENSI ONS See Figures 10 - 12.  From the right side of the saw, place the water tray (drain plug end to the left) on the lip at the bottom of the water tray frame.
  • Page 16 ASSEMBLY MITER INSTALLING THE MITER GUIDE LOCK GUIDE KNOB See Figure 13. MITER GUIDE The miter guide can be used from both the left and right side KNOB of the cutting wheel.  Place the slot on the underside of the miter guide on the sliding table fence.
  • Page 17 ASSEMBLY TO CLOSE / OPEN THE LEG STAND See Figures 15 - 17.  Remove water tray, water tray extensions and the water tank, and any workpieces from the tool. Store.  Place the sliding table in the center of the frame and lock RELEASE the table in place.
  • Page 18 ASSEMBLY TILE CUTTING WHEEL For maximum performance and safety, it is recommended that you use the 10 in. cutting wheel provided with your saw. Additional cutting wheels of the same high quality are available at your local dealer. WARNING: Do not use cutting wheels rated less than the no load speed of this tool.
  • Page 19 ASSEMBLY  Place an outer washer onto the spindle. The double “D” flats on the washer align with the flats on the spindle. Be sure the hollow side of the washer is against the cutting wheel. WHEEL  Place wheel nut on spindle. ...

  • Page 20: Operation

    OPERATION WARNING: PUMP SWITCH ALWAYS OFF Do not allow familiarity with tools to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. PUMP WARNING: SWITCH PUMP SWITCH Always wear eye protection with side shields ON WITH marked to comply with ANSI Z87.1.
  • Page 21 OPERATION ON/OFF SWITCH SWITCH See Figure 23. This saw is equipped with an on/off switch that has a built-in locking feature. This feature is intended to prevent unauthor- ON/OFF ized and possible hazardous use by children and others. SWITCH TO TURN THE SAW ON: SWITCH ...
  • Page 22 OPERATION MAKING CUTS CROSS CUT / RIP CUT Always draw the line to be cut on the tile using a marker or MARK MITER grease pencil. If the tile is shiny and hard-to-mark, place GUIDE masking tape on the tile and mark the tape. A common problem when cutting tile is straying from the marked line.
  • Page 23 OPERATION TO MAKE A MITER CUT MITER CUT See Figure 28. Miter cuts are used for cutting outside and inside corners on material, decorative chair rail, and base molding with the material at any angle to the wheel other than 90°. Miter cuts tend to “creep”...
  • Page 24 OPERATION  Turn the material over and make the cut along one of the  Turn the on/off switch to the OFF position. marks. This time overcut the other line and the cut piece  Slide the table away from the motor head and position should separate from the rest of the material.

  • Page 25: Adjustments

    ADJUSTMENTS WARNING: SCREW Before performing any adjustment, make sure the tool is unplugged from the power supply and the switch is in the OFF position. Failure to heed this warning could result in serious personal injury. FRAMING The saw has been adjusted at the factory for making very SQUARE accurate cuts.

  • Page 26: Maintenance

    ADJUSTMENTS DEPTH STOP ADJUSTMENTS If the cutting wheel is not an exact 45°:  Set the saw arm to a 45° angle. See Figure 35.  Place a combination square beside the wheel and set the The depth stop limits the wheel’s downward travel. It saw arm at 45°.
  • Page 27 MAINTENANCE BRUSH LUBRICATION BRUSH BRUSH ASSEMBLY All of the bearings in this tool are lubricated with a sufficient ASSEMBLY amount of high grade lubricant for the life of the unit under BRUSH normal operating conditions. After extended use, clean the rails so the table will slide smoothly.
