OPERATING INSTRUCTIONS
The Wattage Corsair EP Park Scale RTF is
distributed exclusively by Global Hobby Distributors
18480 Bandilier Circle, Fountain Valley, CA 92708
All contents copyright © 2003, Global Hobby
Distributors Version V1.0 August 2003
Kit Product Number: 128316
IMPORTANT
Before beginning assembly, please read and understand the warnings listed on the next page.
Failure to do so could lead to bodily harm and/or injury. The Wattage Corsair EP Park Scale RTF is not intended
for those under 12 years of age, unless closely supervised by an adult.
Visit our website at http://watt-age.globalhobby.com for information on other Wattage products
Specifications & Features:
Wing Span: 34.75 Inches
Wing Area: 175 Square Inches
Length: 21 Inches
Weight RTF: 17.5 Ounces
Wing Loading: 14.5 Ounces Per Square Foot
Elevator, Rudder & Throttle Control
Included Pre-installed 4Ch FM 27Mhz Radio System
Included Rechargeable Flight Battery
Included 2.5 Hour AC Battery Charger
Molded from Durable Plastic and Foam
Replacement Parts Available
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Corsair EP RTF and is the answer not in the manual?

Questions and answers

Related Manuals for Global Services Corsair EP RTF

Summary of Contents for Global Services Corsair EP RTF

  • Page 1 OPERATING INSTRUCTIONS Specifications & Features: The Wattage Corsair EP Park Scale RTF is Wing Span: 34.75 Inches distributed exclusively by Global Hobby Distributors Wing Area: 175 Square Inches 18480 Bandilier Circle, Fountain Valley, CA 92708 Length: 21 Inches Weight RTF: 17.5 Ounces Wing Loading: 14.5 Ounces Per Square Foot Elevator, Rudder &...

  • Page 2: For Your Information

    If you cannot solve a problem using the troubleshooter, or if you have any other questions or concerns, please contact us at the locations below: Global Services On the Web 18480 Bandilier Circle http://globalservices.globalhobby.com...

  • Page 3: Section 1: Parts Identification

    INTRODUCTION Thank you for purchasing the Wattage Corsair EP Park Scale RTF. Before completing the final assembly of your new airplane, please carefully read through these operating instructions in their entirety. Doing so will ensure your success the first time around! Tired of park-flyers that look like toys? The Corsair EP Park Scale RTF from Wattage combines the beautiful style of the classic piston-engine fighter with a park flyer design and RTF technology.

  • Page 4: Section 2: Recommended Items

    SECTION 2: RECOMMENDED ITEMS This section lists the items you will need to fly your new Corsair EP Park Scale RTF. As you can see, there's not much to it! 8 Pack Global AA Alkaline batteries for the transmitter Part # 110181 Small Phillips-Head Screwdriver PRO TIP The Wattage Corsair EP Park Scale RTF includes a 7 cell Nickel Cadmium flight battery and a 2.5 hour AC...
  • Page 5 BECOMING FAMILIAR WITH YOUR CORSAIR EP PARK SCALE RTF, CONTINUED..Arming Switch: This is a safety device. When the flight battery is plugged in, the motor can be turned on only after pressing this switch once. Control Horn: A plastic piece that is secured to the control surfaces. The pushrod wire from the servo inside the airplane attaches to the control horn, so the control surface can be moved.

  • Page 6: Section 4: Assembling Your Corsair Ep Park Scale Rtf

    SECTION 4: ASSEMBLING YOUR CORSAIR EP PARK SCALE RTF Step 1: Installing the Transmitter Batteries Remove the battery cover from the back of the transmitter by pulling down on it with one hand while holding the transmitter with your other hand. Install 8 fresh AA Alkaline batteries, being careful to make sure that the polarity is correct for each battery.
  • Page 7 While holding the horizontal tail in place and aligned, secure it to the fuselage by threading eight small screws through the predrilled holes in the fuselage and into the horizontal tail. IMPORTANT Four screws should be installed on the top and four on the bottom. Tighten the screws gently. Overtightening them can strip the foam and plastic.
  • Page 8 While holding the vertical tail in place and aligned, secure it to the fuselage by threading four small screws through the predrilled holes in the fuselage and into the vertical tail. IMPORTANT Two screws should be installed on each side. Tighten the screws gently. Overtightening them can strip the foam and plastic.
  • Page 9 Step 5: Installing the Propeller Carefully install the propeller onto the motor. To install the propeller correctly, simply push it firmly onto the motor shaft. PRO TIP One extra propeller has been included should you break the original one during landing. We suggest keeping the extra one with you while you're flying, just in case.
  • Page 10 Step 7: Installing the Landing Gear Install the landing gear by simply pushing the landing gear wire firmly into the molded plastic slot in the bottom of the wing. PRO TIP To make it easier to install the landing gear wire, squeeze the base of the wire together while you push it into the slot.

  • Page 11: Section 5: Learning To Fly Your Corsair Ep Park Scale Rtf

    SECTION 5: LEARNING TO FLY YOUR CORSAIR EP PARK SCALE RTF Step 1: Basic Operation Before actually flying your Corsair EP Park Scale RTF you should understand how the airplane is controlled. Below we list the four basic flight modes: Climb: Climbing is controlled by pushing the throttle control stick on the transmitter (the left-hand stick) completely forward to turn on the motor, then by pulling back on the elevator control stick (the right-hand stick).
  • Page 12 Looking from the back of the airplane, push the right-hand control stick completely to the left. The vertical control surface (rudder) should move left. Again looking from the back of the airplane, push the right-hand control stick completely to the right. The rudder should move right.

  • Page 13: Section 6: Getting Ready To Fly Your Corsair Ep Park Scale Rtf

    SECTION 6: GETTING READY TO FLY YOUR CORSAIR EP PARK SCALE RTF Step 1: Charging the Flight Battery Plug the flight battery connector into the battery If the flight battery is hot to the charger connector. When plugged in properly you should touch, it is fully charged.

  • Page 14: Section 7: Your First Flight

    Step 3: Choosing Your Flying Field The flying field you choose should be a large, open field with grass. There should not be any vehicles, buildings, power lines, trees, large rocks or anything else that your airplane can crash into. Step 4: Range Testing the Radio System After getting out to your flying field, but before you fly for the first time, you must range test the radio system.
  • Page 15 Double-check that the elevator and rudder control surfaces are moving in the correct direction. If they aren't, flip the servo reversing switches as described on page # 12. When you move the right-hand control stick forward and back, the elevator control surface should move down and up. When you move the right-hand control stick right and left, the rudder control surface should move right and left.
  • Page 16 When going into a turn, the airplane will have a natural tendency to lose some altitude. Unless you want to descend, you should gently pull back on the right-hand control stick to keep the airplane level during the turn. The steeper the turn the more altitude the airplane will lose and the more you will need to pull back on the control stick.

  • Page 17: Section 8: Flight-Trimming The Corsair Ep Park Scale Rtf

    We suggest ordering directly from your local Wattage dealer. If your local dealer does not stock Wattage products, you can order directly from us at the address shown below: Global Services On the Web 18480 Bandilier Circle http://globalservices.globalhobby.com...

  • Page 18: Section 11: Flight Tips And Warnings

    SECTION 11: FLIGHT TIPS AND WARNINGS Check before every flight to ensure that the batteries in the transmitter are working properly. The needle in the voltage meter should be in the green "safe" area. Change the batteries when the needle falls into the red "unsafe" area. Before recharging the flight battery, let the motor run until the flight battery is completely drained.

  • Page 19: Section 12: Troubleshooting Guide

    E) Did not press red motor arming switch E) Press red motor arming switch once F) A crash has damaged an internal component F) Contact Global Services 3) Airplane is difficult to control A) You are flying in too much wind...

  • Page 20: Our Guarantee

    Include a method of payment for any service charges. Send the unit to us by United Parcel Service, Federal Express or by Insured Mail. Postage is non-refundable. Send your package to: Global Services Visit Our Website 18480 Bandilier Circle http://globalservices.globalhobby.com...
