Introduction
Read this chapter to familiarize yourself with the features, benefits, and
capabilities of the Catalyst Express 520 switches.
Chapter Topics
•
•
•
•
•
•
•
OL-12761-02
Overview, page 1-2
Hardware Features, page 1-6
Software Features, page 1-10
Hardware Requirements, page 1-15
Software Requirements, page 1-15
C H A P T E R
User Guide for the Catalyst Express 520 Switches
1
1-1
Advertisement
Related Manuals for Cisco Catalyst Express 520
Summary of Contents for Cisco Catalyst Express 520
-
Page 1: Table Of Contents
• Hardware Features, page 1-6 • Software Features, page 1-10 • Box Contents, page 1-14 • Supported Hardware, page 1-14 • • Hardware Requirements, page 1-15 Software Requirements, page 1-15 • User Guide for the Catalyst Express 520 Switches OL-12761-02... -
Page 2: Overview
Introduction Overview Overview The Catalyst Express 520 switches provide network services that can support the data, voice, and mobile network demands of small and medium-sized businesses. The services ensure transmission quality and reliability for data and voice traffic. They also provide security to protect against network attacks. - Page 3 Catalyst Express 520 Switches Catalyst Express 520-8PC-K9 This switch provides Power over Ethernet (PoE) to Cisco IP phones and wireless access points. Because of its compact size, it can be deployed outside the traditional wiring-closet environment, such as in office workspaces and classrooms. It has 8 10/100 PoE ports for desktop, printer, IP phone, server, and wireless access-point connectivity •...
- Page 4 Any of the Catalyst Express 520 switches can be Switches A, B, C, and D in this network. To take full advantage of the different models of the Catalyst Express 520 switch platform, use the one that is designed for the type of connections that you require.
- Page 5 Chapter 1 Introduction Overview Switches C and D: Use the Catalyst Express 520-24TT-K9 or the Catalyst • Express 520G-24TC-K9 model to provide high-speed (up to 100 Mb/s and 1000 Mb/s, respectively) connections to network users. You can also use the Catalyst Express 520-24LC-K9 or the Catalyst Express 520-24PC-K9 model to connect Cisco prestandard and IEEE 802.3af-compliant powered devices, such as IP phones and access points, to...
-
Page 6: Hardware Features
100 and 240 VAC. Use the supplied AC power cord to connect the AC power connector to an AC power outlet. Depending on the Catalyst Express 520 model, a Cisco RPS 675 can be connector connected to the switch. The RPS is a redundant power system that automatically senses when the internal power supply of a connected device fails and provides power to prevent the loss of network traffic. - Page 7 Solid amber RPS is in standby mode or is in a fault condition. Blinking amber Switch internal power supply has failed, and the RPS is providing power to the switch. User Guide for the Catalyst Express 520 Switches OL-12761-02...
- Page 8 “Supported Hardware” section on page 1-14. Downlink Depending on the Catalyst Express 520 model, the downlink ports can be 10/100 ports PoE ports, 10/100 ports, or 10/100/1000 ports. You can set these ports for speed and duplex autonegotiation, in compliance with IEEE 802.3ab, to optimize port bandwidth.
- Page 9 Introduction Hardware Features The PoE ports provide up to 15.4 W of power to connected Cisco prestandard and IEEE 802.3af-compliant powered devices if the switch detects that there is no power on the circuit. On a per-port basis, through the Cisco Configuration Assistant, you can control whether the PoE port automatically provides power when a powered device is connected.
-
Page 10: Software Features
Cisco Configuration Assistant, page 1-13 • A subset of the basic software features are accessible through the device manager. All software features are accessible through the Cisco Configuration Assistant. Device Manager The device manager is a graphical device management tool for basic setup, monitoring, and troubleshooting of individual switches. - Page 11 Chapter 1 Introduction Software Features Figure 1-4 Device Manager Interface User Guide for the Catalyst Express 520 Switches 1-11 OL-12761-02...
- Page 12 Smartport status display the port roles assigned to the switch ports. • Security Secure Socket Layer (SSL) protocol authenticates and encrypts communications to the switch • device manager GUI. User Guide for the Catalyst Express 520 Switches 1-12 OL-12761-02...
- Page 13 Report (which identifies problems and suggests resolutions related to connectivity such as port-speed mismatch and faulty cabling) The Cisco Configuration Assistant is available in a number of languages. You can download the Cisco Configuration Assistant to your PC or laptop from this Cisco.com site: http://www.cisco.com/go/configassist...
-
Page 14: Box Contents
Verify that you have received the items shown here. If any item is missing or damaged, contact your Cisco representative or reseller for instructions. The model shown is a Catalyst Express 520-24PC-K9 switch. Your switch might look slightly different. The Catalyst Express 520-8PC-K9 switch does not ship with a rack-mount bracket kit. -
Page 15: Hardware Requirements
