QUICK SETUP GUIDE
LC-50LB261U
1
50
"
LED TV
Roku Ready
®
Your TV is certified to work with the
Included accessories
Roku Streaming Stick™.
Instantly stream 1000+ entertainment
channels, including Netflix, Hulu Plus,
Pandora, and more. Connect the
Streaming Stick (not included) to the
purple MHL port on your TV and enjoy.
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your User Guide is
not provided in the box but is available online.
Go to www.sharpusa.com/manuals/hd.aspx.
Find your model and select Download Owner's Manual.
Your online User Guide opens.
START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: Phillips screwdriver and a soft surface to lay the TV on.
1 Carefully place your TV face-down on a cushioned, clean surface
to protect the screen.
2 Insert the TV stand into the TV.
3 Secure the TV stand with the four provided screws.
OR
- OR -
How do I prepare my TV for wall mounting?
(not for use with the TV stand)
You'll need: A soft surface to lay the TV on.
1 Carefully place your TV face-down on a cushioned, clean surface to
protect the screen.
2 See the instructions that came with your wall mount for more information
about how to correctly mount your TV.
Which cables do you have?
Your TV has several different jacks for connecting devices. For the
best video quality, use the best available connection.
STOP!
VIDEO QUALITY
Do not plug your
power cord in until
BEST
all other devices
have been
BETTER
connected.
Component video and analog audio
GOOD
Composite video and analog audio (AV)
GOOD
Note: You can also connect a DVI device to your TV. See your online User Guide
for connection instructions.
Power cord
Features
Front view
Remote control
and two AAA
batteries
TV stand
Back view
Power connector
M6 (20 mm length)
(4 pcs.)
P
P
Y / VIDEO
B
R
DIGITAL AUDIO
C O M P O N E N T / AV
OUTPUT
Note: Images do not necessarily represent the exact design of your television.
[ 1 ]
[ 1 ]
MAKING CONNECTIONS
2
How do I watch TV (cable or satellite box) or connect a device such as a DVD or
Blu-ray Disc player, game console, Roku Streaming Stick™, or MHL-enabled device?
JACK TYPE
CABLE CONNECTOR
Using an HDMI cable (BEST)
HDMI video/audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
Power indicator
/A UDIO
OUT
How do I connect my TV to an antenna or cable wall jack?
3
DVI
2
MHL
1
A RC
USB
L
R
PC / DVI
ANT / CABLE
PC IN
AUDIO IN
Before using your new product, please read these instructions to prevent any damage.
[ 2 ]
[ 3 ]
[ 2 ]
Wall mount installation guide
(not included)
3
DVI
3
DVI
2
2
MHL
MHL
1
1
A RC
A RC
AUDIO/VIDEO OUT
Component cable option
Y / VIDEO
P
P
P
L
P
R
Y / VIDEO
B
R
L
R
D I GI T A L A U D I O
B
R
CO M P O N E N T / A V
A NT / C A B L E
P C IN
D I GI T A L A U D I O
OU T P U T
CO M PON EN T / A V
OU T P U T
Note: Connect the yellow video
cable to the green Y/VIDEO jack
on the back of your TV.
Y / VIDEO
P
B
P
R
L
R
PC / DVI
DIGITAL AUDIO
C O M P O N E N T / AV
ANT / CABLE
PC IN
AUDIO IN
OUTPUT
M6 × 20 mm screws
Multi-purpose jack: You can
plug any device that uses
HDMI into any HDMI jack.
However, certain devices
must be connected to a DVI,
MHL, or ARC jack. See the
instructions that came with
your DVI, ARC, MHL-enabled
device, or Roku Streaming
Stick™ for more information.
Note: The component and AV jacks
are shared. This means you can
connect only one component or AV
device at a time. We suggest
upgrading to HDMI if your device
supports it.
P C / DV I
A U D I O IN
P C / DV I
A NT / C A B L E
P C IN
A U D I O IN
AUDIO/VIDEO
OUT
AV cable option
CABLE
OVER
