CTC Union IPCAM-8318P User Manual

CTC Union IPCAM-8318P User Manual

Dual stream network high-speed dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IPCAM-8318P
Dual Stream Network High-speed Dome Camera
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPCAM-8318P and is the answer not in the manual?

Questions and answers

Related Manuals for CTC Union IPCAM-8318P

Summary of Contents for CTC Union IPCAM-8318P

  • Page 1 IPCAM-8318P Dual Stream Network High-speed Dome Camera...
  • Page 2 LEGAL The information in this publication has been carefully checked and is believed to be entirely accurate at the time of publication. CTC Union Technologies assumes no responsibility, however, for possible errors or omissions, or for any consequences resulting from the use of the information contained herein. CTC Union Technologies...

  • Page 3: Table Of Contents

    Table of contents INSTALLATION & PRODUCT SPEC............6 USING IP CAMERA VIA MOBILE PHONE OR MEDIA PLAYER..... 10 HOW TO USE INTELLIGENT IP INSTALLER...........11 3.1. Initial use Intelligent IP Installer ................11 3.2. Configuration of Main Menu................. 12 3.3. Camera ........................ 13 3.3.1.
  • Page 4 5.3.3. Network ..........................51 5.3.3.1. Information......................51 5.3.3.2. PPPoE ........................52 5.3.3.3. DDNS........................53 5.3.3.4. UPnP ........................54 5.3.3.5. IP Notification .....................55 5.3.4. Security ..........................57 5.3.4.1. Accounts ......................57 5.3.4.2. HTTPS........................58 5.4. Advanced Settings....................59 5.4.1. PTZ Control.........................59 5.4.2. Preset Position........................60 5.4.3. Patrol...........................61 5.4.4. FTP Client ...........................62 5.4.4.1.

  • Page 5: Installation & Product Spec

    Installation & Product SPEC Installation Steps Follow these steps to install the CTC Union IPCAM-8318P on your LAN: 1. Check the package contents against the list below. 2. Setup the device. See Chapter 3.1 on the available methods. Package Contents...
  • Page 6 RJ-45 Product Appearance Mount the housing There are 2 (two) ways to mount the PTZ camera, which are: Mounted to wall through a bracket Held to ceiling surface through a bracket (Option) Please read the accessory list to get understand of what components are for which type of mountings.
  • Page 7 Put the cover back to holder（Fig-5） 。 Fig-5 The Mounting Holders Two different holders and their accessories are supplied with the camera For Wall-mount (standard) --- crane type bracket For Ceiling-mount (optional) --- cane type bracket Φ 7...
  • Page 8 Product Specification...

  • Page 9: Using Ip Camera Via Mobile Phone Or Media Player

    Using IP Camera via Mobile Phone or Media Player To use IP cameras via mobile phones, please make sure your RTSP is set to “ON”. (Default is “ON”) To change the settings of IP cameras, please see “Settings” for details. 3G Mobile Phone viewing For 3G mobile phone viewing, type “rtsp://<IP>:<PORT>/video.3gp”...

  • Page 10: How To Use Intelligent Ip Installer

    How to Use Intelligent IP Installer This chapter introduces how to monitor the image from the camera using Intelligent IP Installer. The IP cameras can be used with Microsoft web browsers and Intelligent IP Installer in Windows operating systems. This document focuses on introducing you to Intelligent IP Installer.

  • Page 11: Configuration Of Main Menu

    Configuration of Main Menu 3.2. Main Menu Camera Click this button to get into common information of all Network Cameras in local network. You can connect the specific Network Cameras to get live video and to optimize video setting. User Click this button to get into user basic setting information of all Network Cameras in network.

  • Page 12: Camera

    Camera 3.3. The Camera page provides you all Network Cameras in the network with product factory information, including product Name, IP Address, MAC, Mod. Name and Mod. Search：Click it to search Network Cameras in the network, it displays Network Cameras information including Name, IP Address, MAC, Mod. Name and Mod. ID. Note: If the camera is not located in local network, it will appear in red text.

  • Page 13: Setup

    Setup 3.3.1. Choose a network camera, click on Setup to change the configurations. You have to key in the username and password of the administrator to enter the setup page. The following screen will display: Note: For IP cameras not in local network area (which appears in red in the search screen), you can still use setup to change the configurations of these cameras.
  • Page 14 Account settings: The account setting is displayed. You can change the account setting here. Press “Next” to continue, “Previous” to go back, “Cancel” to go to the main page.
  • Page 15 Date/Time settings: You can set the date/time of the network camera here. See ”Hint” for details. Press “Next” to continue, “Previous” to go back, “Cancel” to go to the main page.
  • Page 16 Network settings: You can change the network settings of the network camera here. See “Hint” for details. Press “Next” to continue, “Previous” to go back, “Cancel” to go to the main page.
  • Page 17 PPPoE settings: You can change the PPPoE settings here. See “Hint” for details. Press “Next” to continue, “Previous” to go back, “Cancel” to go to the main page.
  • Page 18 DDNS settings: You can change the DDNS settings here. Press “Next” to continue, “Previous” to go back, “Cancel” to go to the main page.
  • Page 19 Apply settings: Click on “Apply” to use the new settings. Choose “Reboot system to apply new (network) settings” to reboot after the settings are applied.

  • Page 20: Upgrade

    Upgrade 3.3.2. Choose a network camera, click on Upgrade to upgrade the firmware. You have to key in the username and password of the administrator to enter the upgrade page. The following screen will display: Choose the firmware image file you want to upgrade and press “Upgrade” to start. The device will automatically reboot after upgrade.

  • Page 21: Factory Default

    Factory Default 3.3.3. Choose a network camera, click on Factory default reset the configurations to default. You have to key in the user name and password to use the factory default function. Click on “OK” to continue. The device will automatically reboot after the configurations set to default.

  • Page 22: Reboot

    Reboot 3.3.4. Choose a network camera, click on Reboot to reboot the device. You have to key in the user name and password to use the reboot function. Click on “OK” to continue. The device will automatically reboot.

  • Page 23: User

    User 3.4. The System page provides you all Network Cameras configurations in the network with product or downloaded configuration file information, including Info, User, Date Time, TCP/IP, PPPoE and DDNS. Load configuration File： Select From PC File or From Device, the former can load information of downloaded configuration file and the latter can load Network Camera configurations in the network.
  • Page 24 From PC File：Click it and press Load to select configuration location from PC. Note: • Configuration file format is *.conf.
  • Page 25 From Device：Click it and press Load to select the specific device in the network. Type the Username and Password to load configuration from device. Note: If you have connected to the specific device before, you don’t have to type the Username and Password again.

  • Page 26: Info

    Info 3.4.1. The Info page provides you with product factory information, including Product Name, Firmware Version and Web version.

  • Page 27: User

    User 3.4.2. The Network Camera default account and password setting is “admin/admin”. Intelligent IP Installer provides to assign a password if the Network Camera is intended to be accessed by others. Use this menu to set the username and password of Administrator and up to 9 different users (User 1 to User 9), and the authentication access right of each group.

  • Page 28: Date/Time

    Date/Time 3.4.3. Current date & time：This displays the current date and time of the camera. PC clock：This displays the date and time of the monitoring PC clock. Adjust：Select one of four time adjusting modes. Keep current setting：Select this mode to keep the current date and time of the camera.

  • Page 29: Tcp/Ip

    TCP/IP 3.4.4. HTTP Port：Select port 80 in general situations. If you want to use a port number other than 80, select the text box and enter a port number between 1024 and 65535. Note： • When you have set the HTTP port number to a number other than 80 on the Network setting page or in the Setup Program, access the camera by typing the IP address of the camera on the web browser as follows: Example: when HTTP port number is set to 2000 Æ...

  • Page 30: Pppoe

    while the DNS server is assigned by the DHCP server. Use the following DNS server：Select this when you set the fixed address as the IP address of DNS server. Primary DNS：Enter the IP address of the primary DNS server. Secondary DNS：Enter the IP address of the secondary DNS server, if necessary. PPPoE 3.4.5.
  • Page 31 Primary DNS：Enter the IP address of the primary DNS server. Secondary DNS：Enter the IP address of the secondary DNS server.

  • Page 32: Ddns

    DDNS 3.4.6. Server Name：Select the DDNS Server User ID：Enter the user ID for authentication necessary for DDNS connections. Type it up to 64 characters. Password：Enter the password for authentication necessary for DDNS connections. Type it up to 32 characters. Confirm：Re-type the password to confirm. Hostname：Enter the host name that is registered to the DDNS server.

  • Page 33: About

    About 3.5. This page displays Intelligent IP Installer information including Version, Copyright and Product Date information Note： This computer procedure is protected of the right law and international convention. Making all or part which spread a procedure again without permission, may cause serious civil and criminal sanction and mention most severe telling in accordance with the law.

  • Page 34: Using Ip Camera Via Web Browser

    Using IP Camera via Web Browser System Requirement To use the product normally, we strongly recommend your computer follows our minimum system requirement (Computer level lower than this might cause some problems) Item Requirements Pentium 4 1600MHz (or equivalent AMD) Graphic Card 64MB RAM graphic cards (or equivalent on-board graphic cards)

  • Page 35: Configuration

    Configuration This chapter introduces how to monitor the image from the device using Microsoft Internet Explorer web browser. The IPCAM can be used with Microsoft web browsers and Intelligent IP Installer in Windows operation systems. The recommended browser for Windows is Internet Explorer 6.0 or above. If you want to know how to use CTC Union with Intelligent IP Installer, please check the Intelligent IP Installer User’s Manual for Windows operation systems.

  • Page 36: Initially Accessing The Ipcam

    Initially accessing the IPCAM 5.1. 1. Start your web browser, and enter the IP address or host name of the CTC Union IP camera in the Location / Address field of your browser. Note： • If you only want to view the video without seeing the setting page, enter “http://<IP>/index2.htm”...

  • Page 37: Configuration Of Main Screen

    Configuration of Main Screen 5.2. Language You can click the pull-down box to select the system language, including English, Traditional Chinese, Simplified Chinese, German, Japanese or Spanish. Setting 5.2.1. This function is only for the Administrator. Click this button to get into the Basic and Advance settings screen.

  • Page 38: Client Setting

    Client Setting 5.2.2. Mode: Click the pull-down box to choose between MPEG-4 and M-JPEG (Motion JPEG) video compression modes. Note：MJPEG streaming is unavailable if RTSP mode is ON. View Size: Select the desired display image resolution to 640X480 (4CIF) or 320X240 (CIF).

  • Page 39: Ptz Control

    PTZ Control 5.2.4. Pan / Tilt control buttons： Click the arrow button of the direction you want to move the camera. Other camera control functions： Move the camera to a pre-defined position. Before you start this function, you need to specify Guard tour settings in the Setting Menu under Advance / Patrol setting.

  • Page 40: Live View

    Live View 5.2.5. Snapshot: You can capture a still image shot from the camera and save it in your computer. 1. Press , and a snapshot window will appear. 2. Click “Save” to save the picture in your computer. 3. Click “Close” to return to the view page. Zoom in / out the image via the monitor window 1.

  • Page 41: Basic Setting

    Basic Setting 5.3. Click the “Basic” menu item to display the sub menus, including System, Camera, Network, and Security. System 5.3.1. 5.3.1.1. Information This information page provides you with product information, including Product name, Firmware version, and Web version.

  • Page 42: Date & Time Setting

    5.3.1.2. Date & Time Setting Current date & time：This displays the current date and time of the device. PC clock：This displays the date and time of the monitoring PC clock. Date & time format ： Click the pull-down box to select among different time display formats, including yyyy-mm-dd hh:mm:ss (year-month-day hour:minute:second), mm-dd-yyyy hh:mm:ss (month-day-year hour:minute:second), and dd-mm-yyyy hh:mm:ss (day-month-year...
  • Page 43 a network of computers. NTP server name：Type the host name or IP address of the NTP server, up to 64 characters. Time zone：Select the time zone and time difference from Greenwich Mean Time in the area where the device is installed from the pull-down box.

  • Page 44: Initialization

    5.3.1.3. Initialization Reboot：Click this button to reboot the device. A confirmation dialogue will appear. Click OK to proceed. It takes about two minutes to reboot the device. Factory default：Click this button to reset the device to the factory default settings. A confirmation dialogue will appear. Click OK to proceed, the network indicator on the device will start to blink.

  • Page 45: Camera

    Camera 5.3.2. 5.3.2.1. General RTSP: Switch the RTSP streaming On/Off. Note： • RTSP: Real Time Streaming Protocol. RTSP is supported by most media clients. (RealPlayer, Media Player, QuickTime, etc…) Deinterlace Filter：Switch the deinterlace filter on/off. Overlay：Select to add Text Overlay or Privacy Mask on/off the display screen. Text Overlay：Enables users to see some information on the display screen, including Date/Time and user-defined text.

  • Page 46: Mpeg-4

    5.3.2.2. MPEG-4 Computer View RTSP (If RTSP mode is ON) RTSP port: Specify the transmission port number for RTSP streaming video. Default value is 554. Viewer authentication: If the viewer authentication is ON, users viewing through RTSP will be requested to key-in username and password. RTP (If RTSP mode is ON) Unicast streaming: Unicast streaming Video port range: Specify the transmission port range...
  • Page 47 MPEG-4 viewer port (If RTSP mode is OFF) Unicast streaming Video/Audio port number: Specify the transmission port number of the video data. It is initially set to 8090. Specify an even number from 1024 to 65534. Image Size：Specify the image size the network camera transmits. You can choose among 704 ×...
  • Page 48 Mobile View RTSP (If RTSP mode is ON) RTSP port: Specify the transmission port number for RTSP streaming video. Default value is 8554. RTP (If RTSP mode is ON) Unicast streaming: Unicast streaming Video/Audio port range: Specify the transmission port range for RTP streaming video. RTP will select a port randomly from the range.

  • Page 49: M-Jpeg

    5.3.2.3. M-JPEG Note： • Motion JPEG settings are unavailable if the RTSP mode is ON, which means the MJPEG streaming is closed. MJPEG viewer port Unicast streaming Video/Audio port number : Specify the transmission port number for the video data. It is initially set to 8070. Specify an even number from 1024 to 65534.

  • Page 50: Network

    Network 5.3.3. 5.3.3.1. Information MAC address：Displays the MAC address of the device. Obtain an IP address automatically (DHCP)：If a DHCP server is installed on the network, to select this so the IP address is assigned by the DHCP server. Note：When you set Obtain an IP address automatically (DHCP), make sure that the DHCP server is working on the network.

  • Page 51: Pppoe

    5.3.3.2. PPPoE Use this setting when you connect the device through PPPoE (Point -to- Point Protocol over Ethernet). PPPoE connection is a protocol that is widely used in xDSL (digital subscriber line such as ADSL, VDSL or SHDSL) as the authentication and connection system. IP address：The IP address obtained from the PPPoE connecting to the network.

  • Page 52: Ddns

    5.3.3.3. DDNS DDNS or Dynamic DNS allows this device to register its IP address with a DDNS service provider. This allows accessing this device by using a real name, rather than having to remember the device's IP address. Server name：Choose the DDNS Server from the list. User ID：Enter the user ID for authentication necessary for DDNS connections.

  • Page 53: Upnp

    5.3.3.4. UPnP This device includes support for UPnP (Universal Plug 'n Play), which is enabled by default. If also enabled on your computer, the device will automatically be detected and a new icon will be added to “My Network Places.” UPnP provides port forwarding for opening a port in a router or firewall in a private network in order to let a party from the outside world contact a user device inside the firewalled network.

  • Page 54: Ip Notification

    5.3.3.5. IP Notification When IP notification is set to On, you can send an e-mail notification of the completion of the network settings. Notify type：Select type of DHCP, Static IP and PPPoE setting that will notify. SMTP server name：Type the SMTP server name up to 64 characters, or the IP address of the SMTP server used to relay the email notification messages.
  • Page 55 setting is necessary when the SMTP server which sends e-mails performs authentication using the POP user account. User name, Password：Type the user name and Password of the user who has the mail account. This setting is necessary when the SMTP server which sends e-mails performs authentication.

  • Page 56: Security

    Security 5.3.4. 5.3.4.1. Accounts The device default account and password setting is “admin/admin”. This means anyone might gain access to the device including the configuration as long as the IP address is known. It is necessary to assign a password if the device is intended to be accessed by others.

  • Page 57: Https

    5.3.4.2. HTTPS HTTPS is a URI scheme used to indicate a secure HTTP connection. It is syntactically identical to the http:// scheme normally used for accessing resources using HTTP. Using an https: URL indicates that secure HTTP is to be used, but with a different default TCP port (443) and an additional encryption/authentication layer between the HTTP and TCP.

  • Page 58: Advanced Settings

    Advanced Settings 5.4. PTZ Control 5.4.1. This section explains Pan, Tilt, Zoom, Focus, Iris and Auto Pan speed control settings, as well as the Protocol, Baud rate and Address which depend on the Speed Dome control module. Please note that changing the Dip Switch might result in control abnormal situation.

  • Page 59: Preset Position

    Preset Position 5.4.2. In this section, up to 32 Pan / Tilt and Zoom positions can be saved, as well as the home position, which the device faces to when the power is turned on. Setting Set：Use it to save the camera position to a preset number. Carry out the following steps.

  • Page 60: Patrol

    Patrol 5.4.3. There are four patrol tours to set for composing different preset positions. Each one lists up to 8 positions which can be programmed, and the will camera move to those programmed positions sequentially. The camera stops when it moves to the last preset position.

  • Page 61: Ftp Client

    FTP Client 5.4.4. Use this setup page to configure capturing and sending of images to an FTP server. By using FTP client function, you can send a video file which has been shot and recorded triggered by the external sensor input, alarm buffer or with the built-in motion detection function to FTP server.

  • Page 62: Alarm Sending

    5.4.4.2. Alarm Sending This function is used to forward the image file to the specified FTP server when an alarm is detected by an external sensor input or by the built-in motion detection function. Select On to send the image file to FTP server triggered by alarm detection.
  • Page 63 Motion Detection：Click it On to use Motion Detection function as a trigger. You can then setup the motion detection function page. Note： • Motion Detection works only when the Video mode is set to MPEG-4 and the Cropping is set to Off. Alarm Buffer：Select Use alarm buffer when you forward the image of before and after the alarm detection (pre-alarm, post-alarm).

  • Page 64: Periodical Sending

    5.4.4.3. Periodical Sending You can setup to send an image file to FTP server periodically by selecting On to send the image file to FTP server triggered with setting period. Remote path：Type the remote path, up to 64 characters. Image file name：Type the file name of the image sent to FTP server with up to 10 alphanumeric characters, - (hyphen) and _ (under score).

  • Page 65: Smtp

    SMTP 5.4.5. Use the SMTP setting page when you want to send an image via e-mail. By using the Mail (SMTP) function, you can send a mail with attached image which has been shot triggered by the external sensor input or with the built-in motion detection function.
  • Page 66 Authentication：Select the authentication method required when you send an email. Off: Select if no authentication is necessary when an email is sent. On: When authentication is necessary to send an e-mail, select one of the authentication methods from the following. SMTP: Select if SMTP authentication is necessary when an e-mail is sent.

  • Page 67: Alarm Sending

    5.4.5.2. Alarm Sending Use this setting page to trigger the email sending in response to an alarm detected by the external sensor input or by the built-in motion detection function. Alarm sending：Select On to set up send mail in response to the alarm detection.
  • Page 68 0000000001 and 4294967295 and two fixed digits 00 is added to the Image file name. Motion Detection：Click this to use the Motion Detection function as a trigger. You can then setup the motion detection function page. Note： • Motion Detection works only when the Video mode is set to MPEG4 and Cropping is set to Off.

  • Page 69: Periodical Sending

    5.4.5.3. Periodical Sending You can setup to send an image file by SMTP server periodically by selecting On to send the image file by SMTP server linked with setting period. Image file name：Type the file name of the image sent by SMTP up to 10 alphanumeric characters, - (hyphen) and _ (under score).
  • Page 70 Always：The sending function is always active. Schedule：You can specify the period when the periodical sending is effective in the schedule setting in the other section. Click Schedule and the setting menu for the effective period is displayed. (“Setting the Schedule — Schedule setting Menu” page).

  • Page 71: Http Event

    HTTP Event 5.4.6. Use this menu to setup capturing and sending images to an HTTP server. By using HTTP client function, you can send the specified CGI-BIN message linked with the external sensor input or with the built-in motion detection function to HTTP server.

  • Page 72: Alarm Sending

    5.4.6.2. Alarm sending Use this page to setup the alarms used to trigger actions such as sending mail, sending to FTP server or sending to HTTP server. Alarm sending：Select On to set the alarm detection action. Motion Detection：Click On to use Motion Detection function as a sensor. You can set the details on the motion detection function page.

  • Page 73: Alarm Output

    Alarm Output 5.4.7. When you click Alarm output on the Advance mode menu, the Alarm output setting menu appears. You can configure the alarm out of I/O port on the rear of the device linked to the alarm detection and the timer. Setting Alarm output：To activate the Alarm output function, select On.
  • Page 74 Alarm Input: Control the external alarm input of I/O port on the rear of the device triggering the FTP and SMTP sending function. Click Alarm Input to display the Alarm input setting menu. For details, see “Setting the Alarm Input — Alarm input setting Menu”...

  • Page 75: Schedule

    Schedule 5.4.8. When you click Schedule on the Advance mode menu, the Schedule setting menu appears. This is the same menu as the setting menu which is displayed when you click Schedule to set Effective period and Schedule in FTP client setting menu, e-Mail (SMTP) setting menu, Alarm out setting menu and so on.

  • Page 76: Alarm Input

    Alarm Input 5.4.9. When you click Alarm Input on the Advance mode menu, the Alarm input setting menu appears. You can set in this menu to control the external alarm input of I/O port on the rear of the device triggering the FTP and SMTP sending functions. Setting Sensor input 1：Click On to use external sensor which is connected to sensor input1 of the camera I/O port.

  • Page 77: Alarm Buffer

    Alarm Buffer 5.4.10. On this page you can set the Pre-alarm image (the image before the alarm detection) and the Post - alarm image. These can be set when Alarm sending FTP client setting menu or Image memory setting menu is set to On, and also when Use alarm buffer is selected.

  • Page 78: Motion Detection

    Motion Detection 5.4.11. When you click Motion Detection on the Advance mode menu, the Motion Detection setting menu appears. There are three Motion Detection functions which act as sensors and can be set for different detecting zones. Each one has Threshold and Sensitivity inputs which you can adjust to specific zone sequentially.
  • Page 79 Carry out the following steps： 1. Click On Motion Detection 1, choose one of eight orders. 2. A detecting zone 1 appears. Use mouse to adjust and move the zone boundaries and position. 3. Use tool bar to set Threshold and Sensitivity value. 4.

  • Page 80: System Log

    System Log 5.4.12. The System Log function allows users to review any changes and events that have happened. The system starts logging automatically after started. Remote Log: Enables user to send the log data to a specified log server.
