Axia IP-Intercom System Installation & User Manual page 50

• Digital Input to Digital Output: 138 dB
Equivalent Input Noise
• Microphone Preamp: -128 dBu, 150 ohm source, reference -50 dBu input level
Total Harmonic Distortion + Noise
• Mic Pre Input to Analog Line Output: <0.005%, 1 kHz, -38 dBu input, +18 dBu output
• Analog Input to Analog Output: <0.008%, 1 kHz, +18 dBu input, +18 dBu output
• Digital Input to Digital Output: <0.0003%, 1 kHz, -20 dBFS
• Digital Input to Analog Output: <0.005%, 1 kHz, -6 dBFS input, +18 dBu output
Crosstalk Isolation and Stereo Separation and CMRR
• Analog Line channel to channel isolation: 90 dB isolation minimum, 20 Hz to 20 kHz
• Microphone channel to channel isolation: 80 dB isolation minimum, 20 Hz to 20 kHz
• Analog Line Stereo separation: 85 dB isolation minimum, 20Hz to 20 kHz
• Analog Line Input CMRR: >60 dB, 20 Hz to 20 kHz
• Microphone Input CMRR: >55 dB, 20 Hz to 20 kHz
Power Supply AC Input
• Auto-sensing supply, 90VAC to 240VAC, 50 Hz to 60 Hz, IEC receptacle, internal fuse
• Power consumption: 35 Watts or less.
Operating Temperatures
• -10 degree C to +40 degree C, <90% humidity, no condensation
Dimensions and Weight
• Microphone node: 1.75 inches x 19 inches x 10 inches, 6 pounds
• Analog Line node: 1.75 inches x 19 inches x 10 inches, 6 pounds
• AES/EBU node: 1.75 inches x 19 inches x 10 inches, 6 pounds
• Router Selector node: 1.75 inches x 19 inches x 10 inches, 6 pounds
• GPIO node: 1.75 inches x 19 inches x 13 inches, 8 pounds
• Studio Mix Engine: 3.5 inches x 19 inches x 15 inches, 10 pounds
• IC.20: 3.5 inches x 19 inches x 8.5 inches, 5 pounds
• IC.10X: 1.75 inches x 19 inches x 8.5 inches, 4 pounds
• IC.1: 1.75 inches x 19 inches x 8.5 inches, 4 pounds
Version 1.2 July 2010
