Summary of Contents for Volvo XC90

  • Page 1 VOLVO XC90 Owner's Manual Web Edition I n f o r m a t i o n P r o v i d e d b y :...
  • Page 2 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 3 Welcome to the world-wide family of Volvo owners. We trust that you vehicle if you may be affected by alcohol, medication or any impair- will enjoy many years of safe driving in your Volvo, an automobile ment that could hinder your ability to drive.
  • Page 4: Table Of Contents

    Contents 00 Introduction 01 Safety 02 Instruments and controls Important information....... 10 Occupant safety........18 Instrument overview........56 Environment..........14 Seat belts..........20 Instrument panel........58 Important warnings........15 Supplemental Restraint System....23 Information display........62 Front airbags..........24 Center console buttons......64 Occupant Weight Sensor......
  • Page 5 Contents 03 Climate 04 Interior 05 Locks and alarm Climate control system – general informa- Front seats..........104 Remote keys and key blades....124 tion............94 Rear seats..........108 Locking and unlocking......128 Air distribution........... 96 Interior lighting........111 Child safety locks........130 Electronic climate control (ECC)....
  • Page 6: Contents

    Contents 06 Starting and driving 07 Wheels and tires 08 Car care General information........ 134 General information........ 172 Washing and cleaning the vehicle..200 Fuel requirements........135 Tire inflation ..........175 Paint touch up......... 204 Refueling..........137 Tire inflation pressure table..... 177 Starting the vehicle.........
  • Page 7 Contents 09 Maintenance and servicing 10 Audio 11 Specifications Volvo service........... 208 Audio system overview......246 Label information........278 Maintaining your vehicle......209 Audio system controls......247 Dimensions ..........280 Working on your vehicle......211 Radio functions........252 Weights ..........282 Engine compartment.......
  • Page 8 Contents 12 Index Index............294 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 9: Contents

    Contents I n f o r m a t i o n P r o v i d e d b y :...
  • Page 10: Introduction

    • Before you operate your vehicle for the first whose purpose is to provide important infor- Volvo Cars of North America, LLC time, please familiarize yourself with the mation in a clear and concise way. The impor- information found in the chapters "Instru-...
  • Page 11 Introduction Important information Risk of damage to the vehicle Information Types of lists used in the manual Procedures Procedures (step-by-step instructions), or actions that must be carried out in a certain order, are arranged in numbered lists in this manual. If there is a series of illustrations associated with step-by-step instructions, each step in the procedure is numbered in the same...
  • Page 12 Cali- fornia to cause cancer, and birth defects or • • Volvo reserves the right to make model Coolant other reproductive harm. In addition, certain changes at any time, or to change spec- •...
  • Page 13 • Do not export your Volvo to another coun- of the gear selector and move the selector from normal vehicle operation or in a crash or near- try before investigating that country's P (Park).
  • Page 14: Environment

    Recycling ventional gasoline-powered internal combus- As part of Volvo’s commitment to the environ- Volvo is committed to the well being of its cus- tion engines, Volvo is actively looking at ment, it is essential for the vehicle to be recy- tomers.
  • Page 15: Important Warnings

    Your new ted, or if you allow accessories to be instal- quicker and simpler. Volvo is, or can be, equipped with many fea- led by someone unfamiliar with your vehi- • Never use portable computers or personal ture-rich entertainment and communication cle.
  • Page 16 Occupant safety..................18 Seat belts....................20 Supplemental Restraint System.............. 23 Front airbags................... 24 Occupant Weight Sensor................ 28 Side impact protection airbags............... 31 Inflatable Curtain..................33 Whiplash Protection System..............35 Child safety..................... 37 Child restraint systems................40 Infant seats....................42 Convertible seats..................44 Booster cushions..................
  • Page 17 S A F E T Y I n f o r m a t i o n P r o v i d e d b y :...
  • Page 18: 01 Safety

    Safety is the Volvo cornerstone. Our concern If you are taking any medication, consult exists in a group of vehicles, it may dates back to 1927 when the first Volvo rolled your physician about its potential effects order a recall and remedy campaign.
  • Page 19 If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform Trans- port Canada in addition to notifying Volvo Cars of Canada Corp. Transport Canada can be contacted at:...
  • Page 20: Seat Belts

    Volvo also believes no child should sit in the front seat of a vehicle. Unbuckling the seat belt To remove the seat belt, press the red section Most states and provinces make it mandatory on the seat belt receptacle.
  • Page 21 • Never repair the belt yourself; have this work done by an authorized Volvo serv- ice technician only. The seat belt should always be worn during •...
  • Page 22 01 Safety Seat belts steering wheel). Within this context, they should strive to position the seat with as large a distance as possible between their belly and the steering wheel. Child seats Please see page 38 for information on secur- ing child seats with the seat belts.
  • Page 23: Supplemental Restraint System

    As an enhancement to the three-point seat ence in the system could cause mal- 1. Switch off the ignition for at least belts, your Volvo is equipped with a Supple- function and serious injury. All work on 10 minutes and disconnect the battery.
  • Page 24: Front Airbags

    01 Safety Front airbags • The front airbag system The driver's side front airbag is folded and located in the steering wheel hub. • The passenger's side front airbag is folded behind a panel located above the glove compartment. WARNING •...
  • Page 25 Volvo Cars of Canada Corp. impact of the collision and the inertial • Volvo's front airbags use special sen- forces generated by it, and to determine if National Customer Service sors that are integrated with the front the intensity of the collision is sufficient for seat buckles.
  • Page 26 01 Safety Front airbags WARNING WARNING • • Do not use child safety seats or child Children must never be allowed in the booster cushions/backrests in the front front passenger's seat. passenger's seat. We also recommend • Occupants in the front passenger's seat that occupants under 4 feet 7 inches must never sit on the edge of the seat, (140 cm) in height who have outgrown...
  • Page 27 Never try to open the airbag cover on the steering wheel or the passenger's side dashboard. This should only be done by a trained and qualified Volvo service technician. Failure to follow these instructions can result in injury to the vehicle occupants.
  • Page 28: Occupant Weight Sensor

    Occupant Weight Sensor (OWS) indicator light However, if a fault is detected in the system: installed according to the manufacturer's Volvo recommends that ALL occupants (adults instructions, • The OWS indicator light will stay on and children) shorter than 4 feet 7 inches •...
  • Page 29 This will allow the system to Volvo recommends that children always be properly The OWS is designed to disable (will not inflate) restrained in appropriate child restraints in the rear seats.In...
  • Page 30 • The seat belt should never be wrapped the armrest in the door or the center Volvo Cars of North America, LLC around an object on the front passeng- console, by pressing the feet on the er's seat. This could interfere with the...
  • Page 31: Side Impact Protection Airbags

    01 Safety Side impact protection airbags Side impact airbags – front seats only NOTE SIPS airbag deployment (one airbag) occurs only on the side of the vehicle affected by the impact. The airbags are not designed to deploy in all side impact situations. Components in the SIPS airbag system This SIPS airbag system consists of gas gen- erators and side airbag modules built into the...
  • Page 32 Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician. • In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright posi- tion with the seat belt properly fastened.
  • Page 33: Inflatable Curtain

    Side Impact Protection System. It is not designed to deploy during collisions from the front or the rear of the vehicle. The inflatable curtains in the Volvo XC90 are • Never try to open or repair any compo- also designed to help protect the occupants of This system consists of inflatable curtains nents of the IC system.
  • Page 34 01 Safety Inflatable Curtain WARNING In order for the IC to provide its best pro- tection, both front seat occupants and both outboard rear seat occupants should sit in an upright position with the seat belt prop- erly fastened; adults using the seat belt and children using the proper child restraint sys- tem.
  • Page 35: Whiplash Protection System

    01 Safety Whiplash Protection System Whiplash Protection System (WHIPS) – front seats only The Whiplash Protection System (WHIPS) con- WARNING WARNING sists of specially designed hinges and brackets • The WHIPS system is designed to sup- Occupants in the front seats must never sit on the front seat backrests designed to help out of position.
  • Page 36 WHIPS system. seat is folded down, the occupied front and qualified Volvo service technician, • If the rear seat backrests are folded seats must be adjusted forward so that they...
  • Page 37: Child Safety

    When a child has outgrown the child safety or increasing the injury of a child. seat, you should use the rear seat with the Volvo recommends the proper use of restraint standard seat belt fastened. The best way to systems for all occupants including children.
  • Page 38 When attaching the seat belt to a child Volvo's recommendations WARNING seat: Why does Volvo believe that no child should sit • Do not use child safety seats or child 1. Attach the seat belt to the child seat in the front seat of a car? It's quite simple really.
  • Page 39 01 Safety Child safety seat of any vehicle with a front passenger side airbag. • Drive safely! Child restraint registration and recalls Registering a child restraint Child restraints could be recalled for safety reasons. You must register your child restraint to be reached in a recall.
  • Page 40: Child Restraint Systems

    01 Safety Child restraint systems Child restraints Convertible seat Booster cushion Infant seat WARNING WARNING There are three main types of child restraint A child seat should never be used in the Always refer to the child restraint manufac- systems: infant seats, convertible seats, and front passenger seat of any vehicle with a turer's instructions for detailed information booster cushions.
  • Page 41 • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.
  • Page 42: Infant Seats

    01 Safety Infant seats Securing an infant seat with a seat belt Positioning the seat belt through the infant seat Fasten the seat belt Do not place the infant seat in the front passeng- WARNING WARNING er's seat • A child seat should never be used in the An infant seat must be in the rear-facing NOTE front passenger seat of any vehicle with a...
  • Page 43 01 Safety Infant seats 3. Fasten the seat belt by inserting the latch WARNING plate into the buckle (lock) until a distinct It should not be possible to move the child click is audible. restraint (child seat) more than 1 in. (2.5 cm) in any direction along the seat belt path.
  • Page 44: Convertible Seats

    See the con- able part of its total weight and its neck is vertible seat manufacturer's recommenda- still very weak. Volvo recommends that chil- tions. dren up to age 4 travel, properly restrained, facing rearward.
  • Page 45 01 Safety Convertible seats WARNING • Convertible child seats should be instal- led in the rear seat only. • A rear-facing convertible seat should not be positioned behind the driver's seat unless there is adequate space for safe installation. 1. Place the convertible seat in the rear seat of the vehicle.
  • Page 46 01 Safety Convertible seats WARNING A child seat should never be used in the front passenger seat of any vehicle with a front passenger airbag – not even if the PASSENGER AIRBAG OFF symbol near the rear-view mirror is illuminated (on vehi- cles equipped with Occupant Weight Sen- sor).
  • Page 47: Booster Cushions

    01 Safety Booster cushions Securing a booster cushion Positioning the seat belt Position the child correctly on the booster cushion 4. Ensure that the seat belt is pulled taut and fits snugly around the child. Booster cushions are recommended for chil- dren who have outgrown convertible seats.
  • Page 48: Isofix/Latch Lower Anchors

    WARNING point and secure the restraint with the vehicle's center seat belt. Volvo's ISOFIX/LATCH anchors conform to • Always follow your child seat manufac- FMVSS/CMVSS standards. Always refer to turer's installation instructions, and use...
  • Page 49 01 Safety ISOFIX/LATCH lower anchors WARNING Be sure to fasten the attachment correctly to the anchor (see the illustration). If the attachment is not correctly fastened, the child restraint may not be properly secured in the event of a collision. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 50: Top Tether Anchors

    01 Safety Top tether anchors Top tether anchors WARNING WARNING Be sure to fasten the child tether attachment • Never route a top tether strap over the correctly to the anchor. If it is not correctly top or around the head restraint. It fastened, the child seat may not be properly should always be routed under the head restrained in the event of a collision.
  • Page 51: Integrated Booster Cushion

    (15 and 36 kg) and whose height is between 38 and 54 in (97 and 137 cm). In Canada, Transport Canada's weight Volvo's own integrated booster cushion has recommendation is 40 – 80 lbs (18 - 36 kg). been specially designed to help safeguard a child seated in the rear seat.
  • Page 52 01 Safety Integrated booster cushion The booster cushion must be pressed down before the backrest can be folded down. Raising 1. Pull the handle at the front of the cushion forward. 2. Move the seat belt latch aside before rais- ing the cushion.
  • Page 53 01 Safety I n f o r m a t i o n P r o v i d e d b y :...
  • Page 54 Instrument overview................56 Instrument panel..................58 Information display.................. 62 Center console buttons................64 Steering wheel adjustment..............66 Lighting panel..................67 Manually unlocking the fuel filler door............ 69 Left-side steering wheel lever..............70 Right-side steering wheel lever............... 71 Hazard warning flashers................. 74 Trip computer..................
  • Page 55 I N S T R U M E N T S A N D C O N T R O L S I n f o r m a t i o n P r o v i d e d b y :...
  • Page 56: 02 Instruments And Controls

    02 Instruments and controls Instrument overview I n f o r m a t i o n P r o v i d e d b y :...
  • Page 57: Instruments And Controls

    02 Instruments and controls Instrument overview Headlights/Parking lights Horn Control panel in the driver's door Panel vents Cruise control buttons in steering wheel Display Turn signals, High/low beams, READ-but- Temperature gauge Parking brake pedal Odometer/Trip odometer/Cruise control Parking brake release handle indicator Speedometer Reading lights...
  • Page 58: Instrument Panel

    02 Instruments and controls Instrument panel Instrument panel Turn signal indicators – right/left odometers 1 and 2 using one short press Speedometer on the button. – The display presents infor- Text window – The text window displays Warning symbol mation and warning messages, the ambi- information and warning messages.
  • Page 59 02 Instruments and controls Instrument panel Gear and driving mode indicator – The cur- Warning/information symbol in center of rently selected driving mode is displayed the instrument panel here. If you use the Geartronic function on This symbol shines as a red or yel- the automatic transmission, the currently low light depending on the nature selected gear will be displayed.
  • Page 60 If the brake fluid level is above the MIN mark, check the engine oil level, see Have the system(s) inspected by a trained and drive carefully to a trained and qualified Volvo page 62. If the light stays on after qualified Volvo service technician as soon as...
  • Page 61 153. potentially may need correcting. When this happens, please have your vehicle checked by Tire pressure monitoring light a trained and qualified Volvo service technician See page 194 for more informa- as soon as possible. tion on this function. A CHECK ENGINE light may have many cau- ses.
  • Page 62: Information Display

    SEE MANUAL Refer to your owner's manual. For additional information, please contact your Volvo retailer. Take your vehicle to a trained and qualified Volvo service technician for inspection at your convenience SERVICE REQUIRED (but preferably before the next scheduled maintenance service).
  • Page 63 12 months, whichever occurs first, to remind the driver that the service interval has been exceeded. The message will be displayed for 2 minutes each time the vehicle is started until reset by a trained and qualified Volvo service technician. OIL LEVEL LOW – FILL OIL Check the oil level and top up if necessary, see page 215.
  • Page 64: Center Console Buttons

    02 Instruments and controls Center console buttons Active Bending Lights* Rear seat air conditioning* Folding door mirrors* The beams of these headlights This button controls the Press the button and release it adjust laterally to help light up a optional rear seat air condition- to fold the door mirrors in or curve according to movements ing system.
  • Page 65 The auxiliary sockets can also be used for cigarette lighters, which are available as NOTE accessories at your Volvo retailer. The system activates automatically when the engine is started, and can be deacti- vated by pressing this button (e.g. when towing a trailer) or reactivated if necessary.
  • Page 66: Steering Wheel Adjustment

    02 Instruments and controls Steering wheel adjustment Both the height and the reach of the steering wheel can be adjusted to a comfortable posi- tion for the driver. Pull down the lever on the left of the steering column. Adjust the steering wheel to a suitable position and press the lever back into place to lock the steering wheel in the new position.
  • Page 67: Lighting Panel

    02 Instruments and controls Lighting panel Parking lights NOTE The front and rear parking lights can be turned Active Bending Lights*: Turn the headlight on even when the ignition is switched off. switch to position 0 to activate a daylight ±...
  • Page 68 02 Instruments and controls Lighting panel Active Bending Lights (ABL)* 2. Press button (3) to turn on the rear fog light. NOTE When this function is activated, the headlight An indicator light in the button illuminates when If the fuel filler door does not unlock after the beams adjust laterally to help light up a curve the rear fog light is on.
  • Page 69: Manually Unlocking The Fuel Filler Door

    02 Instruments and controls Manually unlocking the fuel filler door Panel on passenger's side of cargo area To manually unlock the fuel filler door 6. Move the catch rearward to unlock the fuel filler door lock, or move it forward to lock 1.
  • Page 70: Left-Side Steering Wheel Lever

    , 60 or 90 seconds. The time interval can be changed by a trained and qualified Volvo service technician. Factory setting I n f o r m a t i o n P r o v i d e d b y :...
  • Page 71: Right-Side Steering Wheel Lever

    02 Instruments and controls Right-side steering wheel lever • Windshield wipers Intermittent wiper function When approximately 1 US quart (1 liter) remains in the washer fluid reservoir, the With the lever in this position, you headlights will not be washed when the can set the wiper interval by twist- lever is pulled to conserve washer fluid for ing the control ring (1) upward to...
  • Page 72 Press button (2), see page 71. Consult your Volvo retailer if you would like to have this function deactivated. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 73 02 Instruments and controls Right-side steering wheel lever IR-reflecting windshield* Section of the windshield where the IR-coating is not applied An optional factory-installed infrared (IR) coa- ting can be applied to the windshield to help protect the cabin from the sun's heat and the fading effect of sunlight on upholstery, panels, etc.
  • Page 74: Hazard Warning Flashers

    02 Instruments and controls Hazard warning flashers Hazard warning flashers Rear window and door mirror defroster Press the switch to start heat- ing the rear window and door mirrors to remove ice or con- densation. A light in the switch will light up.
  • Page 75: Trip Computer

    02 Instruments and controls Trip computer • Trip computer* Current speed in mph (Canadian models of driving and the amount of fuel remaining in only) the tank when the reading was taken. • DSTC (see page 153 for detailed informa- "----"...
  • Page 76 02 Instruments and controls Trip computer 6. Current speed in miles per hour (Canadian models only) This function provides the driver with an instan- taneous conversion of the vehicle's current speed from km/h to mph. NOTE Trip computer readings may vary slightly depending on the circumference of the tires on the vehicle and driving style.
  • Page 77: Cruise Control

    02 Instruments and controls Cruise control Engaging the cruise control function Increasing or decreasing speed Braking • Cruise control is automatically disengaged when the brake pedal is depressed. The currently set speed is stored in memory. • Pressing resume will return the vehicle to the previously set speed.
  • Page 78 02 Instruments and controls Cruise control Temporarily disengaging the cruise control 1. Press 0 to temporarily disengage cruise control. > CRUISE will be displayed in the infor- mation window in the instrument panel. 2. Depress the brake pedal. causes the vehicle to Pressing "resume"...
  • Page 79: 12-Volt Sockets

    The auxiliary socket can also be used to power a cigarette lighter. Accessory cigarette lighters NOTE and ashtrays can be purchased from your Volvo retailer. • If the 12-volt sockets are used while the engine is not running, there is a risk that the vehicle's battery will be discharged.
  • Page 80: Hood/Tailgate

    02 Instruments and controls Hood/tailgate Opening/closing the hood To fold down the lower section of the tailgate, WARNING pull handle upward. • Do not grasp the ribs in the grille when closing the hood. If your fingers pro- trude through the grille, they could be injured on components in the engine compartment as the grille closes.
  • Page 81: Power Windows

    02 Instruments and controls Power windows Power windows WARNING The power windows are controlled by buttons Always remove the ignition key when the in the arm rests. The ignition switch must be vehicle is unattended. (ignition key in position I, II or the engine Make sure that the windows are completely running) for the electrically operated windows unobstructed before they are operated.
  • Page 82 02 Instruments and controls Power windows Lockout switch for rear windows The power rear door windows can be disabled by a switch located on the driver's door (see illustration). If the light in the switch is OFF: The rear door windows can be raised or lowered with the buttons on the rear door armrests or with the buttons on the driver's door armrest.
  • Page 83: Mirrors

    02 Instruments and controls Mirrors Rearview mirror or when the engine is running. The compass NOTE can be switched off or on by pressing the inset This function is automatically switched off button on the rear side of the mirror (see the when the gear selector is placed in the inset illustration).
  • Page 84 02 Instruments and controls Mirrors 2. Press the button on the rear side of the Calibrating the compass Power door mirrors mirror with straightened paperclip or simi- 1. Stop the car in a large, open area, away lar object for approximately 3 seconds until from traffic.
  • Page 85 02 Instruments and controls Mirrors For information about the optional folding mir- CAUTION ror function see page 64. Use the heating function to remove ice, snow, or mist from the mirrors. WARNING The mirrors should always be adjusted prior to driving. Objects seen in the passenger's side wide-angle door mirror are closer than they appear to be.
  • Page 86: Power Moonroof

    02 Instruments and controls Power moonroof Power moonroof Auto open: Pull the switch as far back as pos- sible (position 4) and release it to automatically slide open the moonroof to the "comfort" position. Pull the switch rearward again to open the moonroof completely.
  • Page 87 02 Instruments and controls Power moonroof WARNING • Never open/close the moonroof if it is obstructed in any way when in opera- tion. • Never allow a child to operate the moonroof. • Never extend any object or body part through the open moonroof, even if the vehicle's ignition is completely switched off.
  • Page 88: Homelink ® Wireless Control System

    02 Instruments and controls ® HomeLink Wireless Control System* Introduction Programming HomeLink WARNING • If you use HomeLink to open a garage NOTE door or gate, be sure no one is near the gate or door while it is in motion. Some vehicles may require the ignition switch to be turned on or to the second •...
  • Page 89 02 Instruments and controls ® HomeLink Wireless Control System* found where the hanging antenna wire is cedures, replace “Programming HomeLink” NOTE attached to the motor-head unit. step 2 with the following: Some devices may require you to replace • 5. Firmly press and release the “learn” or Continue to press and hold the HomeLink this Programming Step 2 with procedures button while you press and release -...
  • Page 90 02 Instruments and controls ® HomeLink Wireless Control System* Erasing HomeLink Buttons For questions or comments, contact HomeLink at: www.homelink.com or 1–800–355–3515. To erase programming from the three Home- Link buttons (individual buttons cannot be This device complies with FCC rules part 15 erased but can be “reprogrammed”...
  • Page 91 02 Instruments and controls I n f o r m a t i o n P r o v i d e d b y :...
  • Page 92 Climate control system – general information........94 Air distribution..................96 Electronic climate control (ECC)............. 98 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 93 C L I M A T E I n f o r m a t i o n P r o v i d e d b y :...
  • Page 94: 03 Climate

    Work of this type should only be done If your vehicle has been parked in the sun in by a trained and qualified Volvo service tech- Always keep the air intake grille at the base of the windshield free of snow.
  • Page 95 03 Climate Climate control system – general information Climate system blower The following points pertain if the ignition is on but the engine in not running: The climate system blower will be automati- cally switched off when the engine is not run- •...
  • Page 96: Air Distribution

    03 Climate Air distribution Air distribution Air vents in the dash Air vents in the door pillars The incoming air is distributed through the ven- Open Open tilation points in the passenger compartment Closed Closed shown above. Horizontal air flow Horizontal air flow Vertical air flow Vertical air flow...
  • Page 97 03 Climate Air distribution Ventilated front seats* For maximum ventilation: ± Hold down for approximately 2 sec- onds. To gradually decrease ventilation: ± Press briefly on To switch off ventilation: ± Hold down for approximately 2 sec- onds. The ventilation can be used at the same time as seat heating*, for example, to help dry damp clothing.
  • Page 98: Electronic Climate Control (Ecc)

    03 Climate Electronic climate control (ECC) Overview AC – (ON/OFF) Temperature passenger´s side will only function if the blower is not switched off. Recirculation/Multifilter with sensor* Temperature driver´s side Press the switch to turn the air conditioning on or off. The "ON" or "OFF" LED will light up to Recirculation Blower indicate if the system is switched on or off.
  • Page 99 03 Climate Electronic climate control (ECC) minated outside air, the air intake closes and recirculation button is pressed, the climate Air distribution control system will recirculate the air in the the air inside the passenger compartment is passenger compartment for recirculated, i.e.
  • Page 100 Temperature already on and if the passenger compart- Heated rear seats (XC90 Executive*) These controls are used to individually set the ment blower is not turned off) to dehumid- temperature for both sides of the passenger ify the air in the passenger compartment.
  • Page 101 03 Climate Electronic climate control (ECC) Operation Press to operate the air quality sensor (normal setting). Select one of the following three functions by pressing 1, 2 or 3 times. 1. The AUT LED lights. The air quality sensor is now activated. 2.
  • Page 102 Front seats.................... 104 Rear seats..................... 108 Interior lighting..................111 Storage compartments................. 113 Securing cargo..................118 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 103 I N T E R I O R I n f o r m a t i o n P r o v i d e d b y :...
  • Page 104: 04 Interior

    04 Interior Front seats Manually adjusted front seats 1. Move the seat as far back as possible. WARNING 2. Adjust the backrest to the upright position. • Do not adjust the seat while driving. The seat should be adjusted so that the 3.
  • Page 105 04 Interior Front seats Power seat* NOTE The power seats have an overload protector Operation that activates if a seat is blocked by any Driver's seat: The seat can be adjusted if the object. If this occurs, switch off the ignition ignition key is in position I, II or if the engine is (key in position 0 ) and wait for a short period running.
  • Page 106 04 Interior Front seats 1. Unlock the driver's door with the same WARNING remote key (the one used to lock the doors) • Because the driver's seat can be 2. Open the driver's door within 2 minutes. adjusted with the ignition off, children should never be left unattended in the The driver's seat will automatically move to the vehicle.
  • Page 107 04 Interior Front seats 3. With the MEM button depressed, press Massage Lumbar support button 1 briefly to store the seat's current position. To move the seat to the position that it was in when button 1 was programmed: Press and hold down button 1 until the seat stops moving.
  • Page 108: Rear Seats

    04 Interior Rear seats Entering the third row of seats Removing the center console Sliding center seat – second row (seven- In order to make it possible to move the center seat models only) Tilting the outboard backrests in the seat in the second row of seats as far forward The center seat in the second row can be second row of seats:...
  • Page 109 04 Interior Rear seats Head restraint – second row, center position The head restraint in the center position can be adjusted to 4 different heights. To raise – pull the restraint up until it clicks into one of the four heights positions. To lower –...
  • Page 110 04 Interior Rear seats 3. Pull the handle (1) outward to release the 1. Move the seats in the second row as far WARNING backrest. The backrests are designed to forward as possible, see page 108. • When one or more sections of the back- lock at a 45 degree angle.
  • Page 111: Interior Lighting

    The courtesy light timer periods can be 10 minutes after the engine has been turned also activates the automatic function. changed. Contact a trained and qualified Volvo off. The lights can be turned off sooner by service technician. pressing the respective buttons.
  • Page 112 04 Interior Interior lighting Vanity mirror The light comes on when you open the cover. Glove compartment lighting The light in the glove compartment comes on or switches off when its door is opened or closed. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 113: Storage Compartments

    04 Interior Storage compartments I n f o r m a t i o n P r o v i d e d b y :...
  • Page 114 This lid can be folded back Ashtray (accessory) to form a small table area for rear seat passen- An ashtray insert is available from your Volvo gers. retailer. This insert slides into either of the cup Lift the tray under the lid to expose the deep holders.
  • Page 115 • The cup holder insert can be removed to Ashtray (accessory) provide space for a large plastic bottle. Pull An ashtray insert is available from your Volvo the insert straight up to remove it. Press retailer. down to reinsert it.
  • Page 116 04 Interior Storage compartments Coat hanger Storage space between rear seats Rear side storage compartments and The jacket hanger is located on the inboard This storage space provides compartments for cup holders (seven-seat models) side of the front passenger's seat head pens or other small items.
  • Page 117 04 Interior Storage compartments Refrigerator* The refrigerator is located under the cover in the front seat center armrest. Use the button (see the inset illustration) to adjust the level of cooling. The refrigerator functions when the engine is running or when the ignition is in position II. WARNING Bottles kept in the refrigerator should be firmly sealed and the cover over the refrig-...
  • Page 118: Securing Cargo

    If no one is sitting in the outboard rear being thrown forward in the event of sudden The Volvo XC90 can be equipped with a cargo seat(s), reinforce the backrest by fastening braking, etc. The vehicle is equipped with eye- net made of strong nylon fabric.
  • Page 119 04 Interior Securing cargo The cargo net can be stored under the floor of NOTE the cargo area on five-seat models. On seven-seat models: When using the net in the rear attachment brackets, be sure it is WARNING installed in front of the side armrests. •...
  • Page 120 04 Interior Securing cargo Steel grid (accessory) sion the attachment bracket in the cargo eyelet. Installing the grid, upper attachments 4. Repeat the operation on the opposite side. 1. Lift in the grid through the tailgate or through one of the rear passenger doors (in 5.
  • Page 121 04 Interior Securing cargo Cargo area cover* Grocery bag holder 1. Fold down the lower section of the tailgate. Installing the cargo area cover: 1. Press the end pieces of the cargo area 2. Fold up the rear section of the cargo com- cover down in the holders.
  • Page 122 Remote keys and key blades..............124 Locking and unlocking................128 Child safety locks.................. 130 Alarm..................... 131 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 123 L O C K S A N D A L A R M I n f o r m a t i o n P r o v i d e d b y :...
  • Page 124: 05 Locks And Alarm

    Turn the key blade once in the opposite direction to lock all doors and the tailgate. Each key has a unique code, which your Volvo retailer uses if new keys are required. A maxi- Use the switch on the driver's door armrest to mum of six remote keys can be programmed lock/unlock the vehicle from the inside.
  • Page 125 If either of the remote keys is lost, the other the button again (within 10 seconds) to unlock should be taken with the car to a Volvo retailer. all doors, and the tailgate. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 126 05 Locks and alarm Remote keys and key blades ditions: (1) This device may not cause harmful Tailgate unlock NOTE interference, and (2) this device must accept Press this button to unlock the tailgate (without • If an airbag deploys, your vehicle's SRS any interference received, including interfer- unlocking the other doors).
  • Page 127 WARNING NOTE Never use the transmitter to lock the doors The old battery should be disposed of prop- from inside the vehicle. erly at a recycling center or at your Volvo retailer. • Doing so would ACTIVATE: • the break-in alarm, which would sound if one of the doors were opened •...
  • Page 128: Locking And Unlocking

    05 Locks and alarm Locking and unlocking 2. Press the lock section of the button. 2. Press the READ button on the left-side steering wheel lever to erase any mes- 3. Close the door. This will lock the vehicle sages that may be displayed in the infor- completely and arm the alarm.
  • Page 129 05 Locks and alarm Locking and unlocking Automatic relocking If you use the tailgate unlock button to unlock the tailgate without opening it, it will automati- cally relock after approximately 2 minutes. NOTE If you open the tailgate and close it again, it will remain unlocked and the alarm will not be rearmed.
  • Page 130: Child Safety Locks

    05 Locks and alarm Child safety locks REAR Child safety locks in the rear doors Child safety lock in the tailgate Power child locks* Manual child safety locks – rear doors/ To prevent the rear doors from being opened WARNING tailgate from the inside: Remember, in the event of an accident, the...
  • Page 131: Alarm

    "Panic" button • The siren is disconnected when the alarm Contact a trained and qualified Volvo serv- In an emergency situation, this feature can be is disarmed. ice technician. used to attract attention.
  • Page 132 General information................134 Fuel requirements................. 135 Refueling....................137 Starting the vehicle................139 Ignition switch and steering wheel lock..........141 Economical driving................142 Difficult driving conditions..............143 Automatic transmission................ 144 Jump starting..................147 All Wheel Drive*..................148 Brake system..................149 Parking brake..................152 Stability system..................
  • Page 133 S T A R T I N G A N D D R I V I N G I n f o r m a t i o n P r o v i d e d b y :...
  • Page 134: 06 Starting And Driving

    "oxygenated" fuel. Fuel requirements result in loss of emission warranty coverage. Volvo allows the use of the following "oxygen- State and local vehicle inspection programs Deposit control gasoline (detergent ated" fuels; however, the octane ratings listed...
  • Page 135: Fuel Requirements

    Unburned benzene has been strongly linked to affect engine reliability. certain forms of cancer. If you live in an area Volvo engines are designed to achieve rated where you must fill your own gas tank, take horsepower, torque, and fuel economy per- precautions.
  • Page 136 A warning message will be displayed in the Handling, roadholding text window in the instrument panel when Volvo allows the use of the following "oxygen- Vehicle load, tire design and inflation pressure the battery charge is low. ated" fuels; however, the octane ratings listed all affect vehicle handling.
  • Page 137: Refueling

    06 Starting and driving Refueling Fuel filler door You can also keep the vehicle locked if you needle nears the red zone, or when the fuel remain inside it during refueling. The central warning light comes on. locking button does not lock the fuel filler door. Be sure the fuel filler door is not obstructed and WARNING is completely closed after refueling.
  • Page 138 If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps.
  • Page 139: Starting The Vehicle

    104. these pedals is not impeded. noticeably higher than normal for a • Volvo's floor mats are specially manu- short period. This is done to help bring factured for your car. They must be components in the emission control 1.
  • Page 140 06 Starting and driving Starting the vehicle NOTE CAUTION Your vehicle is equipped with a KEYLOCK Automatic transmission system. When the engine is switched off, • The engine should be idling when you the gear selector must be in the P position move the gear selector.
  • Page 141: Ignition Switch And Steering Wheel Lock

    06 Starting and driving Ignition switch and steering wheel lock Ignition switch and steering wheel lock WARNING III – Start position: Release the key when the 0 – Locked position: Never switch off the ignition (turn the ignition engine starts. The key Remove the key to lock key to position 0) or remove the key from the returns automatically to...
  • Page 142: Economical Driving

    06 Starting and driving Economical driving • Economical driving conserves natural Note that roof racks, ski racks, etc, increase air resistance and also fuel con- resources sumption. Better driving economy may be obtained by • At highway driving speeds, fuel consump- thinking ahead, avoiding rapid starts and stops tion will be lower with the air conditioning and adjusting the speed of your vehicle to...
  • Page 143: Difficult Driving Conditions

    Difficult driving conditions Driving on rough/unpaved surfaces NOTE CAUTION The Volvo XC90 is designed primarily for on- Avoid driving on steep inclines if the fuel • Engine damage will occur if water is road driving, and it has excellent handling cha- tank is nearly empty.
  • Page 144: Automatic Transmission

    06 Starting and driving Automatic transmission N (Neutral) Automatic transmission – shift gate positions Neutral – no gear engaged. Use the parking brake. WARNING Never leave the vehicle unattended when the engine is running. If, by mistake, the gear selector is moved from P, the vehicle may start moving.
  • Page 145 06 Starting and driving Automatic transmission While driving W – Winter/Wet driving mode – NOTE enhanced vehicle traction If you select the MAN position while driving, the The gear selector must be in the D (Drive) gear that was being used in the D position will position for kickdown to function.
  • Page 146 06 Starting and driving Automatic transmission NOTE Mode W can be chosen regardless of the postion of the gear selector but will only function when the gear selector is in the D (drive) position. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 147: Jump Starting

    06 Starting and driving Jump starting 2. First connect the auxiliary battery positive WARNING (+) terminal (1) to the positive (+) terminal in • Do not connect the jumper cable to any your vehicle's engine compartment (2), part of the fuel system or to any moving located under a small black plastic cover parts.
  • Page 148: All Wheel Drive

    The temporary spare tire is for temporary, low- speed, short-distance use only. Replace it with Your Volvo can be equipped with an electron- a full-sized tire as soon as possible. Do not ically controlled All Wheel Drive system*, which...
  • Page 149: Brake System

    DO NOT DRIVE window: . Have the vehicle large stones. towed to a trained and qualified Volvo serv- ably higher pressure will be required on the ice technician and have the brake system brake pedal to compensate for the lack of inspected.
  • Page 150 DO NOT DRIVE. Have the vehicle towed to a trained and qualified Volvo serv- Anti-lock brakes (ABS) ice technician and have the brake system If the warning lamp lights up there is a inspected.
  • Page 151 • If the brake fluid level is above the MIN mark, drive carefully to a trained and quali- fied Volvo service technician and have the brake system inspected. Emergency Brake Assistance (EBA) The EBA function is designed to provide full brake effect immediately in the event of sud- den, hard braking.
  • Page 152: Parking Brake

    06 Starting and driving Parking brake 3. Release the brake pedal and ensure that the vehicle is at a standstill. 4. If the vehicle rolls, the parking brake pedal must be pushed down more firmly. 5. When parking a vehicle always put the gear selector in P.
  • Page 153: Stability System

    06 Starting and driving Stability system Dynamic Stability Traction Control NOTE (DSTC) • The message DSTC SPIN CONTROL The stability system consists of a number of indicates that the stability sys- functions designed help reduce wheel spin, tem's spin control function has tempo- counteract skidding, and to generally help rarily been switched off.
  • Page 154 A trained and qualified • If the indicator light goes out, the fault was be adapted to traffic and road conditions. Volvo service technician should check the temporary and no further action is system. required.
  • Page 155: Front/Rear Park Assist

    Park Assist is an information system, NOT a Rear park assist is deactivated automati- safety system. This system is designed to cally when towing a trailer if Volvo genuine be a supplementary aid when parking the trailer wiring is used.
  • Page 156 Consult a trained and qualified Volvo service technician. Audible signals from the park assist CAUTION system...
  • Page 157: Towing

    06 Starting and driving Towing Positions for attaching towing eyelets • Emergency towing After the vehicle has been towed, the eyelet Maximum speed: 50 mph (80 km/h). Do not exceed the maximum allowable towing should be removed and returned to the tool The towing eyelet is located in the tool bag, speed.
  • Page 158 All Wheel Drive Vehicles with AWD (All Wheel Drive) with the • Remember that the power brakes and Volvo recommends the use of flat bed equip- front wheels off the ground should not be power steering will not function when ment.
  • Page 159: Towing A Trailer

    06 Starting and driving Towing a trailer The maximum weights recommended by Volvo load should be positioned so that it does not for trailers with brakes are shown in the table shift and the tongue load should be 10% of the trailer's weight.
  • Page 160 Consult your Volvo retailer. • Do not connect the trailer's brake system • Volvo recommends the use of Volvo trailer directly to the vehicle's brake system. hitches that are specially designed for the vehicle. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 161 Consult a trained and qualified Volvo service technician for correct installation. • When towing a trailer, the trailer's safety wire must be correctly fastened to the hole or hook provided in the trailer hitch on the vehicle.
  • Page 162: Detachable Trailer Hitch

    2. Pull the ball holder out of the hitch assem- bly. A cover for the hitch assembly can be pur- chased from your Volvo retailer. Ball holder Locking bolt Cotter pin Hitch assembly...
  • Page 163: Load Carriers (Accessory)

    06 Starting and driving Load carriers (accessory) Positioning load carriers If wing-shaped load carriers are used, make sure that they are installed on the roof rails with the rounded edge forward. Load carriers of this type are identical and can be placed anywhere along the roof rails.
  • Page 164: Cold Weather Precautions

    Synthetic oil is not used when the oil is changed at the normal maintenance service intervals except at owner request and at additional charge. Please consult your Volvo retailer. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 165: Before A Long Distance Trip

    To prevent injury from contact with hot surfaces, do not inspect your vehicle’s transmission fluid yourself. Have your vehicle’s transmission fluid level inspected by a qualified Volvo service technician. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 166: Blind Spot Information System

    06 Starting and driving Blind Spot Information System* your vehicle, and up to approximately 31 ft. (9.5 meters) behind the side-view mirror), see the illustration, the indicator light in the door panel (2) illuminates. The light will glow contin- uously to alert the driver of the vehicle in the blind area.
  • Page 167 06 Starting and driving Blind Spot Information System* When you pass another vehicle: vehicle in the blind area must have its head- Limitations lights on. This means, for example, that the In certain situations, the BLIS indicator light(s) The system reacts when you pass another system will not detect a trailer without head- may illuminate even when there are no other vehicle at a speed of up to 6 mph (10 km/h)
  • Page 168 Text in the dis- play BLIND-SPOT BLIS not functioning properly. Contact an SYST SERVICE authorized Volvo REQUIRED service technician. The vehicle's own shadow against a large, light, BLIND-SPOT The right side BLIS smooth surface such as barriers between lanes on SYST R CAMERA camera is obscured.
  • Page 169 06 Starting and driving Blind Spot Information System* System status Text in the dis- play BLIND-SPOT INFO BLIS system on SYSTEM ON BLIND-SPOT The BLIS cameras' function has been SYST FUNCTION reduced due to REDUCED weak or impaired data transfer between the BLIS system's cameras and the vehicle's...
  • Page 170 General information................172 Tire inflation ..................175 Tire inflation pressure table..............177 Tire designations................... 178 Glossary of tire terminology..............180 Vehicle loading..................181 Uniform Tire Quality Grading..............182 Snow chains, snow tires, studded tires..........183 Temporary spare................... 184 Tire Sealing System ................185 Changing wheels...................
  • Page 171 W H E E L S A N D T I R E S I n f o r m a t i o n P r o v i d e d b y :...
  • Page 172: 07 Wheels And Tires

    Otherwise there is a risk of altering at 6-year intervals, even if it has never been the car's roadholding and handling characte- Some Volvo models are equipped with an used. ristics. Ultra High Performance tire and wheel com-...
  • Page 173 • The wheel and tire sizes for your Volvo wheels to reduce the chance of oversteer aside rain, snow and slush. are specified to meet stringent stability during hard braking.
  • Page 174 1/16" (1.6 mm). The tires have wear indicator strips running Your Volvo retailer can also provide guidance across or parallel to the tread. The letters TWI based on your particular driving circumstan- are printed on the side of the tire.
  • Page 175: Tire Inflation

    07 Wheels and tires Tire inflation Inflation placard temperature drop causes a corresponding NOTE drop of 1 psi (7 kPa) in inflation pressure. Check The placards shown indicate inflation pres- your tire pressures frequently and adjust them sure for the tires installed on the vehicle at to the proper pressure, which can be found on the factory only.
  • Page 176 07 Wheels and tires Tire inflation pressures. A hot tire at or below recommended Load ratings NOTE cold inflation pressure could be significantly See page 178 for an explanation of the load • If you overfill the tire, release air by under-inflated.
  • Page 177: Tire Inflation Pressure Table

    Tire inflation pressure table The following tire pressures are recommended tion placard (see page 175 for its location) for by Volvo for your vehicle. Refer to the tire infla- information specific to the tires installed on your vehicle at the factory.
  • Page 178: Tire Designations

    07 Wheels and tires Tire designations 215: the width of the tire (in millimeters) M+S or M/S = Mud and Snow; AT = All from sidewall edge to sidewall edge. The Terrain; AS = All Season larger the number, the wider the tire. U.S.
  • Page 179 07 Wheels and tires Tire designations Treadwear, Traction, and Temperature grades: see page 182 for more informa- tion. Maximum permissible inflation pressure: the greatest amount of air pres- sure that should ever be put in the tire. This limit is set by the tire manufacturer. Tire suppliers may have additional markings, notes or warnings such as standard load, radial tubeless, etc.
  • Page 180: Glossary Of Tire Terminology

    • Recommended tire inflation pressure: load at 41 psi [43 psi (2.9 bar) for Metric inflation pressure, established by Volvo, tires]. Increasing the inflation pressure which is based on the type of tires that are beyond this pressure will not increase the mounted on a vehicle at the factory.
  • Page 181: Vehicle Loading

    Consult • The resulting figure equals the available Permissible axle weight your Volvo retailer for information. amount of cargo and luggage load The maximum allowable weight that can be capacity. For example, if the "XXX" amount carried by a single axle (front or rear).
  • Page 182: Uniform Tire Quality Grading

    07 Wheels and tires Uniform Tire Quality Grading ALL PASSENGER VEHICLE TIRES MUST WARNING CONFORM TO FEDERAL SAFETY The traction grade assigned to this tire is REQUIREMENTS IN ADDITION TO THESE based on braking (straight-ahead) traction GRADES tests and is not a measure of cornering (turning) traction.
  • Page 183: Snow Chains, Snow Tires, Studded Tires

    Snow chains cornering, braking, and accelerating. Fail- CAUTION ure to do so could reduce traction to an Snow chains can be used on your Volvo with • Check local regulations regarding the unsafe level or adversely affect handling. the following restrictions: use of snow chains before installing.
  • Page 184: Temporary Spare

    In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING Current legislation prohibits the use of the "Temporary Spare"...
  • Page 185: Tire Sealing System

    • Have the tire inspected by a trained and Accessing the tire sealing system Speed limit sticker qualified Volvo service technician as The tire sealing system is stowed under the soon as possible to determine if it can On/Off switch floor of the cargo area.
  • Page 186 07 Wheels and tires Tire Sealing System • Inhalation: Move the person to fresh air. then driven a short distance to distribute WARNING If irritation persists, get medical atten- the sealing compound in the tire. Please keep the following points in mind tion.
  • Page 187 If cracks, bubbles, etc. form on the tire, tle cannot be unscrewed. This must be done ing system. switch off the compressor immediately. by a trained and qualified Volvo service technician. • If there is visible damage to the sidewall WARNING or the rim, the tire cannot be repaired.
  • Page 188 Consult a trained and qualified compressor. If necessary, release air from Volvo service technician to have the 14. Immediately drive the vehicle for approxi- the tire by turning the air release knob bottle removed and properly disposed mately 2 miles (3 km) at a maximum speed counterclockwise.
  • Page 189 6. Start the vehicle’s engine. 9. Turn off the compressor (press the on/off a Volvo retailer or a recycling station switch to position 0) when the correct infla- that can properly dispose of harmful WARNING tion pressure has been reached.
  • Page 190: Changing Wheels

    07 Wheels and tires Changing wheels Jack location If the vehicle is equipped with the optional gro- CAUTION cery bag holder: Fold up the rear section of the Seven-seat models: Do not store objects cargo area floor, disconnect the grocery bag Changing wheels in the area for the rear seat cushions (when holder's retaining cords and fold up the lower...
  • Page 191 07 Wheels and tires Changing wheels 8. Place the wheel with the flat tire in the vehi- Pivot the toggle 90 degrees so that when WARNING cle's cargo compartment. raised, the wheel will rest on the toggle. When raising or lowering the spare wheel, 3.
  • Page 192 07 Wheels and tires Changing wheels 4. Remove the wheel cover (where applica- ble) using the lug wrench in the tool bag. 5. With the wheels still on the ground, use the lug wrench to loosen the wheel bolts ½ – 1 turn.
  • Page 193 07 Wheels and tires Changing wheels check that the jack is still correctly posi- CAUTION WARNING tioned in the attachment. • • The vehicle must not be driven with The jack must correctly engage the bar 7. Raise the vehicle until the wheel to be wheels of different dimensions or with a in the jack attachment.
  • Page 194: Tire Pressure Monitoring System (Tpms)

    07 Wheels and tires Tire Pressure Monitoring System (TPMS) panel and will display one of the following mes- tire causes the tire to overheat and can lead to The tire pressure monitoring system uses sen- LOW TIRE PRESS. tire failure. Under-inflation also reduces fuel sors mounted in the tire valves to check infla- sages in the text window: efficiency and tire tread life, and may affect the...
  • Page 195 In certain cases, it may be necessary to reca- chapter or consult your Volvo retailer. • librate TPMS to conform to Volvo's recom- If wheels without TPMS sensors are moun- mended tire inflation pressures (see the infla- ted on the vehicle,...
  • Page 196 07 Wheels and tires Tire Pressure Monitoring System (TPMS) Activating/deactivating TPMS (Canadian models only) 1. Switch off the engine. 2. Turn the ignition key to position I or II. 3. Press and hold the Reset button on the left-side steering wheel lever until TIRE PRESS SYST OFF is displayed.
  • Page 197 07 Wheels and tires I n f o r m a t i o n P r o v i d e d b y :...
  • Page 198 Washing and cleaning the vehicle............200 Paint touch up..................204 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 199 C A R C A R E I n f o r m a t i o n P r o v i d e d b y :...
  • Page 200: 08 Car Care

    CAUTION Exterior components CAUTION • Avoid waxing or polishing plastic or rub- Volvo recommends the use of special cleaning ber components Chromed wheels: Clean chrome-plated products, available at your Volvo retailer, for • Polishing chromed strips can wear...
  • Page 201 08 Car care Washing and cleaning the vehicle first few months (because the paint will not Polishing and waxing CAUTION have hardened sufficiently). • Normally, polishing is not required during • Avoid waxing or polishing plastic or rub- • the first year after delivery, however, wax- An automatic wash is a simple and quick ber components way to clean your vehicle, but it is worth...
  • Page 202 CAUTION able at your Volvo retailer. protective qualities of its finish. The cleaner Volvo does not recommend the use of long- removes dirt and oil buildup. The light cream • This treatment should be carried out for the...
  • Page 203 08 Car care Washing and cleaning the vehicle Protecting leather upholstery Cleaning the seat belts 1. Put a small amount of protectant cream on Clean only with lukewarm water and a mild a cloth and apply a thin coating of cream soap solution.
  • Page 204: Paint Touch Up

    Pull the tape off so that any NOTE Paint repairs require special equipment and loose flakes of paint adhere to it. skill. Contact a trained and qualified Volvo When touching up the vehicle, it should be • Thoroughly mix the primer and apply it with clean and dry.
  • Page 205 08 Car care I n f o r m a t i o n P r o v i d e d b y :...
  • Page 206 Volvo service..................208 Maintaining your vehicle............... 209 Working on your vehicle................ 211 Engine compartment................213 Engine oil....................214 Fluids..................... 217 Wiper blades..................219 Battery....................220 Replacing bulbs..................223 Fuses..................... 232 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 207 M A I N T E N A N C E A N D S E R V I C I N G I n f o r m a t i o n P r o v i d e d b y :...
  • Page 208: 09 Maintenance And Servicing

    Volvo advises you to follow the suspected. service program outlined in this booklet. To keep your Volvo in top condition, specify time- Applicable warranties tested and proven Genuine Volvo Parts and Accessories.
  • Page 209: Maintaining Your Vehicle

    Visually inspect battery terminals for cor- may be permanent or temporary. OBD II will serviced by a qualified Volvo technician. rosion. Corrosion may indicate a loose ter- store a message about any fault. minal connector, or a battery near the end •...
  • Page 210 09 Maintenance and servicing Maintaining your vehicle way driving is typically needed to allow OBD II to reach readiness. Your Volvo retailer can provide you with more infor- mation on planning a trip. • Maintain your vehicle in accordance with your vehicle's maintenance schedule.
  • Page 211: Working On Your Vehicle

    Always use axle stands or function and serious injury. Any work should similar structures. The vehicle's gross vehicle only be performed by an authorized Volvo workshop. weight is between 5770 lbs (2630 kg) and 6080 lbs (2760 kg). Use a jack and stands rated for this weight.
  • Page 212 If it is necessary to top off the coolant steering and the air conditioning unit. changed. If the system must be drained, con- when the engine is warm, unscrew the sult a trained and qualified Volvo service tech- expansion tank cap slowly so that the NOTE nician.
  • Page 213: Engine Compartment

    09 Maintenance and servicing Engine compartment Brake fluid reservoir WARNING Relay/fuse box The cooling fan (located behind the radiator) may start or continue to operate (for up to Air cleaner 6 minutes) after the engine has been switched off. Radiator Dipstick-engine oil Filler cap-engine oil Washer fluid reservoir...
  • Page 214: Engine Oil

    Depending on your driving habits, premium or synthetic oils may provide superior fuel econ- omy and engine protection. Consult your Volvo retailer or a trained and qualified Volvo service technician for recommendations on premium or synthetic oils. Viscosity chart Oil additives must not be used.
  • Page 215 • Add oil if necessary. If the level is close to Volvo does not recommend the use of oil the MIN mark, add approximately • If the engine is warm, wait for at least additives.
  • Page 216 09 Maintenance and servicing Engine oil WARNING Do not allow oil to spill onto or come into contact with hot exhaust pipe surfaces. CAUTION Not checking the oil level regularly can result in serious engine damage if the oil level becomes too low.
  • Page 217: Fluids

    If the system must be drained, con- Check coolant regularly! 6.8 US qts (6.5 liters). sult a trained and qualified Volvo service tech- nician. • Do not top up with water only. This When there is less than approximately 1 US qt...
  • Page 218 DO NOT DRIVE. Have the car The fluid level should always be between the towed to a trained and qualified Volvo ADD and FULL marks. service technician and have the brake system inspected.
  • Page 219: Wiper Blades

    09 Maintenance and servicing Wiper blades Windshield wiper blades To change a windshield wiper blade: To change a tailgate wiper blade: 1. Fold the wiper arm out from the windshield 1. Pull the wiper arm rearward, away from the and hold the wiper blade. tailgate window.
  • Page 220: Battery

    • • After inspection, be sure the cap over each taken to your Volvo retailer. battery cell or the cover is securely in WARNING place. • Check that the battery cables are correctly PROPOSITION 65 WARNING! connected and properly tightened.
  • Page 221 09 Maintenance and servicing Battery Symbols Replacing the battery No smoking, no open flames, no sparks Wear protection goggles Explosion See owner’s manual for WARNING details REMOVAL OF BATTERY DISCONNECT O CABLE FIRST xxxx xxxxx xx xxxxx xxxx xxxxx xx xxxxx xxxx xxxxx xxxxx xxxx xx Recycle properly...
  • Page 222 Only use replacement batteries equip- ped with a ventilation hose. Consult a and screw it securely in place. 5. Disconnect the positive cable and pull the trained and qualified Volvo service tech- ventilation hose from the battery. nician. NOTE 6. Lift out the old battery and put a new bat- After the battery has been disconnected or tery into place.
  • Page 223: Replacing Bulbs

    Volvo retailer. nents in the engine compartment will be hot. The following bulbs should only be replaced by a trained and qualified Volvo service techni- cian: WARNING • Active Bending Lights Active Bending Lights* - due to the high The entire lamp housing must be lifted out •...
  • Page 224 09 Maintenance and servicing Replacing bulbs Location of the bulbs in the headlight Replacing the low beam bulb (halogen housing headlights) Low beam headlight/Active Bending 1. Remove the plastic cover over the bulb by Lights* turning it counterclockwise. High beam headlight (daytime running light 2.
  • Page 225 09 Maintenance and servicing Replacing bulbs 7. Press the bulb holder into place on the 5. Insert the new bulb (without touching the 2. Turn the bulb holder counterclockwise and headlight housing. glass) in the holder. pull it out of the headlight housing. 8.
  • Page 226 09 Maintenance and servicing Replacing bulbs 1. Turn the lamp holder approximately 1/4 2. Press in the bulb slightly and pull it out of 1. Switch off the ignition. turn counterclockwise and pull it out of the the holder. 2. Turn the bulb holder slightly counterclock- headlight housing.
  • Page 227 Volvo service technician. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 228 09 Maintenance and servicing Replacing bulbs Replacing bulbs in the taillight cluster 1. Switch off all lights and turn ignition key to 8. Disconnect the wiring. 15. Press wiring back into place. position 0. 9. Place the tail light housing on a soft cloth 16.
  • Page 229 09 Maintenance and servicing Replacing bulbs Rear fog light Front footwell lighting Cargo compartment light 1. Switch off the ignition. The front footwell lights are located under the 1. Carefully insert a screwdriver and pry out dashboard on the driver's and passenger's the lens.
  • Page 230 Other bulbs may be difficult for you to 1. Carefully insert a screwdriver and pry out replace yourself. Let a trained and qualified the lens. Volvo service technician replace these bulbs if necessary. 2. Pry out the bulb and replace it. Bulb specifications...
  • Page 231 Front footwell lighting SV8.5 (length 38mm) NOTE Please consult a Volvo retailer’s Parts department for the most up-to-date speci- fications. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 232: Fuses

    Fuse box in the cargo compartment have the electrical system inspected by a trained and qualified Volvo service technician. The easiest way to see if a fuse is blown is to Fuse box in the cargo compartment remove it.
  • Page 233 09 Maintenance and servicing Fuses WARNING Never use metal objects or fuses with higher amperage than those stated on the follow- ing pages. Doing so could seriously damage or overload the vehicle's electrical system. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 234 09 Maintenance and servicing Fuses Fuses in the engine compartment When replacing fuses, be sure to replace a blown fuse with a new one of the same color and amperage (written on the fuse). Starter motor relay Engine control module, fuel injectors, mass airflow sensor Windshield wipers Intake manifold actuator (6-...
  • Page 235 09 Maintenance and servicing Fuses Driver's side low beam head- light Passenger's side low beam headlight – Engine control module feed, engine relay Parking lights Vacuum pump I n f o r m a t i o n P r o v i d e d b y :...
  • Page 236 Entertainment (RSE)* Driver's door – central lock- with a new one of the same color and amper- ing, power windows, door Volvo Navigation System*, age (written on the fuse). mirror Sirius satellite radio* Front passenger's door – cen-...
  • Page 237 09 Maintenance and servicing Fuses Ignition switch, SRS, engine control module, immobilizer, transmission control module Ceiling lighting, upper elec- tronic control module Moonroof* Bluetooth hands-free system 15 – 38 I n f o r m a t i o n P r o v i d e d b y : Option/accessory, for more information, see Introduction.
  • Page 238 When replac- ing a blown fuse, be sure to replace it with a Audio system 12-volt sockets – front and rear new one of the same color and amperage (writ- seats, refrigerator* (XC90 – ten on the fuse). Executive) –...
  • Page 239 09 Maintenance and servicing Fuses Driver's side front foglight* Vacuum pump Passenger's side front fog- Pump – windshield and tail- light* gate washers – – – – Transmission control module1 Driver's side high beam1 Passenger's side high beam – – –...
  • Page 240 09 Maintenance and servicing Fuses Fuses in the cargo compartment The fuses in the cargo area are located behind the panel on the driver's side of the cargo com- partment. When replacing a blown fuse, be – Rear passenger's side door – sure to replace it with a new one of the same power window, power window Rear Electronic module...
  • Page 241 09 Maintenance and servicing Fuses Rear air conditioning system* Passenger's side trailer light- ing: brake light, fog light, turn – signal* – Main fuse: fuses 37 and 38 Accessory audio – – – Rear window wiper – Trailer wiring (15-feed)* –...
  • Page 242 09 Maintenance and servicing Fuses Additional fuses in the cargo compartment (XC90 Executive*) The fuses in the cargo area are located behind Rear seat heating, pas- the panel on the driver's side of the cargo com- senger's side 15 A partment.
  • Page 243 09 Maintenance and servicing I n f o r m a t i o n P r o v i d e d b y :...
  • Page 244 Audio system overview................. 246 Audio system controls................247 Radio functions..................252 Sirius satellite radio................257 Auxiliary equipment................261 CD player/changer................264 Menu structure..................267 ® Bluetooth hands-free connection............268 Rear Seat Entertainment – Dual Screen (RSE)*........273 I n f o r m a t i o n P r o v i d e d b y : Option/accessory, for more information, see Introduction.
  • Page 245 A U D I O I n f o r m a t i o n P r o v i d e d b y :...
  • Page 246: 10 Audio

    10 Audio Audio system overview CD player SOUND – make sound settings VOLUME – turn to adjust EXIT/CLEAR – step back in the menu or cancel a selection POWER – On/Off Not in use AM/FM – for switching between FM1, MENU –...
  • Page 247: Audio System Controls

    10 Audio Audio system controls • Steering wheel keypad Accessing and using menus One long press on EXIT/CLEAR exits menu mode. • A short press on the EXIT/CLEAR enables you to cancel, undo, or answer no to a menu selection, or to go back in the menu structure.
  • Page 248 10 Audio Audio system controls 1. With the audio system switched on, use to prevent the driver from being distracted NOTE by an unexpected change in music. the SEL button to select a sound source. The MY KEY buttons can only be pro- •...
  • Page 249 10 Audio Audio system controls To activate the system: Selecting a sound source 1. Press the SOUND button (2) repeatedly until you come to the setting that you wish • Press AM/FM (4) repeatedly to toggle 1. Turn the ignition key to position I. to change.
  • Page 250 10 Audio Audio system controls • Dolby Surround Pro Logic II is only availa- Equalizer Setting Shown in the dis- ble on the highest level audio system – play Equalizer FR Premium Sound. EQ – FRONT (certain audio systems) Balance between FADER Use the following instructions to select PRO the front and rear...
  • Page 251 10 Audio Audio system controls 5. Press ENTER until you come to the menu mode to save the changes you have made. Optimal sound reproduction The audio system is calibrated for optimal sound reproduction through the use of digital signal processing. This calibration takes into account the speakers, amplifier, cabin acous- tics, the seating position of the listener, etc., for each combination of vehicle and audio system.
  • Page 252: Radio Functions

    10 Audio Radio functions Station search the display. The radio will slowly scroll in Automatically storing stations – the desired direction and then increase AUTOSTORE speed after a few seconds. 2. Release the button when the desired fre- quency is displayed. 3.
  • Page 253: Radio Functions

    10 Audio Radio functions When AUTOSTORING is no longer displayed, 2. Press SCAN (2). SCAN will be shown in the HD Radio reception (U.S. display. the autostore process is complete. The auto- models only) matically stored stations can be selected withe 3.
  • Page 254 93.9 WNYC will noticeable as a "stuttering" effect. ing” (consisting of a frequency's main (Volvo uses the symbol > to indicate there channel and any sub-channels that may The above items are dependant on the are sub-channels available) The sub-FM...
  • Page 255 10 Audio Radio functions Switching HD on or off Sub-channels main channel, press the left arrow key. To go to subchannel 2 (if available), press the right The factory setting for HD radio is on. However, arrow key. when driving through areas with weak HD sig- nals (fringe areas), you may experience that the If you are currently tuned to a frequency's main radio repeatedly switches between analogue/...
  • Page 256 10 Audio Radio functions you are out of digital range of the transmitter, No HD reception will be displayed. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 257: Sirius Satellite Radio

    10 Audio Sirius satellite radio Listening to satellite radio (see also "Selecting a channel" in the right 5. Use the buttons to select column). a channel in the currently chosen category. The Sirius satellite system consists of a number of high elevation satellites in geosynchronous 2.
  • Page 258 10 Audio Sirius satellite radio 1. Press MENU and scroll to Direct channel Storing a channel 2. Scroll to " Add song to song mem. " and entry follow the instructions shown in the dis- A total of 20 satellite channels can be stored; play.
  • Page 259 10 Audio Sirius satellite radio • Radio text Your Sirius ID can be displayed NOTE The text that is displayed about the song cur- Skip options All channels are initially unlocked at deliv- rently playing can be changed. Use the AUTO ery.
  • Page 260 This permanently removes all channels from the locked list and makes them available for The current code will be displayed. selection. Your Volvo retailer can also provide you with Temp. unlock all ch. assistance. This function will temporarily unlock all chan- nels and make them available for selection.
  • Page 261: Auxiliary Equipment

    10 Audio Auxiliary equipment • AUX: sound from an auxiliary device is heard from the audio system's speakers • RSE: sound from the RSE system is heard from the audio system's speakers AUX* The AUX (auxiliary) port can be used to con- nect a device such as an MP3 player.
  • Page 262 USB socket and on the no longer exists. If the problem persists, forward/reverse or change tracks: device. contact a trained and authorized Volvo service technician. • Press briefly to change tracks. •...
  • Page 263 Bluetooth sys- er's headphone volume until the distortion tem. A list of compatible devices is available goes away. at you Volvo retailer or at www.volvo- cars.us. Finally, exit the menu and adjust the audio vol- ume to a comfortable level.
  • Page 264: Cd Player/Changer

    10 Audio CD player/changer mode when it is switched on, the CD will play Ejecting all discs automatically. Otherwise, to play a CD: A long press on the EJECT button (3) starts the EJECT ALL function. 1. Select an empty position using the station setting buttons 1 –...
  • Page 265: Changing Tracks/Random Play

    10 Audio CD player/changer Navigating the disc and playing tracks 2. Press and hold down CD changer If a disc with audio files is in the CD player, This function offers two alternatives for playing search within a track/file. The search con- press ENTER to display a list of folders on the the tracks on the disc(s) in the CD changer in tinues as long as the buttons are...
  • Page 266: Disctext/Compact Disc Care

    2. Select DISCTEXT in the menu and press • Volvo does not recommend the use of ENTER. plastic outer rings on the disc. 3. Any information that may be stored on the • Condensation may occur on discs/optical disc will be displayed.
  • Page 267: Menu Structure

    10 Audio Menu structure FM Menu 1. Radio Text 2. Audio Settings 1. Surround 2. Equalizer Fr 3. Equalizer Rr 4. Reset All AM Menu See Audio Settings i the FM Menu. CD Menu 1. Random 2. Disc Text 3. Audio Settings See Audio Settings in the FM Menu.
  • Page 268: Bluetooth Hands-Free Connection

    NOTE Not all cell phones are fully compatible with the hands-free system. A list of compatible phones is available at your Volvo retailer or at www.volvocars.us WARNING Never use the hands-free feature or any other device in your vehicle in a way that distracts you from the task of driving safely.
  • Page 269 ® 2. Activate the vehicle’s Bluetooth hands- access, navigate and make selections in the 3. Select My Volvo Car free system by briefly pressing the in the list of devices hands-free system’s menus (see page 272). PHONE button. shown in the cell phone’s display.
  • Page 270 10 Audio ® Bluetooth hands-free connection Making a call NOTE NOTE 1. Ensure that PHONE is shown at the top of Certain cell phones may require confirma- • On certain cell phones, the connection the center console display and that the tion from the phone’s keypad when a call is is broken when the mute function is symbol is visible (by pressing briefly on...
  • Page 271 10 Audio ® Bluetooth hands-free connection Ringing volume More information about registering Phone book and connecting cell phones Go to Phone Menu… Phone settings… In order to use the hands-free system’s phone PHONE A maximum of 5 cell phones can be registered book (list of contacts), must be dis- Sounds and volume…...
  • Page 272 10 Audio ® Bluetooth hands-free connection illustration on 268. This starts a search based bers. Other call lists can be found under Call 2.2. Copy fr. cell phone on the first letter on the button that has been register… Bluetooth… pressed.
  • Page 273: Rear Seat Entertainment - Dual Screen (Rse)

    10 Audio Rear Seat Entertainment – Dual Screen (RSE)* Introduction 2. Press NOTE The RSE system can be used at the same time 3. Use the navigation buttons (the arrow keys Using RSE for more than approximately as the vehicle’s audio system. 10 minutes with the engine switched off may surrounding the OK button on the RSE drain the vehicle’s battery and make it diffi-...
  • Page 274 10 Audio Rear Seat Entertainment – Dual Screen (RSE)* Home-burned CDs Connecting a device to RSE-AUX System CDs burned on a home computer can be The formats supported by the system are: played. However, the quality of the sound may Audio CD-DA, DVD Audio Playback, be affected by the type of source file and for-...
  • Page 275 10 Audio Rear Seat Entertainment – Dual Screen (RSE)* Replacing batteries in the remote NOTE control and cordless headphones If the temperature in the passenger com- The remote control and headphones each run partment is high (e.g., if the car has been on 2 AAA batteries.
  • Page 276 Electrical system................... 289 Three-way catalytic converter............... 290 Overview of information and warning symbols ........291 Volvo programs..................293 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 277 S P E C I F I C A T I O N S I n f o r m a t i o n P r o v i d e d b y :...
  • Page 278: 11 Specifications

    11 Specifications Label information I n f o r m a t i o n P r o v i d e d b y :...
  • Page 279 Model plate: includes e.g., Vehicle Identi- Vehicle Emission Control Information: fication Number (VIN), codes for color and Your Volvo is designed to meet all appli- upholstery, etc. The model plate is located cable emission standards, as evidenced by on the rear side of the B-pillar (the pillar...
  • Page 280: Dimensions

    11 Specifications Dimensions Position Dimension in (mm) Wheelbase 112.6 (2857) Length 189.3 (4807) Load length, floor, seatback down 79.4 (2018) Load length, cargo area 44 (1118) Height 70.2 (1784) Load height 34.3 (872) Track, front 64.3 (1634) Track, rear 63.9 (1624) I n f o r m a t i o n P r o v i d e d b y :...
  • Page 281 11 Specifications Dimensions Position Dimension in (mm) Load width, floor 41.8 (1064) Width 76.2 (1936) Width incl. door mirrors (folded out) 83.1 (2112) Width incl. door mirrors (folded in) 76.2 (194) I n f o r m a t i o n P r o v i d e d b y :...
  • Page 282: Weights

    11 Specifications Weights Category Canada Gross vehicle weight 7-seat, 6-cyl, FWD 5915 lbs – 7-seat, 6-cyl, AWD 6080 lbs 2760 kg Capacity weight 7-seat models 1210 lbs 550 kg Permissible axle weight, front 7-seat, 6-cyl, FWD 2770 lbs – 7-seat, 6-cyl, AWD 2880 lbs 1310 kg Permissible axle weight, rear...
  • Page 283 11 Specifications Weights CAUTION The maximum permissible axle loads and/ or the gross vehicle weight must not be exceeded. WARNING When adding accessories, equipment, lug- gage and other cargo to your vehicle, the total capacity weight must not be exceeded. I n f o r m a t i o n P r o v i d e d b y :...
  • Page 284: Fluids

    0.63 US qts. (0.6 liters) Air conditioning system Front – 2.2 lb. (1 kg), Rear* 2.9 lb. (1.3 kg) R 134a (HFC134a) Coolant Volvo original coolant/antifreeze (Thermostat begins to open at 194 ° F (90 ° C)). 7.9 US qts. (7.5 liters) Brake fluid DOT 4+ boiling point >536 °F (280 °C), P/N 9437433...
  • Page 285 11 Specifications Fluids Category Specification Identifier b05ba8cc8f1288e9c0a80be101bcf274 Use washer fluid solvent in cold weather conditions 6.9 US quarts (6.5 lit- Washer fluid reservoir ers) Air conditioning system Refrigerant – R134a The transmission oil does not normally need to be changed during the service life of the vehicle. However, it may be necessary to replace the oil if the vehicle is often driven in areas of sustained temperature extremes (hot or cold), when towing a trailer over long distances, for prolonged driving in mountainous areas, or if the vehicle is often driven short distances in temperatures under 40 °F (5 °C).
  • Page 286: Suspension

    11 Specifications Suspension Rear suspension Individual rear wheel suspension with longitu- dinal support arms, double link arms and track rods. Front suspension Spring strut suspension with integrated shock absorbers and control arms linked to the sup- port frame. Power-assisted rack and pinion steering.
  • Page 287: Engine Oil

    11 Specifications Engine oil Oil specifications Lower quality oils may not offer the same fuel Volvo recommends Castrol. economy, engine performance, or engine pro- Engine oil must meet the minimum ILSAC tection. specification GF-4, API SL, or ACEA A1/B1. Engine designation Volume 3.2 6-cyl.
  • Page 288: Engine Specifications

    11 Specifications Engine specifications Engine designation B6324S5 Output kW/rps 179/107 hp/rpm 240/6400 Torque Nm/rps 320/53 ft. lbs./rpm 236/3200 No. of cylinders 3.3/84 Bore (mm/in.) Stroke (mm/in.) 3.78/96 Cylinder displacement, liters 3.19 (194.8 cu in) Compression ratio 10.8:1 Charge air cooler (Intercooler) Fuel system Turbocharged engines employ a turbo-com- The engine is equipped with a multiport fuel...
  • Page 289: Electrical System

    11 Specifications Electrical system General information 12-volt system with voltage controlled gener- ator. Single wire system in which the chassis and engine block are used as conductors, grounded on the chassis. Battery Battery 3.2 6-cyl. Voltage 12 V Cold start capacity 520 A (CCA) Reserve capacity...
  • Page 290: Three-Way Catalytic Converter

    11 Specifications Three-way catalytic converter Three-way catalytic converter - components or location, or removing com- ponents, and/the repeated use of leaded general information fuel. • Keep your engine properly tuned. Certain engine malfunctions, particularly involving NOTE the electrical, fuel or distributor ignition systems, may cause unusually high three- Unleaded fuel is required for vehicles with way catalytic converter temperatures.
  • Page 291: Overview Of Information And Warning Symbols

    11 Specifications Overview of information and warning symbols Introduction Symbol Description Page Symbol Description Page The symbols in the vehicle's various displays Fault in the ABS Oil pressure warn- are divided into three main categories: system ing light • Warning symbols •...
  • Page 292 11 Specifications Overview of information and warning symbols Symbol Description Page Symbol Description Page Left turn signal Bluetooth-con- nected cell phone Bluetooth hands-free Right turn signal Information symbols in the ceiling console Symbol Description Page Other information symbols Seat belt reminder Symbol Description Page...
  • Page 293: Volvo Programs

    11 Specifications Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional informa- tion, features, and benefits are described in a separate information package in your glove compartment. If you require assistance, dial: In the U.S.
  • Page 294: Index

    12 Index 1, 2, 3 ... Audio Blind Spot Information System (BLIS)..166 system introduction......246 Blower (fan)..........100 12-volt sockets.......... 79 Audio system Bluetooth cell phone connection..... 268 Bluetooth streaming audio....262 Booster cushion HD digital radio........253 accessory..........47 Rear seat entertainment.....
  • Page 295 12 Index Center console buttons......64 Cup holder rear seat..........115 Central locking system - remote key..125 Economical driving........142 Curb weight..........181 Changing a wheel........192 Electrically operated moonroof....86 Current fuel consumption......75 Changing coolant........212 Electrical system........289 Charge air cooler........
  • Page 296 Front seats Generator warning light......60 power..........105 Glove compartment......... 115 ventilated..........97 Grocery bag holder........121 XC90 Executive........107 Gross vehicle weight (GVW)....181 Front suspension........286 Ignition switch.......... 141 Fuel............134 Immobilizer (start inhibitor)...... 124 Fuel filler cap........... 137 Important information........
  • Page 297 12 Index Instrument overview........56 Locking steering wheel......141 Instrument panel........58 Locking the car........128 OBD II............209 Instrument panel lighting......68 Locks, child safety........130 Occupant safety........18 Interior lighting......... 111 Long distance trips........164 ISOFIX/LATCH anchors......48 Low beam headlight........
  • Page 298 REDUCE SPEED........62 Technician certification......293 Snow chains..........183 Refrigerant (A/C system)......94 Temperature control........ 100 Snow tires..........183 Refrigerator (XC90 Executive)....117 Temperature gauge........58 Spare tire..........184 Temporary spare tire....... 184 Registering child restraints......39 Spare tire – accessing......190 Three-way catalytic converter....
  • Page 299 Volvo and the environment......14 Tire Pressure Monitoring System (TPMS) 194 Trip computer..........75 Volvo maintenance........208 Tires............172 Trip odometer..........58 Volvo On Call Roadside Assistance..293 age............172 Turn signals..........70 changing..........190 changing from summer to winter..173 designations........178 improving economy......
  • Page 300 12 Index W – Winter..........145 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 301 I n f o r m a t i o n P r o v i d e d b y :...
  • Page 302 Kdakd 8Vg 8dgedgVi^dc IE &('-+ JH6  8VcVYV! 6I &&'%! Eg^ciZY ^c HlZYZc! <ŽiZWdg\ '%&&! 8deng^\]i © '%%%"'%&& Kdakd 8Vg 8dgedgVi^dc I n f o r m a t i o n P r o v i d e d b y :...

Table of Contents
