  • Page 1: Media Server

    SOFTWARE VERSION 3.5 WWW.PRG.COM ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 2 All other brand names which may be mentioned in this manual are trademarks or registered trademarks of their respective companies. This manual is for informational use only and is subject to change without notice. Please check www.prg.com for the latest version.
  • Page 3 These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 4 Updated to include v3.3 changes. Updated to include v3.4 changes. 02.9800.0001.34 April 22, 2011 Updated instructions for the new Remote II application. Updated to include v3.5 changes. 02.9800.0001.35 November 16, 2011 Re-organized manual and expanded various sections. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 5: Table Of Contents

    Chapter 1. Overview General Overview Features......................................4 Concepts of Operation ................................. 5 Components Mbox Extreme Case Assembly ..............................6 Dual I/O Module ................................... 7 Auxiliary Input Panel ..................................9 Mac Computer.................................... 10 Fixture Descriptions Mbox Extreme Environment Concept ............................12 Fixture and Layer Overview ................................
  • Page 6 Using Standard EDID Sets ..............................52 EDID Capture (Custom Setting)............................53 SDI Output (SD - Standard Definition & HD - High Definition)....................54 Genlock (Generator Lock)................................56 Enhancing Mbox Extreme Performance Disabling Mac Sharing Features..............................58 Chapter 4. Advanced Features 3D Objects and Digital Gobos About 3D Models and Digital Gobos (Objects)...........................
  • Page 7 USB/FireWire Input ................................113 Configuration Setting Video Input for Video Capture Card ..........................114 Configuring Video Input within Mbox Extreme......................... 116 Deinterlacing..................................... 118 Interlaced (i) vs. Progressive (p) Content/Input (Deinterlacing) ..................118 How to Deinterlace Content and/or Input ......................... 118 ®...
  • Page 8 Mbox Daemon ..................................132 General Operation ..................................133 Description of Indicators................................136 Monitor HUD..................................... 136 Setting Mbox Extreme Server Preferences Remotely ......................137 Setup of Alignment Rectangles Using Remote II ......................137 Server Control Commands ............................... 138 Timecode Window ..................................139 Note About Thumbnails ................................

  • Page 9: About This Manual

    High End Systems will support the use of Mbox Extreme v3.x on any console running Hog 2 software. In general, if you are using Mbox Extreme with any console other than Vx76, Virtuoso or grandMA, it is a good idea to contact PRG for more information.

  • Page 10: Customer Service

    Customer Service For technical assistance, contact the PRG International Service Center or contact your nearest PRG office. Contact information for all PRG office locations can be found on our website at: www.prg.com/about-us/locations/ PRG Dallas (International Service) 8617 Ambassador Row, Suite 120 Dallas, Texas 75247 USA Phone: 214.630.1963...

  • Page 11: Chapter 1. Overview

    OVERVIEW This chapter provides an overview of Mbox Extreme features, components, and operations. GENERAL OVERVIEW COMPONENTS FIXTURE DESCRIPTIONS OPERATING MODES...

  • Page 12: General Overview

    3D objects are stored directly on the Mbox Extreme hard drive, allowing instant access to any file. The Mbox Extreme is a single server rack unit equipped with two video outputs that can be used to drive a variety of video display devices.

  • Page 13: Concepts Of Operation

    Basic Function The basic function of the Mbox Extreme Media Server is to control dynamic media - such as movie clips, still images and 3D objects - during a stage show or other performance. The resulting visual imagery is output to a display device such as a projector, LED wall, plasma screen or low-res LED lighting fixture.

  • Page 14: Components

    COMPONENTS Mbox Extreme Case Assembly The following illustrations show the main case components for the Mbox Extreme v3 hardware: Auxiliary Input Panel ** Dual I/O Module * UPS Power Unit UPS Power Unit FRONT VIEW REAR VIEW ETHERNET LEFT RIGHT...

  • Page 15: Dual I/O Module

    Genlock connectors are active. (Note that the Genlock Out is not a pass-thru. This output should only be used if the Mbox Extreme server is the master for syncing (rather than using it as a daisy-chain port).
  • Page 16 Art-Net universe 1. (DMX512 cables can only carry one universe of data at a time, and in some cases Mbox requires two universes.) The DMX512 starting address can be set on the Mbox Extreme Setup window, but should typically be set to 0.

  • Page 17: Auxiliary Input Panel

    The Auxiliary Input panel provides input/output connectors for signals other than video and DMX/Art-Net. Ethernet - This port is used when networking multiple Mbox Extreme servers together. Audio Out - The XLR audio outputs are balanced. The mini plug audio output is unbalanced.

  • Page 18: Mac Computer

    Mac Computer The Mbox Extreme Media Server contains a Mac Pro computer which has been customized by PRG. The Mac computer is used to operate the Mbox Extreme system and store the media. It also provides standard computer connectors such as USB and FireWire® for the purpose of importing or exporting media data.
  • Page 19 Genlock Card Audio In/Out Graphics Card Figure 1-7: Mbox Extreme v3.5 Components Note: Version 3.5 racks can be easily identified by the "v3.5" label on the top of the Mbox Extreme rack case. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 20: Fixture Descriptions

    Mbox Extreme Environment Concept In order to get the most out the Mbox Extreme Media Server, it is important to understand the overall concept of the Mbox Extreme environment, which is essentially a building platform for "virtual scenery." The final "look" of this virtual...

  • Page 21: Fixture And Layer Overview

    "fixture." All parameters are controlled by mapping DMX512 channels to the console. An appendix at the end of this manual contains tables for all DMX512 channels used with the Mbox Extreme server. The fixtures and their controllable parameters are outlined below. To help illustrate these concepts, an image of the corresponding "Heads Up Display"...
  • Page 22 Crossfade Type and Timing Drawmode 3D Effect 1 with Controls A & B 3D Effect 2 with Controls A & B  For a complete DMX512 channel maps, refer to "DMX512 Mapping" on page 145. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 23: Fixture, Layer And Parameter Details

    Shutter Control Mbox Extreme has shutters, much like a Leko, which can be used to mask off areas of the final image. The shutters can be thought of as sitting in between the camera and the layers. They do not affect any one layer or group of layers, only the final image.

  • Page 24: Layers: Texture + Object

    A transition style (e.g. dissolves, wipes, bleeds) and a time for the Texture transition can be set on each layer. If a layer’s transition time control is set above 0, Mbox Extreme will use the layer’s current transition mode to change from one image to the next in the time designated.

  • Page 25: Operating Modes

    Dual. The primary purpose of the operating mode is to configure the screen arrangement and required DMX512 profile for the server. The Mbox Extreme Setup tab, covered later in this manual, is used to change the operating mode. (Refer to "Setup"...

  • Page 26: Panoramic Wide Mode

    Any of the server's 12 possible content layers can be displayed on either screen or with a portion on each screen (with or without an overlap). Figure 1-12: Example of Panoramic Dual Mode ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 27: Chapter 2. Installation And Power-Up

    INSTALLATION AND POWER-UP This chapter provides instructions for setting up the Mbox Extreme server and powering up for the first time. SAMPLE CONFIGURATION DIAGRAMS SETUP GETTING STARTED PATCHING FIXTURES...

  • Page 28: Sample Configuration Diagrams

    In the following configuration, DMX512 control signal is distributed from one DMX512 console to multiple DMX512 devices and one Mbox Extreme Media Server. Data is then distributed from the Mbox Extreme Media Server to the other components as shown below.

  • Page 29: Art-Net Input Configuration: Network Switch And Multiple Media Servers

    Art-Net Input Configuration: Network Switch and Multiple Media Servers In the following configuration, Art-Net control signal is distributed from one control console to one network switch. The network switch then distributes the control signal to all Mbox Extreme Media Servers. Art-Net...

  • Page 30: Output Configuration: Single Media Server With Plasma Display And Lcd Projector

    Output Configuration: Single Media Server with Plasma Display and LCD Projector In the following configuration, a Plasma Display and LCD Projector are connected to a single Mbox Extreme Media Server. VGA IN PLASMA DISPLAY LCD PROJECTOR DVI 1 OUT MBOX EXTREME Figure 2-3: Single Media Server with Plasma Display and LCD Projector ®...

  • Page 31: Setup

    Step 5. Connect local monitor power cable to UPS or to local AC power service. Step 6. Connect UPS power cable to local AC power service. Step 7. Connect stage outputs and other Mbox Extreme servers (if required) according to the following sections. ®...

  • Page 32: Connecting The Stage Output

    Networking Multiple Mbox Servers The Mbox Extreme’s Mac computer has two standard Ethernet ports on its rear panel. The first Ethernet port is pre- connected to the two Ethernet ports on the front of the Dual I/O module, and is dedicated to Art-Net reception.

  • Page 33: Getting Started

    Mbox Extreme will begin in Window mode and proceed with a scan of the media library. (If a large number of 3D models have been selected to preload, there may be a brief delay in which the computer will not respond to any user input.) After the media scan is complete, depending on the preference settings, the application will either stay in...

  • Page 34: Power-Up Procedure

    When the Mbox Extreme application is launched, the Mbox Daemon application will also be launched. This software application is required on all Mbox Extreme servers to enable remote feedback. The Mbox Daemon won’t be visible, however, since it is a background process and has no user interface unless it is "forced" to be shown. (To force Daemon’s interface to be shown, press [...

  • Page 35: Patching Fixtures

    DMX Requirements In order to control the Mbox Extreme Media Server, it will need to be "patched" to a control console. Patching allows DMX512 channels to be mapped to the controllable elements of the Mbox Extreme environment. Use the following guidelines when patching: One Mbox Extreme Media Server running v3.x software requires at least 466 DMX512 channels.

  • Page 36: Dmx Mapping

    466 Total Keystone Control DMX Channels Layer 1 Layer 2 Layer 3 Layer 4 Layer 5 Layer 6 Layer 7 Layer 8 Layer 9 372 Total Layer 10 DMX Channels Layer 11 Layer 12 ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 37 Layer 7 Layer 6 Layer 8 Layer 9 Layer 7 372 Total Layer 10 Layer 8 DMX Channels Layer 11 Layer 9 372 Total Layer 12 Layer 10 DMX Channels Layer 11 Layer 12 ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 38 Keystone Control Keystone Control Layer 1 Layer 1 Layer 2 Layer 2 Layer 3 Layer 3 Layer 4 Layer 4 Layer 5 Layer 5 Layer 6 Layer 6 Total DMX Channels Total DMX Channels ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 39: Playing Back Video - Quick Start

    Playing Back Video - Quick Start Once a console has been connected, the Mbox Extreme fixtures patched, and the display device turned on, video can be played back. To immediately play back video: Step 1. At console, select Camera fixture and set its intensity to full. Very Important! – the Camera fixture’s intensity controls the built-in hardware dimmer on the I/O module.
  • Page 40 Step 5. To apply an effect to the layer, for example, set the Effect 1 parameter to 2 (sepia tone) and set the Effect 1 Control A to 255 (full). This should result in a sepia version of the same clip: ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 41: Chapter 3. Operation

    OPERATION This chapter provides instructions for configuration and operation of the Mbox Extreme server. MEDIA CONTENT APPLICATION WINDOW HEADS UP DISPLAYS (HUDS) DUAL I/O MODULE ENHANCING MBOX EXTREME PERFORMANCE...

  • Page 42: Media Content

    3D Model Files (Objects) Custom 3D models can be added to the Mbox Extreme Media Server. The server supports the Alias Wavefront™ 3D .obj format. There are several third-party applications that can export files to this format, including Maya®, Poser®, Bryce®, and Cheetah3D to name a few.

  • Page 43: Media Content Management

    If the file extension of a DV movie file is changed from .mov to .vid, it will cause Mbox Extreme to deinterlace that movie as it plays. The results of deinterlacing on the fly are not as good as when using deinterlaced content, however, this means that interlaced content can be played without it looking as noticeable.

  • Page 44: Folder And File Numbering

    Folder 000 in both the folders is reserved and should not be used. The stock PRG movies and still images are located in Media folders 001 - 038 and 248 - 254. Media folder 255 is reserved for video inputs and layer copy functionality.

  • Page 45: Additional Media Content Organization Guidelines

    Mbox Extreme application is running, the Media and Models folders must be re-scanned in order to use that new content. These folders can be re-scanned while Mbox Extreme is running by pressing [ R] on the server's keyboard or from the console by using the control channel on the Camera fixture. There will be a brief pause in movie playback while the rescan takes place.

  • Page 46: Adding Media Content

    Step 4. For each file, add a unique 3-digit index value to each file (between 0-255) along with a descriptive name that includes the file extension. For example, "001.man.obj", "002.hammer.obj", "003.airplane.obj", etc. (Note the caution given above.) ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 47: Creating And Viewing Content Thumbnails

    Creating and Viewing Content Thumbnails Each Mbox Extreme server can create thumbnail images of the content. To create thumbnails on a server, press [ T]. Thumbnail images are stored in a standard location on every server and are grouped with HTML files that allow any networked computer (Mac or PC) to use an HTML browser to view the thumbnails on the server.

  • Page 48: Application Window

    APPLICATION WINDOW Overview The Mbox Extreme application window allows the server’s output to be viewed in either Window or Fullscreen mode on the preview monitor. Fullscreen - While in Fullscreen mode, the server’s output (i.e., video) will be displayed at "full screen" without any user interface showing.

  • Page 49: Setup

    Input License Key to authorize the application. Set a width and height for Textures. Set the network port for CITP communications between Mbox Extreme and Mbox Remote and/or any lighting console or visualizer that supports CITP and MSEX. (Refer to "Mbox Daemon"...

  • Page 50: Setup: Dmx Profile

    The resulting window size will be shown under the menu (960 x 540 in the example to the right). At Startup - when this box is checked, the Mbox Extreme application will start in Windows mode. If it is not checked, the application will start in Fullscreen mode.

  • Page 51: Setup: Fullscreen Mode

    The extra screen area outside the requested fullscreen dimension will be rendered in black and will not allow content to be placed there. As in the prior case, Mbox Extreme has no control over the actual resolution that the operating system provides. (See "Active Area Controls" section below for further information.)

  • Page 52: Setup: Update Rate

    By default, Mbox Extreme will automatically adjust its update rate. However, if there is poor playback smoothness, it may be necessary to force Mbox Extreme to output a lower number of frames per second to the Graphics card. There are multiple entries in the Update Rate pop-up menu. The selection should be limited to: "default" - which will result in Mbox Extreme automatically adjusting the update rate;...

  • Page 53: Setup: Texture Size

    , the Texture Size should never be set lower than this value if you intend to use any stock content. CAUTION! If changes are made to the Texture Size, the Mbox Extreme application must be restarted for these changes to take effect. Setup:...

  • Page 54: Setup: I/O Module

    I/O module output section has been found. If "---" is displayed on one or both buttons, this indicates that Mbox Extreme cannot find the I/O module circuit board in question.* These buttons also identify which output section is which. When the Output 1 button is pressed, the top I/O module output section should flash its LEDs rapidly.

  • Page 55: Setup: Log (Media Errors)

    For example, two media files with the same number would be reported as an error in the log. The log also lists all media content found by Mbox Extreme during the scan. If a file does not appear in this list, then the server will not attempt to play it.

  • Page 56: Heads Up Displays (Huds)

    HEADS UP DISPLAYS (HUDS) Overview Mbox Extreme provides Heads Up Displays (HUDs) that contain detailed information about the server. There are two methods for calling up most of these HUDs: the Camera fixture control channel or the keyboard. Refer to the chart on page 152 for a listing of discrete values for the Camera Control Channel.

  • Page 57: Using The Huds

    LAYER 1 column: All other HUDs will show the same type of changes to the parameter values. Paging through F1, F2, F3 and F4 HUDs can be helpful during programming to verify value changes. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 58: Dual I/O Module

    During operation, the I/O module can suppress the stage output so that "inappropriate" content - such as the Mac desktop or Mbox Extreme application frame - will not be displayed on the stage output (e.g., when in Window mode). I/O module settings can be configured using the Mbox Extreme Setup tab as covered in "Setup: I/O Module"...

  • Page 59: Connected Display Devices And Edid

    Figure 3-2 below. The header of each window will display the name of the EDID set (e.g. PRG-MbE 60Hz as shown below) or the name of the captured EDID (e.g. LCD 2408WFP).

  • Page 60: Using Standard Edid Sets

    Both switches will be set to their Yes position only when capturing a custom EDID set. (Refer to the next section.) Desired EDID Set Stage Blackout Switch Preview Dim Switch  YES  YES Capture from DVI/VGA ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 61: Edid Capture (Custom Setting)

    Figure 3-3: Dual aI/O Module To capture EDID for each output: Step 1. Quit Mbox Extreme application. Step 2. Open Mac Displays Preference window (Figure 3-2). Step 3. Connect monitor to preview output of the other output section (not being programmed).

  • Page 62: Sdi Output (Sd - Standard Definition & Hd - High Definition)

    SDI can be sent from both outputs of the I/O module simultaneously. A standard DVI monitor may need to be connected to the Preview output(s) of the I/O module so that the Mac desktop can be viewed when Mbox Extreme is not running in Fullscreen mode.
  • Page 63 Most SD-SDI monitors cannot display an HD-SDI signal, but HD-SDI monitors can display SD-SDI signals. When entering the Fullscreen mode with Mbox Extreme set to output an SDI-compatible resolution, the SDI indicator LED to the left of SDI connector A will illuminate. SDI will be output if one of the pre-determined SDI settings is selected or if the Custom mode is configured with a resolution and frequency that matches one of the possible SDI formats.

  • Page 64: Genlock (Generator Lock)

    The function of Genlock is to tell the server when to start drawing each frame of video. This function can be synced so that all Mbox Extreme servers in the system will start drawing at the same time. The Mbox Extreme Dual I/O Module provides the the ability to synchronize - or "genlock"...
  • Page 65 To ensure that genlock input and output work successfully, make sure that the devices being synchronized are set to refresh at identical rates. If Mbox Extreme is set to output video with a refresh rate of 59.94Hz, then its output can only be usefully connected to another device that is set to refresh at 59.94Hz.

  • Page 66: Enhancing Mbox Extreme Performance

    Disabling Mac Sharing Features Using the Mac’s File Sharing or Remote Management features will affect the performance of the Mbox Extreme server. It is recommended that these features NOT be used during show situations. They can be disabled by unchecking their boxes in the Mac Sharing Preferences window (see example below) or from a connected console using the Camera Control Channel.

  • Page 67: Chapter 4. Advanced Features

    ADVANCED FEATURES This chapter provides instructions for using the advanced features of the Mbox Extreme server. 3D OBJECTS AND DIGITAL GOBOS ANIMATED TEXTURES LAYER COPY DRAWMODES SPECIAL EFFECTS TEXT FILES AUDIO SYNCHRONIZATION ALIGNMENT RECTANGLES EFFECTS AND TRANSITIONS MULTISCREEN GOBOS...

  • Page 68: 3D Objects And Digital Gobos

    All 3D models and digital gobos require some amount of lighting to be properly visible. If the object file is used without turning on one of the Mbox Extreme lighting fixtures or without using Drawmode 1 (Light), then the object will appear on the screen as a black silhouette.

  • Page 69: Preloading 3D Objects

    - 002.LargeObjects.preload Preloading a large number of objects will cause Mbox Extreme to take longer to start up and should only be done if the models in question do not appear on screen as quickly as desired. When models are preloaded, it is the vertex array file that is preloaded rather than the original .obj or .vle file.

  • Page 70: Dha And Vari*Lite Digital Gobos

    - 001.NewObject.obj should be renamed as - 001.NewObject.pixels.obj In this case, an object that is 200 generic units tall will appear as 200 pixels tall within Mbox Extreme. And a piece of 2D content that is 200px high would fit exactly when applied to that object.

  • Page 71: Creating Custom Digital Gobos

    SVG files are the most compatible and they provide better functionality than AI files. Mbox Extreme's vertex array compiler pays attention to "object fill" information in these file types. Path and Stroke information is ignored, unless special steps are taken with the file. (Refer to the Adobe Illustrator documentation for more information on path, fill, and stroke.)
  • Page 72 (line, arc, spiral), text tool, and the pencil. All of these tools, except the line tool, will create a filled object. Filled objects will be compiled as solid areas in Mbox Extreme and will be the areas that accept a texture, if one is applied. Text...
  • Page 73 You don't need to change any of the options in the window, just press OK. Add more objects as desired. (You can use multiple layers, if required.) Step 5. Use the text tool to create text as desired. Use the Character options to set font and size. Character Options ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 74 Option 1 or Option 2. The texture applied to the gobo will fill the crop area when the gobo is used in Mbox Extreme. Note: It is not recommended that the crop area be sized or positioned so that any portion of an object fall outside the crop area.
  • Page 75 Step 8. Before you saving the file, consider where the center of the file should be. By default, the center of a digital gobo will appear in the center of the Mbox Extreme window and the gobo will rotate around that center point.

  • Page 76: Animated Digital Gobos

    Animated Digital Gobos Mbox Extreme animated gobos are similar to SVG gobos, but they have built-in functions which have their own controls. Animated gobos, saved as .dgob files, are located in the /Mbox/Models/002.Animated_Gobos folder. Unlike normal digital gobos, these files do not need to be compiled so there will be no corresponding .vtxa files. Like other digital gobos, the animated gobos are treated as objects and some of them require lighting.

  • Page 77: Tv Screen V1.4 (002/001)

    "snowflakes" must be created within the Mbox folder and numbered .vtxa files (1 to 254) must be placed into it. model_cache .vxta files can be copied from the folder into the snowflakes folder. ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 78 The B modifier selects the number of flakes on the screen at one time. Texture Scale (on the same layer) will affect the size of the flakes and Z-rotation will affect the direction in which the flakes fall. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 79: Tunnel V1.1 (002/003)

    The A modifier sets the amplitude of the ripples. The B modifier sets the number of ripples. In the following example, the X rotation has been adjusted so that the shape can be seen more clearly. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 80: Ring Stripe (002/005)

    For the Fisheye animated gobo, Animation Speed controls the seam blending and mirroring (0-126 = mirrored, 127 – 255 = normal). The A modifier sets the push from center. The B modifier sets the push from edge. fisheye fisheye mirrored ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 81: Cylinderscreen (002/008)

    The A modifier (default = 127) controls the radius of the curve of the screen and the direction of the curve. The B modifier (default = 127) controls the rotation of the screen around its own Y-axis (rather than around the global Y axis of Mbox Extreme's 3D environment). MultiScreen Gobo (002/009) The MultiScreen animated gobo allows the placement of content onto a predefined structure that can receive external data (Art-Net) to control both the position and arrangement of the content on the structure, and also the structure’s...

  • Page 82: Animated Textures

    Once Rev Loop XF Scrub Scrub FWD Loop IPR Mirrored T-B Timecode sync Bounce Layer Slave Once Layer Master Scrub  For a complete channel map, refer to "Play Mode" on page 156. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 83: Layer Copy

    When using the Raw copy mode, if a source layer makes a timed transition, then any destination layers using that source will not receive the transition. Their content will change immediately. A layer cannot copy another layer that is already copying a third layer. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 84: Using Drawmodes

    However, you’re only using one layer not two. You can set the Drawmode back to 0 and try out the other lighting fixtures to see how they affect the gobo. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 85: Drawmode 16 - Orthographic View

    Drawmode 16 causes 3D objects to be drawn using orthographic projection. Typically, when 3D objects are drawn in Mbox Extreme, they all share one vanishing point, which is a fixed point at the center of the screen (assuming the camera is in its default position). Because of this, any object that has depth will show some amount of perspective shift as it is moved around the screen or as the camera moves.

  • Page 86: The Stencil

    The following example first shows the two together and then shows the holes being cut into the Stencil by the gobo: Finally, the following example shows the Stencil on its own showing the holes cut into it: ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 87 Drawmodes by placing the green clip on Layer 1 and placing the textured gobo on Layer 2 with Layer 1’s Drawmode set to 1. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 88: Layer Blending Modes

    For example, Drawmode "Draw thru stencil" has a value of 6. Blend Mode Exclusion has a value of 128. To use these two items together, set the drawmode channel to a value of 6 + 128 = 134. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 89: Special Effects

    You cannot tell that the gobo is rotating from the example image here, but it is. But no decay is visible since there is "nothingness" behind it. However, if you reduce the opacity of Layer 1 behind the gobo, you can begin to see the decay. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 90: Fog

    In the image below, the Fog effect has been turned on. Now the differences in the Z-position (distance from the camera) can be seen. The object furthest from the camera is darkest. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 91: Text Files

    TEXT FILES Support for Text Files Mbox Extreme can display text using RTF (Rich Text Format) or TXT (Text) files. Both files will work, but the RTF format will result in higher quality. .rtf An RTF file can be created by using the TextEdit application on the Mac computer. Simply type some text into a document and then save as an RTF file.

  • Page 92: Audio

    AUDIO Audio Output Features Overview In addition to movies, still images, and 3D objects, Mbox Extreme can also play audio files. Audio can be played back by any of the following methods: The Mac computer’s internal speaker. The Mac computer’s SPDIF audio jack.

  • Page 93: External Audio Tracks (Associated Aiff Files)

    0. The audio file will play, but the triggering content will not be displayed. Embedded Audio Tracks (in QuickTime Movies) Mbox Extreme can also play audio that is embedded in a movie clip. To get Mbox Extreme to play the embedded audio in these files, it will be necessary to rename the file: a file named - 001.MyMovie.mov would be renamed as - 001.MyMovie.audio.mov...

  • Page 94: Synchronization

    Timecode Synchronization (Timecode Sync Playmode) Mbox Extreme allows movie playback to be synchronized to external SMPTE or MIDI timecode, or a simple internal clock. The timecode sync works with both 30 fps non-drop and 30 fps drop-frame timecode and requires the use of the Mbox Remote application (refer to "Mbox Remote II Operation"...
  • Page 95 Step 4. At Value field, enter a number which is the timecode value. Step 5. Press [return]. Step 6. Continue adding entries by pressing Add Item button. MediaTimeCodes.plist Step 7. At File menu, select Save As. Enter as the file name and click Save. ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 96 SMPTE In ETHERNET LEFT RIGHT SMPTE IN MIDI IN MIDI OUT SDI IN Y IN R - Y IN B - Y IN (COMPOSITE) BALANCED AUDIO OUT Figure 4-2: Auxiliary Input Panel (v3.4) ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 97 Line In connector on the Mac, therefore, "Line In" must be selected as the audio input source in the Sound preference window in the Mac's system preferences. The input volume can also be adjusted here. ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 98 When using a timecode input, multiple layers on one Mbox Extreme server or layers on multiple servers can respond to the same timecode, but need not have any other layer properties set the same (except the Timecode Sync playmode, of course).

  • Page 99: Layer-To-Layer Synchronization

    Layer-To-Layer Synchronization Mbox Extreme offers the ability to synchronize playback of a designated master layer on one server to a layer on another server. A layer on one server can sync to the same numbered layer on another server, or one of 16 sync streams can be selected for both sync mastering and slaving.

  • Page 100: Kiosk Playmodes

    - Playout Mode, last 30 seconds - playback position will skip ahead to thirty seconds from the end of the movie.  For a complete channel map, refer to "Play Mode" on page 156. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 101: Alignment Rectangles

    The remote preference setting functionality in the Mbox Remote II application gives access to this advanced configuration. Like many other settings for Mbox Extreme, the Alignment Rectangle settings are stored in a plist file. This file's /Mbox/alignment/alignment.plist default location is It is possible to automatically crop and center content to any Alignment Rectangle.
  • Page 102 - Group 7 rectangles with X & O - Group 8 rectangles without X & O - Group 8 rectangles with X & O - Group 9 rectangles without X & O - Group 9 rectangles with X & O ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 103: Effects And Transitions

    255 files, numbered 001 – 255. In the case of the Custom Wipe transition, you may have up to 20 files – ten are hard- edge wipes 001 – 010, and ten are soft-edge wipes 011 – 020. Numbering, naming, and file extensions conventions follow the same rules as standard Mbox Extreme content. [e.g. 001.MyFile.png] Guidelines: The input image files must be sized appropriately for their intended purpose.

  • Page 104: Adding Custom Effects Or Transitions

    . In order to enable Mbox Extreme to use these Image Units properly, a file must be created to define the parameters of the effect. These files are saved in the standard Apple Property List Editor format, but with special file extensions – not ".plist".
  • Page 105 This is what the plist information for this transition looks like: ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 106 UserVisibleName properties. If you fail to use the correct type or an appropriate value for a property, then it is likely that the entire effect or transition will fail when used with Mbox Extreme. It is best to start by modifying values to a small extent and examine the result of those changes.

  • Page 107: Multiscreen Gobos

    The configuration options for the gobo allow for opacity changes, texture position changes, rotations, and actual position changes. To use this complex feature, please contact your PRG representative. ®...
  • Page 108 Notes ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 109: Chapter 5. Pixel Mapping

    PIXEL MAPPING This chapter provides instructions for setup and operation of the pixel-mapping feature of the Mbox Extreme server. BASIC PIXEL-MAPPING ADVANCED PIXEL-MAPPING...

  • Page 110: Basic Pixel-Mapping

    Net directly. When pixel-mapping, Mbox Extreme retains both the stage and preview outputs so a video signal can still be sent to a display device. Mbox Extreme also provides the ability to previsualize the pixel-mapping setup on the video monitor.

  • Page 111: Setup

    Setup While in Window mode, select the Pixel Map tab at the top of the Mbox Extreme window. If there is no current pixel- mapping file, you will see an empty configuration like the one below. If a pixel-mapping configuration already exists, then click the New button and choose a name and save location for the new file.
  • Page 112 When you place a fixture on the context grid, an entry for that fixture is added to the table on the right of the grid. Mbox Extreme will automatically patch fixtures in order (as you place them) beginning with Art-Net universe 1.
  • Page 113 Pressing [F5] affects both the preview output and the stage outputs, so if you are using one Mbox Extreme for both pixel-mapping and video output, you should not leave the view set to context view or patched fixture view when outputting video for your show.
  • Page 114 0, to allow all Art-Net levels to pass - settings of 254 or 255 will suppress some or all of the Art-Net output. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 115: Advanced Pixel-Mapping

    The default slew rate is 0 seconds - Mbox Extreme will allow the fixture to change color as fast as it can. The other settings allow you to reduce the speed of the changes progressively, up to a maximum of 8 seconds.

  • Page 116: Sampling Areas

    If you create numerous custom fixture profiles, save your patch file to an external drive and take them with you for the next show. PRG has the capability to create special fixture types that cannot be created by the on-board fixture creation tool.
  • Page 117 However you will probably not be using a video output if you are using Sample Areas. Outlines of sample areas Layers placed inside areas Previsualization ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 118 Notes ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 119: Overview

    VIDEO INPUT This appendix provides setup instructions for the four video inputs available on the Mbox Extreme server. OVERVIEW CONFIGURATION...

  • Page 120: Video Input

    Video Input Mbox Extreme allows for up to four video inputs per server. Each input must be set up in advance for it to work properly with the video signal that is being used. The two types of supported video inputs are: QuickTime streaming (Video Capture card) and USB/FireWire (camera).

  • Page 121: Usb/Firewire Input

    QuickTime-based applications on the Mac should work. However, because there are such a wide variety of cameras, it is impossible to verify that all of them work with Mbox Extreme. Always test your particular camera with the Mbox Extreme in advance.

  • Page 122: Configuration

    This configuration is done outside the Mbox Extreme application. To configure Video Capture card: Step 1. Quit Mbox Extreme application, if running. Step 2. At Apple menu, select System Preferences. Step 3. At System Preferences window, click on Decklink button.
  • Page 123 The three possible selections are: SDI Video, Y, R-Y, B-Y Video, and NTSC/PAL (Y in). These correspond to SDI, Component, and Composite video input types. Because Mbox Extreme does not use the audio input on the Decklink Video Capture card, the audio type in each of the inputs can be ignored.

  • Page 124: Configuring Video Input Within Mbox Extreme

    To configure video input: Step 1. Start Mbox Extreme application. Step 2. Make sure that no layer on Mbox Extreme is being told to display a video input. (Send all fixtures to their default state on the console to be sure.) Step 3.
  • Page 125 Texture Size is entered at the Setup tab of the Mbox Extreme Setup window. Step 11. As a final step, you must quit and restart the Mbox Extreme application. ® MBOX EXTREME...

  • Page 126: Deinterlacing

    Interlaced (i) vs. Progressive (p) Content/Input (Deinterlacing) Because Mbox Extreme outputs a progressive video signal from the Mac computer, it is recommended that progressive movie content be used. This recommendation also applies to the video input signal. When using a video input, be especially aware of the difference between interlaced video signals and progressive video signals.

  • Page 127: Chapter 7. Content Creation And Utilities

    CONTENT CREATION AND UTILITIES This chapter contains information on the proper formatting of content for playback on the Mbox Extreme server, along with content management and conversion utilities. CREATING CUSTOM CONTENT MEDIA UTILITY APPLICATIONS...

  • Page 128: Creating Custom Content

    - however, movies using non-preferred codecs may not play as well as movies that use the preferred codecs. While Mbox Extreme will do the best job possible to play any movie content, if the file is not optimized specifically for Mbox Extreme, poor results may occur.

  • Page 129: Compression (Bit Rate)

    60 then the movie will play more smoothly; so 20fps content will look better than 24fps content. So if Mbox Extreme's output frequency is 50Hz, then it would be best to create content that is rendered at 25fps.

  • Page 130: Discrete Audio Support For Multichannel Audio

    Alpha Channel in Movies – the Animation and ProRes 4444 Codecs It is often very useful to be able to add areas of transparency to a layer when using Mbox Extreme. This will make it possible to see other layers behind, to create a "knockout" for IMAG, or to properly display a movie that uses green- screen technology.

  • Page 131: Applications For Content Creation

    Extreme File Converter application. This application will convert the movie into a format that Mbox Extreme is better able to play while still retaining the alpha channel information. When the movie is played in Mbox Extreme, the bit-rate is significantly lower – allowing for better playback – and the transparent areas are still transparent. Refer to "Mbox...

  • Page 132: Media Utility Applications

    Before going any further, please note that you should never lock your original copy of any content. Once content is locked, it can only be played on Mbox Extreme and not on any other computer! Only lock content that you place onto an Mbox Extreme! All of the stock movie, object and digital gobo content on Mbox Extreme is also locked and cannot be used on any other computer or media server.
  • Page 133 Step 8. After clicking Open button, the dialog window will close and Media Lock will lock the items. If you are locking a great number of files, this process may take a minute. Mbox Extreme will display an indication of how many files were processed and if there were errors in the "Files"...

  • Page 134: Mbox Extreme File Converter

    About File Conversion The Mbox Extreme File Convertor will accept file drops of more than one file at a time. It processes four files simultaneously and will queue additional files. The application creates new copies of the original file in the same location as the original file.

  • Page 135: Pre-Multiplying Alpha

    The Mbox Extreme File Converter has one additional function: it can apply pre-multiplied alpha to a TIFF or PNG file that was created using straight alpha. As noted above, this can help to reduce fringing around the edges of these files if they were created improperly.

  • Page 136: Mbox Extreme Plist Editor

    The Mbox Extreme application only writes information to the MboxExtreme plist file when the application quits. Therefore, while Mbox Extreme is running, any changes made to the plist file will be over-written when Mbox Extreme quits. In order to properly use the MbE plist Editor, Mbox Extreme should not be running.

  • Page 137: Using Mbe Plist Editor

    File Types - Mbox Extreme can only index (and display) content that has a recognized file extension. When the Mbox Extreme application launches, it creates a text file that is an index of the recognized files that it finds /Mbox/Media_Report.txt ).
  • Page 138 Notes ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 139: Appendix A. Mbox Remote Ii Application

    MBOX REMOTE II APPLICATION This appendix provides operation instructions for the Mbox Remote II application. MBOX REMOTE II OPERATION...

  • Page 140: Mbox Remote Ii Operation

    [ D] while Mbox Extreme is in Window mode. To set the network port that Mbox Extreme and Daemon will use to communicate with external monitoring devices (like Remote II or CITP-enabled consoles and visualizers), use the CITP pop-up on the Mbox Setup tab as shown...

  • Page 141: General Operation

    General Operation Before opening the Remote II application, ensure that your computer is on a network with one or more Mbox Extreme servers. It is important that all Mbox Extreme servers be running the latest versions of the Mbox Extreme and the Mbox Daemon applications, and that all computers have compatible network settings.
  • Page 142 To add an Mbox Extreme server for monitoring, double-click on the server. The server(s) will be added to the window: At the Server View Settings section of the Preferences window, adjust the Size (width in pixels), Mode (single or dual output), Aspect (4:3 or 16:9), and number of columns as desired.
  • Page 143 To delete a Server View or Breakout View, right-click on the view and then select "Remove" from the pop-up menu. To see more information about a server or layer, hover the cursor over one of the Breakout video streams for approximately 3 seconds. ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 144: Description Of Indicators

    The Mbox Extreme application can be running, but unless the Daemon application is also running, Remote II will only display the red dot and will not provide any feedback. Server IP Address – each Mbox Extreme server’s IP address is shown under the server’s name in the Server View column.

  • Page 145: Setting Mbox Extreme Server Preferences Remotely

    Step 5. Use X, Y, W, and H fields to specify an origin (X, Y) and size (Width, Height) for the rectangle. Keep in mind that the origin (0,0) of Mbox Extreme's display is the top-left corner. Step 6. Use Line field to enter a lineweight for the rectangle. (The default lineweight is 1.) Step 7.

  • Page 146: Server Control Commands

    File Sharing Off – turns File Sharing off. Go Fullscreen – if the Mbox Extreme application is in Window mode, it will enter Fullscreen mode. Exit Fullscreen – if the Mbox Extreme application is in Fullscreen mode, it will enter Window mode.

  • Page 147: Timecode Window

    Remote II. Instead, you can use any browser to view the same information. Just type the following URL into the navigation field of the browser: http:// IP Address of server/Mbox/MboxContent.html For example: http://192.168.0.123/Mbox/MboxContent.html ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 148 Notes ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 149: Appendix B. Maintenance

    MAINTENANCE This appendix contains procedures for extended care of the Mbox Extreme server. ROUTINE MAINTENANCE...

  • Page 150: Routine Maintenance

    Step 3. Remove grill and air filter. Step 4. Clean filter with compressed air (or water, if allowed to fully dry). Step 5. Re-install. Air Filter Grill Screw (6) Figure B-1: Air Filter Removal ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 151: Removing The Computer

    Step 2. At front of rack, remove grill and air filter. Refer back to Figure B-1 on page 142. Step 3. Carefully slide computer out of case (Figure B-2). Step 4. Remove side brackets from computer. Figure B-2: Computer Removal ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 152 Notes ® MBOX EXTREME MEDIA SERVER USER MANUAL...

  • Page 153: Appendix C. Dmx512 Mapping

    DMX512 MAPPING This Appendix contains tables for the combined DMX512 channel map, as well as, additional controls such as playmodes, tiling, shutter shapes, aspect control, blending control, texture effect, transitions, and built-in shapes. DMX512 MAPPING CHARTS...

  • Page 154: Dmx512 Mapping Charts

    Mbox Extreme Control Channel Breakdown One Mbox Extreme Media Server running v3.2 software or greater is made up of between 14 and 22 fixtures depending on the operating mode. For ease of use, some consoles may split the Layer fixture into two separate fixtures.
  • Page 155 Layer 7 Layer 6 Layer 8 Layer 9 Layer 7 372 Total Layer 10 Layer 8 DMX Channels Layer 11 Layer 9 Layer 12 Layer 10 372 Total DMX Channels Layer 11 Layer 12 ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 156 Keystone Control Keystone Control Layer 1 Layer 1 Layer 2 Layer 2 Layer 3 Layer 3 Layer 4 Layer 4 Layer 5 Layer 5 Layer 6 Layer 6 Total DMX Total DMX Channels Channels ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 157 Blur No function Pixel Map Intensity master for pixel- Level mapping Art-Net output Pixel Map Control functions for pixel- Control mapping Audio Level master for audio output Volume ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 158 Corner 3X adjustment Shutter Rotation of shutters Top-Left corner U/D Rotation Corner 3Y adjustment Top-Right corner L/R Corner 4X adjustment Top-Right corner U/D Corner 4Y adjustment Keystone Rotation of entire keystoned Rotation image ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 159 Moves the layer towards and Modifier 1B Second modifier Z Position away from the camera (3D Object objects only) 3D effect applied to the layer Effect 2 Modifier 2A First modifier Modifier 2B Second modifier ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 160 Camera Fog and Blur controls are mapped to Blend and Overlap respectively. These controls are used to Values Command make changes to the blend for use with the Wide Pan- Enable All oramic mode. Disable Masked Disable All ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 161 A round iris, scale is magnified to 30-39 Iris Mode Second Order Shallow enclose the screen. No other controls. A Bezier curve is drawn touching the "Blob" 40-49 midpoints of the rectangle formed by Mode Leko Mode. ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 162 4x4 - 2 of 16 4x4 - 3 of 16 4x4 - 16 of 16 Tiling Positions are in row major order (rows are filled in order). For example, the 3x3 arrangement is laid out as follows: ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 163 DMX 210, 25% blend time at DMX 165 Note that each Aspect Control range is a ratio applied over the native aspect ratio of the file. e.g. 1:1 x 4:3 = 4:3 ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 164 141 - 152 Layer Copy Raw Layer 1 - Layer 12 underlying colors (blacks appear transparent) Local Video Input 4 underlying colors are subtracted Invert from layer’s colors (blacks appear Subtractive opaque) ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 165 Vortex vortex distortion radius angle Lozenge lozenge distortion width thickness Edge Work B&W conversion radius Edge Detect edge detection with color intensity Crystallize break up into crystal pattern radius ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 166 Drop Shadow X-offset Y-offset Drop Shadow w/ position Drop Shadow 2 Simple drop shadow offset amount Luma Lines Color & Luma block effect width rows ASCII Art Converts image to characters scale desat ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 167 This effect requires that the second effect channel on the corresponding layer be set to 255. At that point, Mod 2A sets the half- universe for the start addr. This effect is quite complex and you should contact a PRG representative if you want to use it, as further settings are required.
  • Page 168 Split L/R Center old image splits and slides left and right from the center Split Down old image splits and slides down Split Up old image splits and slides up ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 169 Newsflash 1 objects spin in/out both in same direction, variable spin w/ Object XFade Angle Newsflash 2 as above but objects spin in opposite directions MbE: Y = Built-in, N = Supplementary File ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 170 The damping is divided equally between the start and end of the movement curve. Effect parameters can be adjusted during a move to affect only one side of the curve. ® MBOX EXTREME MEDIA SERVER USER MANUAL...
  • Page 171 Mbox Extreme® Media Server User Manual Version as of: November 16, 2011 PRG part number: 02.9800.0001.35...
  • Page 172 Production Resource Group Dallas Office 8617 Ambassador Row, Suite 120 Dallas, Texas 75247 www.prg.com...

Table of Contents
