Escort iLog User Manual page 9

iLog User Guide
The 'Program and Configure' wizard will display the following window (see figure 1.5 below). If
your iLog logger cannot be programmed the logger tick box (located below the description
heading) will not be checked and you will not be able to proceed. If your logger is password-
protected, you will be prompted for the password upon selecting the tick box.
To proceed to the next stage of the 'Program and Configure' wizard select the next button located
at the bottom of the wizard window.
Logger tick box
Figure 1.5 – Program and Configure Search Window
9
