Before initial use, see "Getting Started"
on page 9.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them for
future reference.
TG7851TU(en-en)_0718_ver011.pdf
Operating Instructions
Model No.
1
Digital Cordless Phone
KX-TG7851TU
2013/07/18
11:59:58
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TG7851TU
Summary of Contents for Panasonic KX-TG7851TU
-
Page 1: Operating Instructions
Digital Cordless Phone KX-TG7851TU Model No. Before initial use, see “Getting Started” on page 9. Thank you for purchasing a Panasonic product. Please read these operating instructions before using the unit and save them for future reference. TG7851TU(en-en)_0718_ver011.pdf 2013/07/18 11:59:58... -
Page 2: Table Of Contents
Table of Contents Introduction Transferring calls, conference calls ....32 Accessory information ........3 Useful Information General information ........4 Character entry ..........33 Important Information Error messages ..........35 Troubleshooting .........36 For your safety ..........5 Important safety instructions ......6 Index For best performance ........6 Index............39 Other information .........7 Specifications ..........7... -
Page 3: Introduction
Telephone line cord Rechargeable batteries Handset cover See page 3 for replacement battery information. The handset cover comes attached to the handset. Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information. Accessory item Model number Rechargeable HHR-4MVT or HHR-4MRT batteries Battery type: –... -
Page 4: General Information
R In the event of problems, you should contact your equipment supplier in the first instance. Declaration of Conformity: R Panasonic System Networks Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. -
Page 5: Important Information
Important Information R Do not allow the AC adaptor or telephone line cord to be excessively pulled, bent or For your safety placed under heavy objects. To prevent severe injury and loss of life/ Operating safeguards property, read this section carefully before using the product to ensure proper and safe R Unplug the product from power outlets operation of your product. -
Page 6: Important Safety Instructions
R Do not open or mutilate the batteries. Base unit location/avoiding noise Released electrolyte from the batteries is The base unit and other compatible Panasonic corrosive and may cause burns or injury to units use radio waves to communicate with the eyes or skin. -
Page 7: Other Information
Important Information should not be placed in rooms where the These symbols (A, B, C) on the products, temperature is less than 0 °C or greater packaging, and/or accompanying documents than 40 °C. Damp basements should also mean that used electrical and electronic be avoided. - Page 8 Important Information DECT (Digital Enhanced Cordless Telecommunications), GAP (Generic Access Profile) R Frequency range: 1.88 GHz to 1.90 GHz R RF transmission power: Approx. 10 mW (average power per channel) R Power source: 220–240 V AC, 50/60 Hz R Power consumption: Base unit: Standby: Approx.
-
Page 9: Getting Started
R USE ONLY Ni-MH batteries AAA (R03) size. Connections R Do NOT use Alkaline/Manganese/Ni-Cd batteries. n Base unit R Confirm correct polarities ( R Use only the supplied Panasonic AC adaptor PNLV226CE. Press plug firmly. Hook “Click” Rechargeable Ni-MH ONLY Use only the supplied telephone line cord. -
Page 10: Note When Setting Up
In For replacement, we recommend using the this case, place the handset on the base Panasonic rechargeable batteries noted on unit or charger and let it charge for at least page 3, 6. 7 hours. -
Page 11: Controls
Getting Started Charge contacts Controls n Control type Soft keys The handset features 2 soft keys. By Handset pressing a soft key, you can select the feature shown directly above it on the display. Navigator key – MDN, MCN, MFN, or MEN: Scroll through various lists and items. -
Page 12: Display
Getting Started Handset soft key icons Display Icon Action Handset display items Returns to the previous screen or outside call. Item Meaning Displays the menu. Range status: The more bars Accepts the current selection. visible, the closer the handset is to the base unit. Makes a call. -
Page 13: Screen Saver Mode
Getting Started Icon Feature Display language Time Settings The display language is preset to French. Caller List Sample displays shown in these operating instructions are shown in English. Intercom N (right soft key) #110 Initial Setup MbN: Select your desired language. a Ringer Setup MOKN Caller Barred... -
Page 14: One Touch Eco Mode
Getting Started MbN: Select the desired setting. Programming the display mode beforehand MOKN a MeN N (right soft key) #192 MbN: Select the desired setting. a MOKN One touch eco mode a MeN Note: The MR/ECON button on the handset enables you to activate the eco function with one R When in multiple items display mode, you touch. -
Page 15: Making/Answering Calls
Making/Answering Calls MbN: Select the desired phone number. Making calls MbN: “Yes” a MOKN a MeN Lift the handset and dial the phone number. Pause (for PBX/long distance service R To correct a digit, press MCN. users) Press M A pause is sometimes required when making When you finish talking, press MeN or calls using a PBX or long distance service. -
Page 16: Useful Features During A Call
Making/Answering Calls Note: MbN: Select the desired volume. R To change the recall/flash time, see MOKN a MeN page 23. Temporary handset ringer off For call waiting or Call Waiting While the handset is ringing for a call, you can Caller ID service users turn the ringer off temporarily by pressing M To use call waiting or Call Waiting Caller ID,... -
Page 17: Key Lock
Making/Answering Calls R This feature is not available using the Note: speakerphone. R Calls to emergency numbers cannot be made until key lock is turned off. Handset equalizer This feature clarifies the voice of the person you are talking to, producing a more natural-sounding voice that is easier to hear and understand. -
Page 18: Shared Phonebook
Shared Phonebook Press the dial key (0 to 9, or #) which Shared phonebook contains the character you are searching for (page 33). The shared phonebook allows you to make R Press the same dial key repeatedly to calls without having to dial manually. Any display the first entry corresponding to handset registered to the base unit can use each character located on that dial key. - Page 19 Shared Phonebook MbN: “Phonebook” a MOKN MbN: Select the desired entry. Press M N (right soft key) to dial the number. Note: R When storing a calling card access number and your PIN in the phonebook as one phonebook entry, press MDN (Pause) to add pauses after the number and PIN as necessary (page 15).
-
Page 20: Speed Dial
Speed Dial MbN: “Yes” a MOKN Speed dial You can assign 1 phone number to each of the dial keys (1 to 3) on the handset. Viewing speed dial key assignments Adding phone numbers to speed You can see the speed dial key assignments dial keys on the handset display. -
Page 21: Programming
Programming Programmable settings You can customise the unit by programming the following features using the handset. To access the features, there are 2 methods. n Scrolling through the display menus N (right soft key) Press MCN, MDN, MEN, or MFN to select the desired main menu. a MOKN Press MCN or MDN to select the desired item from the next sub-menus. - Page 22 Programming Main menu: “Initial Setup” Sub-menu 1 Sub-menu 2 Settings Code Ringer Setup 0-6: Off-6 <6> #160 Ringer Volume *3, *4 <Ringtone 1> #161 – Ringtone Night Mode 1: On #238 – On/Off 0: <Off> Night Mode <23:00/06:00> #237 – Start/End Night Mode 1: 30 sec.
- Page 23 Programming Sub-menu 1 Sub-menu 2 Settings Code – 1: <On> #165 – Keytones 0: Off – – #256 Call Restrict – 1: On #200 Auto Talk 0: <Off> Line Setup 1: Pulse #120 Dial Mode 2: <Tone> *1, *9 0: 900 msec. #121 Recall/Flash 1: 700 msec.
-
Page 24: Special Programming
Programming Sub-menu 1 Sub-menu 2 Settings Code *1, *5 – 1: <On> #173 – First Ring 0: Off Main menu: “Caller Barred” Operation Code Storing/Viewing bar call numbers. #217 If you program these settings using one of the handsets, you do not need to program the same item using another handset. -
Page 25: Night Mode
Programming MbN: Select the desired alarm option. a Night mode MOKN Night mode allows you to select a period of “Off” time during which the handset will not ring for outside calls. This feature is useful for time Turns alarm off. Go to step 9. periods when you do not want to be disturbed, “Once”... -
Page 26: Changing The Handset Name
Programming MbN: Select the entry to be barred. a Changing the handset name N a M Each handset can be given a customised MbN: “Save CID” a MOKN name (“Bob”, “Kitchen”, etc.). This is useful MbN: “Caller Barred” a MOKN when you make intercom calls between handsets. -
Page 27: Registering A Unit
Programming R “ ” is displayed next to the selected Registering a handset to the handset numbers. base unit R To cancel a selected handset, press the same dial key again. “ ” The supplied handset and base unit are disappears. - Page 28 Increasing the range of the base unit You can increase the signal range of the base unit by using a DECT repeater. Please use only the Panasonic DECT repeater noted on page 3. Contact your Panasonic dealer for details. Important: R Before registering the repeater to this base unit, you must turn the repeater mode on.
-
Page 29: Caller Id Service
Caller ID Service phonebook, the stored name in the phonebook is displayed and logged in the Using Caller ID service caller list. Important: R This unit is Caller ID compatible. To use Caller ID features, you must subscribe to a Caller list Caller ID service. -
Page 30: Erasing All Caller Information
Caller ID Service Erasing selected caller information MCN ( ) MbN: Select the desired entry. N a MbN: “Yes” a MOKN a MeN Erasing all caller information MCN ( ) N a MbN: “Yes” a MOKN a MeN Storing caller information to the phonebook MCN ( ) MbN: Select the desired entry. -
Page 31: Voice Mail Service
Voice Mail Service Voice mail service Voice mail is an automatic answering service offered by your service provider/telephone company. After you subscribe to this service, your service provider/telephone company’s voice mail system answers calls for you when you are unavailable to answer the phone or when your line is busy. -
Page 32: Intercom/Locator
Intercom/Locator MbN: “Intercom” a MOKN Intercom MbN: Select the desired unit. a MOKN Intercom calls can be made between Wait for the paged party to answer. handsets. R If the paged party does not answer, press M N to return to the outside call. Note: To complete the transfer: R When paging the handset, the paged... -
Page 33: Useful Information
Useful Information Character entry The dial keys are used to enter characters and numbers. Each dial key has multiple characters assigned to it. The characters that can be entered depend on the character entry mode (page 33). – Press MFN or MEN to move the cursor left or right. –... - Page 34 Useful Information Extended 1 character table ( R The following are used for both uppercase and lowercase: Extended 2 character table ( R The following are used for both uppercase and lowercase: Cyrillic character table ( TG7851TU(en-en)_0718_ver011.pdf 2013/07/18 12:00:01...
-
Page 35: Error Messages
Useful Information Error messages Display message Cause/solution Base no power R The handset has lost communication with the base unit. Move closer to the base unit and try again. No link to base. R Unplug the base unit’s AC adaptor to reset the unit. Reconnect Reconnect main base the adaptor and try again. -
Page 36: Troubleshooting
Useful Information Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the base unit’s AC adaptor and turn off the handset, then reconnect the base unit’s AC adaptor and turn on the handset. General use Problem Cause/solution The handset does not... -
Page 37: Battery Recharge
Useful Information Problem Cause/solution I cannot register a R The maximum number of handsets (6) is already registered to handset to a base unit. the base unit. Cancel unused handset registrations from the base unit (page 27). R You entered the wrong PIN. If you forget your PIN, contact an authorised service centre. -
Page 38: Liquid Damage
Useful Information Caller ID Problem Cause/solution Caller information is not R You must subscribe to a Caller ID service. Contact your service displayed. provider/telephone company for details. R If your unit is connected to any additional telephone equipment, remove and plug the unit directly into the wall jack. R If you use a DSL/ADSL service, we recommend connecting a DSL/ADSL filter between the base unit and the telephone line jack. -
Page 39: Index
Index Phonebook: 18 PIN: 27 Index Power failure: 10 Power on/off: 13 Additional handsets: 27 Privacy mode: 23 Alarm: 24 Recall/flash: 16 Answering calls: 15 Redialling: 15 Auto talk: 15, 23 Repeater: 28 Battery: 9, 10 Ringer tone: 22 Call restriction: 26 Speakerphone: 15 Call share: 17 Speed dial: 20... - Page 40 (found on the bottom of the base unit) Name and address of dealer Attach your purchase receipt here. 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Web Site: http://www.panasonic.net/ © Panasonic System Networks Co., Ltd. 2013 *PNQX5889ZA* *PNQX5889ZA* TU-1/2 PNQX5889ZA TT0813YK0 (E) TG7851TU(en-en)_0718_ver011.pdf...
