CITROEN C3 PICASSO User Manual

EMERGENCY CALL

ASSISTANCE CALL

AUDIO AND TELEMATICS

1
3 4 5
2
1. Engine not running
- Short press: on/off.
- Long press: CD pause, mute for the radio.
Engine running
- Short press: CD pause, mute for the radio.
- Long press: reinitialisation of the system.
2. Volume adjustment (each source is independent, including also
navigation messages and alerts).
3. Access to the "Radio" Menu. Display the list of stations.
4. Access to the "Music" Menu. Display the tracks.
5. Access to the "SETUP" menu.
Long press: access to the GPS coverage and the demonstration
mode.
2
3 4 5
1
1. On/Off and volume adjustment.
2. CD eject.
3. Selection of the display on the screen from the following modes:
Audio (AUDIO), Trip Computer (TRIP) and Telephone (TEL)
functions.
4. Selection of source: radio, audio CD/MP3 CD, USB, Jack
connection, Streaming.
5. Selection of FM1, FM2, FMast and AM.
Bonnet
A. Interior release lever.
B. Exterior safety catch.
C. Bonnet stay.
Fiche_loueur_C3_Picasso_en_01-201 1 Fiche_loueur_C3_Picasso_en_01-201 1
MAIN MENU
Press the "MENU" button to gain access to the
main menu .

FUEL TANK

1. Opening the fuel fi ller fl ap.
2. Opening and hooking the fuel fi ller cap.
Capacity of the tank: approximately 50 litres (petrol) or 48 litres
(Diesel).

MISFUEL PREVENTION

Mechanical device which prevents fi lling the tank of a Diesel vehicle
with petrol. It avoids the risk of engine damage that can result from
fi lling with the wrong fuel.
Located in the fi ller neck, the misfuel prevention device appears
when the fi ller cap is removed.
When a petrol fi ller nozzle is introduced into the fuel fi ller neck of
your Diesel vehicle, it comes into contact with the fl ap. The system
remains closed and prevents fi lling.
Do not persist but introduce a Diesel type fi ller nozzle.

PANORAMIC GLASS SUNROOF

Lift the handle of the blind concerned and release.

STEERING WHEEL ADJUSTMENT

1. Release the adjustment mechanism.
2. Adjust for height and reach.
3. Lock the adjustment mechanism.

ELECTRIC WINDOWS

1. Driver's electric window control switch.
2. Passenger's electric window control switch.
3. Rear right electric window control switch.
4. Rear left electric window control switch.
5. Deactivating the rear electric window and door controls.

GEAR SHIFT INDICATOR

System which reduces fuel consumption by advising the driver to
change up on vehicles fi tted with a manual gearbox.
READY TO GO
CITROËN C3 PICASSO

REMOTE CONTROL KEY

A. Unfolding/Folding the key.
B. Unlocking the vehicle.
C . Normal locking of the vehicle.
Vehicle location.

DOOR MIRRORS

Move control A to the right or to the left to select the corresponding
mirror.
Move control B in all four directions to adjust.

PARKING BRAKE

Applying
Pull the parking brake lever fully up to immobilise your vehicle.
Releasing
Pull the parking brake lever gently, press the release button
then lower the lever fully.
